Analysis of Null Related Beampattern Measures and Signal Quantization Effects for Linear Differential Microphone Arrays

A differential microphone array (DMA) offers enhanced capabilities to obtain sharp nulls at the cost of relatively broad peaks in the beam power pattern. This can be used for applications that require nullification or attenuation of interfering sources. To the best of our knowledge, the existing literature lacks measures that directly assess the efficacy of nulls, and null-related measures have not been investigated in the context of differential microphone arrays (DMAs). This paper offers new insights about the utility of DMAs by proposing measures that characterize the nulls in their beam power patterns. We investigate the performance of differential beamformers by presenting and evaluating null-related measures namely null depth (ND) and Null Width (NW) as a function of depth level relative to the beam power pattern maxima. A study of signal quantization effects due to data acquisition for 1st, 2nd and 3rd order linear DMAs and for different beampatterns i.e. dipole, cardioid, hypercardioid and supercardioid is presented. An analytical expression for the quantized beamformed output for any general $ N^{th} $ order DMA is formulated. Simulation results of the variation of ND with number of quantization bits and the variation of NW as a function of depth are also presented and inferences are drawn. Lab experiments are conducted in a fully anechoic room to support the simulation results. The measured beampattern exhibits a pronounced null depth, confirming the effectiveness of the experimental setup.

A Wireless Self-Calibrating Ultrasound Microphone Array with Sub-Microsecond Synchronization

We present a novel system architecture for a distributed wireless, self-calibrating ultrasound microphone network for synchronized in-air acoustic sensing. Once deployed the embedded nodes determine their position in the environment using the infrared optical tracking system found in the HTC Vive Lighthouses. After self-calibration, the nodes start sampling the ultrasound microphone while embedding a synchronization signal in the data which is established using a wireless Sub-1GHz RF link. Data transmission is handled via the Wi-Fi 6 radio that is embedded in the nodes' SoC, decoupling synchronization from payload transport. A prototype system with a limited amount of network nodes was used to verify the proposed distributed microphone array's wireless data acquisition and synchronization capabilities. This architecture lays the groundwork for scalable, deployable ultrasound arrays for sound source localization applications in bio-acoustic research and industrial acoustic monitoring.

Effect of Signal Quantization on Performance Measures of a 1st Order One Dimensional Differential Microphone Array

In practical systems, recorded analog signals must be digitized for processing, introducing quantization as a critical aspect of data acquisition. While prior studies have examined quantization effects in various signal processing contexts, its impact on differential microphone arrays (DMAs), particularly in one-dimensional (1D) first-order configurations, remains unexplored. This paper investigates the influence of signal quantization on performance of first-order 1D DMAs across various beampatterns. An analytical expression for quantized beamformed output for a first-order 1D DMA has been formulated. The effect of signal quantization has been studied on array performance measures such as the Beampattern, Directivity Factor (DF), Front-to-Back Ratio (FBR), and null depth (ND). Simulation results reveal that beampattern shape remains structurally invariant across quantization bit depths, with quantization primarily affecting ND. DF and FBR remain constant with the varying number of quantization bits. Additionally, ND is shown to be frequency-independent; however, it increases with increasing quantization bit depths, enhancing interference suppression. The study also examines the effect of steering nulls across the azimuthal range, showing that ND degrades as the null moves closer to the source look direction, indicating reduced interference suppression.

Thinking in Directivity: Speech Large Language Model for Multi-Talker Directional Speech Recognition

Recent studies have demonstrated that prompting large language models (LLM) with audio encodings enables effective speech recognition capabilities. However, the ability of Speech LLMs to comprehend and process multi-channel audio with spatial cues remains a relatively uninvestigated area of research. In this work, we present directional-SpeechLlama, a novel approach that leverages the microphone array of smart glasses to achieve directional speech recognition, source localization, and bystander cross-talk suppression. To enhance the model's ability to understand directivity, we propose two key techniques: serialized directional output training (S-DOT) and contrastive direction data augmentation (CDDA). Experimental results show that our proposed directional-SpeechLlama effectively captures the relationship between textual cues and spatial audio, yielding strong performance in both speech recognition and source localization tasks.

Observability-Aware Active Calibration of Multi-Sensor Extrinsics for Ground Robots via Online Trajectory Optimization

Accurate calibration of sensor extrinsic parameters for ground robotic systems (i.e., relative poses) is crucial for ensuring spatial alignment and achieving high-performance perception. However, existing calibration methods typically require complex and often human-operated processes to collect data. Moreover, most frameworks neglect acoustic sensors, thereby limiting the associated systems' auditory perception capabilities. To alleviate these issues, we propose an observability-aware active calibration method for ground robots with multimodal sensors, including a microphone array, a LiDAR (exteroceptive sensors), and wheel encoders (proprioceptive sensors). Unlike traditional approaches, our method enables active trajectory optimization for online data collection and calibration, contributing to the development of more intelligent robotic systems. Specifically, we leverage the Fisher information matrix (FIM) to quantify parameter observability and adopt its minimum eigenvalue as an optimization metric for trajectory generation via B-spline curves. Through planning and replanning of robot trajectory online, the method enhances the observability of multi-sensor extrinsic parameters. The effectiveness and advantages of our method have been demonstrated through numerical simulations and real-world experiments. For the benefit of the community, we have also open-sourced our code and data at https://github.com/AISLAB-sustech/Multisensor-Calibration.

