RF-Diffusion: Radio Signal Generation via Time-Frequency Diffusion

Along with AIGC shines in CV and NLP, its potential in the wireless domain has also emerged in recent years. Yet, existing RF-oriented generative solutions are ill-suited for generating high-quality, time-series RF data due to limited representation capabilities. In this work, inspired by the stellar achievements of the diffusion model in CV and NLP, we adapt it to the RF domain and propose RF-Diffusion. To accommodate the unique characteristics of RF signals, we first introduce a novel Time-Frequency Diffusion theory to enhance the original diffusion model, enabling it to tap into the information within the time, frequency, and complex-valued domains of RF signals. On this basis, we propose a Hierarchical Diffusion Transformer to translate the theory into a practical generative DNN through elaborated design spanning network architecture, functional block, and complex-valued operator, making RF-Diffusion a versatile solution to generate diverse, high-quality, and time-series RF data. Performance comparison with three prevalent generative models demonstrates the RF-Diffusion's superior performance in synthesizing Wi-Fi and FMCW signals. We also showcase the versatility of RF-Diffusion in boosting Wi-Fi sensing systems and performing channel estimation in 5G networks.

Design and Optimization of Cooperative Sensing With Limited Backhaul Capacity

This paper introduces a cooperative sensing framework designed for integrated sensing and communication cellular networks. The framework comprises one base station (BS) functioning as the sensing transmitter, while several nearby BSs act as sensing receivers. The primary objective is to facilitate cooperative target localization by enabling each receiver to share specific information with a fusion center (FC) over a limited capacity backhaul link. To achieve this goal, we propose an advanced cooperative sensing design that enhances the communication process between the receivers and the FC. Each receiver independently estimates the time delay and the reflecting coefficient associated with the reflected path from the target. Subsequently, each receiver transmits the estimated values and the received signal samples centered around the estimated time delay to the FC. To efficiently quantize the signal samples, a Karhunen-Lo\`eve Transform coding scheme is employed. Furthermore, an optimization problem is formulated to allocate backhaul resources for quantizing different samples, improving target localization. Numerical results validate the effectiveness of our proposed advanced design and demonstrate its superiority over a baseline design, where only the locally estimated values are transmitted from each receiver to the FC.

Reshaping the ISAC Tradeoff Under OFDM Signaling: A Probabilistic Constellation Shaping Approach

Integrated sensing and communications is regarded as a key enabling technology in the sixth generation networks, where a unified waveform, such as orthogonal frequency division multiplexing (OFDM) signal, is adopted to facilitate both sensing and communications (S&C). However, the random communication data embedded in the OFDM signal results in severe variability in the sidelobes of its ambiguity function (AF), which leads to missed detection of weak targets and false detection of ghost targets, thereby impairing the sensing performance. Therefore, balancing between preserving communication capability (i.e., the randomness) while improving sensing performance remains a challenging task. To cope with this issue, we characterize the random AF of OFDM communication signals, and demonstrate that the AF variance is determined by the fourth-moment of the constellation amplitudes. Subsequently, we propose an optimal probabilistic constellation shaping (PCS) approach by maximizing the achievable information rate (AIR) under the fourth-moment, power and probability constraints, where the optimal input distribution may be numerically specified through a modified Blahut-Arimoto algorithm. To reduce the computational overheads, we further propose a heuristic PCS approach by actively controlling the value of the fourth-moment, without involving the communication metric in the optimization model, despite that the AIR is passively scaled with the variation of the input distribution. Numerical results show that both approaches strike a scalable performance tradeoff between S&C, where the superiority of the PCS-enabled constellations over conventional uniform constellations is also verified. Notably, the heuristic approach achieves very close performance to the optimal counterpart, at a much lower computational complexity.

Fully-Passive versus Semi-Passive IRS-Enabled Sensing: SNR and CRB Comparison

This paper investigates the sensing performance of two intelligent reflecting surface (IRS)-enabled non-line-of-sight (NLoS) sensing systems with fully-passive and semi-passive IRSs, respectively. In particular, we consider a fundamental setup with one base station (BS), one uniform linear array (ULA) IRS, and one point target in the NLoS region of the BS. Accordingly, we analyze the sensing signal-to-noise ratio (SNR) performance for a target detection scenario and the estimation Cram\'er-Rao bound (CRB) performance for a target's direction-of-arrival (DoA) estimation scenario, in cases where the transmit beamforming at the BS and the reflective beamforming at the IRS are jointly optimized. First, for the target detection scenario, we characterize the maximum sensing SNR when the BS-IRS channels are line-of-sight (LoS) and Rayleigh fading, respectively. It is revealed that when the number of reflecting elements $N$ equipped at the IRS becomes sufficiently large, the maximum sensing SNR increases proportionally to $N^2$ for the semi-passive-IRS sensing system, but proportionally to $N^4$ for the fully-passive-IRS counterpart. Then, for the target's DoA estimation scenario, we analyze the minimum CRB performance when the BS-IRS channel follows Rayleigh fading. Specifically, when $N$ grows, the minimum CRB decreases inversely proportionally to $N^4$ and $N^6$ for the semi-passive and fully-passive-IRS sensing systems, respectively. Finally, numerical results are presented to corroborate our analysis across various transmit and reflective beamforming design schemes under general channel setups. It is shown that the fully-passive-IRS sensing system outperforms the semi-passive counterpart when $N$ exceeds a certain threshold. This advantage is attributed to the additional reflective beamforming gain in the IRS-BS path, which efficiently compensates for the path loss for a large $N$.

Probabilistic Constellation Shaping for OFDM-Based ISAC Signaling

Integrated Sensing and Communications (ISAC) has garnered significant attention as a promising technology for the upcoming sixth-generation wireless communication systems (6G). In pursuit of this goal, a common strategy is that a unified waveform, such as Orthogonal Frequency Division Multiplexing (OFDM), should serve dual-functional roles by enabling simultaneous sensing and communications (S&C) operations. However, the sensing performance of an OFDM communication signal is substantially affected by the randomness of the data symbols mapped from bit streams. Therefore, achieving a balance between preserving communication capability (i.e., the randomness) while improving sensing performance remains a challenging task. To cope with this issue, in this paper we analyze the ambiguity function of the OFDM communication signal modulated by random data. Subsequently, a probabilistic constellation shaping (PCS) method is proposed to devise the probability distributions of constellation points, which is able to strike a scalable S&C tradeoff of the random transmitted signal. Finally, the superiority of the proposed PCS method over conventional uniformly distributed constellations is validated through numerical simulations.

An Overview on IEEE 802.11bf: WLAN Sensing

With recent advancements, the wireless local area network (WLAN) or wireless fidelity (Wi-Fi) technology has been successfully utilized to realize sensing functionalities such as detection, localization, and recognition. However, the WLANs standards are developed mainly for the purpose of communication, and thus may not be able to meet the stringent requirements for emerging sensing applications. To resolve this issue, a new Task Group (TG), namely IEEE 802.11bf, has been established by the IEEE 802.11 working group, with the objective of creating a new amendment to the WLAN standard to meet advanced sensing requirements while minimizing the effect on communications. This paper provides a comprehensive overview on the up-to-date efforts in the IEEE 802.11bf TG. First, we introduce the definition of the 802.11bf amendment and its formation and standardization timeline. Next, we discuss the WLAN sensing use cases with the corresponding key performance indicator (KPI) requirements. After reviewing previous WLAN sensing research based on communication-oriented WLAN standards, we identify their limitations and underscore the practical need for the new sensing-oriented amendment in 802.11bf. Furthermore, we discuss the WLAN sensing framework and procedure used for measurement acquisition, by considering both sensing at sub-7GHz and directional multi-gigabit (DMG) sensing at 60 GHz, respectively, and address their shared features, similarities, and differences. In addition, we present various candidate technical features for IEEE 802.11bf, including waveform/sequence design, feedback types, as well as quantization and compression techniques. We also describe the methodologies and the channel modeling used by the IEEE 802.11bf TG for evaluation. Finally, we discuss the challenges and future research directions to motivate more research endeavors towards this field in details.

Deterministic-Random Tradeoff of Integrated Sensing and Communications in Gaussian Channels: A Rate-Distortion Perspective

Integrated sensing and communications (ISAC) is recognized as a key enabling technology for future wireless networks. To shed light on the fundamental performance limits of ISAC systems, this paper studies the deterministic-random tradeoff between sensing and communications (S&C) from a rate-distortion perspective under vector Gaussian channels. We model the ISAC signal as a random matrix that carries information, whose realization is perfectly known to the sensing receiver, but is unknown to the communication receiver. We characterize the sensing mutual information conditioned on the random ISAC signal, and show that it provides a universal lower bound for distortion metrics of sensing. Furthermore, we prove that the distortion lower bound is minimized if the sample covariance matrix of the ISAC signal is deterministic. We then offer our understanding of the main results by interpreting wireless sensing as non-cooperative source-channel coding, and reveal the deterministic-random tradeoff of S&C for ISAC systems. Finally, we provide sufficient conditions for the achievability of the distortion bound by analyzing a specific example of target response matrix estimation.

Cramér-Rao Bound Minimization for IRS-Enabled Multiuser Integrated Sensing and Communication with Extended Target

This paper investigates an intelligent reflecting surface (IRS) enabled multiuser integrated sensing and communication (ISAC) system, which consists of one multi-antenna base station (BS), one IRS, multiple single-antenna communication users (CUs), and one extended target at the non-line-of-sight (NLoS) region of the BS. The IRS is deployed to not only assist the communication from the BS to the CUs, but also enable the BS's NLoS target sensing based on the echo signals from the BS-IRS-target-IRS-BS link. To provide full degrees of freedom for sensing, we suppose that the BS sends additional dedicated sensing signals combined with the information signals. Accordingly, we consider two types of CU receivers, namely Type-I and Type-II receivers, which do not have and have the capability of cancelling the interference from the sensing signals, respectively. Under this setup, we jointly optimize the transmit beamforming at the BS and the reflective beamforming at the IRS to minimize the Cram\'er-Rao bound (CRB) for estimating the target response matrix with respect to the IRS, subject to the minimum signal-to-interference-plus-noise ratio (SINR) constraints at the CUs and the maximum transmit power constraint at the BS. We present efficient algorithms to solve the highly non-convex SINR-constrained CRB minimization problems, by using the techniques of alternating optimization and semi-definite relaxation. Numerical results show that the proposed design achieves lower estimation CRB than other benchmark schemes, and the sensing signal interference pre-cancellation is beneficial when the number of CUs is greater than one.

Stochastic Particle-Based Variational Bayesian Inference for Multi-band Radar Sensing

Multi-band fusion is an important technology to improve the radar sensing performance. In the multi-band radar sensing signal model, the associated likelihood function has oscillation phenomenon, which makes it difficult to obtain high-accuracy parameter estimation. To cope with this challenge, we divide the radar target parameter estimation into two stages of coarse estimation and refined estimation, where the coarse estimation is used to narrow down the search range for the refined estimation, and the refined estimation is based on the Bayesian approach to avoid the convergence to a bad local optimum of the likelihood function. Specifically, in the coarse estimation stage, we employ a root MUSIC algorithm to achieve initial estimation. Then, we apply the block stochastic successive convex approximation (SSCA) approach to derive a novel stochastic particle-based variational Bayesian inference (SPVBI) algorithm for the Bayesian estimation of the radar target parameters in the refined stage. Unlike the conventional particle-based VBI (PVBI) in which only the probability of each particle is optimized and the per-iteration computational complexity increases exponentially with the number of particles, the proposed SPVBI optimizes both the position and probability of each particle, and it adopts the block SSCA to significantly improve the sampling efficiency by averaging over iterations. As such, it is shown that the proposed SPVBI can achieve a better performance than the conventional PVBI with a much smaller number of particles and per-iteration complexity. Finally, extensive simulations verify the advantage of the proposed algorithm over various baseline algorithms.

Fundamental Limits and Optimization of Multiband Sensing

Multiband sensing is a promising technology that utilizes multiple non-contiguous frequency bands to achieve high-resolution target sensing. In this paper, we investigate the fundamental limits and optimization of multiband sensing, focusing on the fundamental limits associated with time delay. We first derive a Fisher information matrix (FIM) with a compact form using the Dirichlet kernel and then derive a closed-form expression of the Cramer-Rao bound (CRB) for the delay separation in a simplified case to reveal useful insights. Then, a metric called the statistical resolution limit (SRL) that provides a resolution limit is employed to investigate the fundamental limits of delay resolution. The fundamental limits of delay estimation are also investigated based on the CRB and Ziv-Zakai bound (ZZB). Based on the above derived fundamental limits, numerical results are presented to analyze the effect of frequency band apertures and phase distortions on the performance limits of the multiband sensing systems. We formulate an optimization problem to find the optimal system configuration in multiband sensing systems with the objective of minimizing the delay SRL. To solve this non-convex constrained problem, we propose an efficient alternating optimization (AO) algorithm which iteratively optimizes the variables using successive convex approximation (SCA) and one-dimensional search. Simulation results demonstrate the effectiveness of the proposed algorithm.