Lightweight and Robust Multi-Channel End-to-End Speech Recognition with Spherical Harmonic Transform

This paper presents SHTNet, a lightweight spherical harmonic transform (SHT) based framework, which is designed to address cross-array generalization challenges in multi-channel automatic speech recognition (ASR) through three key innovations. First, SHT based spatial sound field decomposition converts microphone signals into geometry-invariant spherical harmonic coefficients, isolating signal processing from array geometry. Second, the Spatio-Spectral Attention Fusion Network (SSAFN) combines coordinate-aware spatial modeling, refined self-attention channel combinator, and spectral noise suppression without conventional beamforming. Third, Rand-SHT training enhances robustness through random channel selection and array geometry reconstruction. The system achieves 39.26\% average CER across heterogeneous arrays (e.g., circular, square, and binaural) on datasets including Aishell-4, Alimeeting, and XMOS, with 97.1\% fewer computations than conventional neural beamformers.

Deep learning based spatial aliasing reduction in beamforming for audio capture

Spatial aliasing affects spaced microphone arrays, causing directional ambiguity above certain frequencies, degrading spatial and spectral accuracy of beamformers. Given the limitations of conventional signal processing and the scarcity of deep learning approaches to spatial aliasing mitigation, we propose a novel approach using a U-Net architecture to predict a signal-dependent de-aliasing filter, which reduces aliasing in conventional beamforming for spatial capture. Two types of multichannel filters are considered, one which treats the channels independently and a second one that models cross-channel dependencies. The proposed approach is evaluated in two common spatial capture scenarios: stereo and first-order Ambisonics. The results indicate a very significant improvement, both objective and perceptual, with respect to conventional beamforming. This work shows the potential of deep learning to reduce aliasing in beamforming, leading to improvements in multi-microphone setups.

ArrayDPS: Unsupervised Blind Speech Separation with a Diffusion Prior

Blind Speech Separation (BSS) aims to separate multiple speech sources from audio mixtures recorded by a microphone array. The problem is challenging because it is a blind inverse problem, i.e., the microphone array geometry, the room impulse response (RIR), and the speech sources, are all unknown. We propose ArrayDPS to solve the BSS problem in an unsupervised, array-agnostic, and generative manner. The core idea builds on diffusion posterior sampling (DPS), but unlike DPS where the likelihood is tractable, ArrayDPS must approximate the likelihood by formulating a separate optimization problem. The solution to the optimization approximates room acoustics and the relative transfer functions between microphones. These approximations, along with the diffusion priors, iterate through the ArrayDPS sampling process and ultimately yield separated voice sources. We only need a simple single-speaker speech diffusion model as a prior along with the mixtures recorded at the microphones; no microphone array information is necessary. Evaluation results show that ArrayDPS outperforms all baseline unsupervised methods while being comparable to supervised methods in terms of SDR. Audio demos are provided at: https://arraydps.github.io/ArrayDPSDemo/.

Unsupervised Blind Speech Separation with a Diffusion Prior

Blind Speech Separation (BSS) aims to separate multiple speech sources from audio mixtures recorded by a microphone array. The problem is challenging because it is a blind inverse problem, i.e., the microphone array geometry, the room impulse response (RIR), and the speech sources, are all unknown. We propose ArrayDPS to solve the BSS problem in an unsupervised, array-agnostic, and generative manner. The core idea builds on diffusion posterior sampling (DPS), but unlike DPS where the likelihood is tractable, ArrayDPS must approximate the likelihood by formulating a separate optimization problem. The solution to the optimization approximates room acoustics and the relative transfer functions between microphones. These approximations, along with the diffusion priors, iterate through the ArrayDPS sampling process and ultimately yield separated voice sources. We only need a simple single-speaker speech diffusion model as a prior along with the mixtures recorded at the microphones; no microphone array information is necessary. Evaluation results show that ArrayDPS outperforms all baseline unsupervised methods while being comparable to supervised methods in terms of SDR. Audio demos are provided at: https://arraydps.github.io/ArrayDPSDemo/.

BERSting at the Screams: A Benchmark for Distanced, Emotional and Shouted Speech Recognition

Some speech recognition tasks, such as automatic speech recognition (ASR), are approaching or have reached human performance in many reported metrics. Yet, they continue to struggle in complex, real-world, situations, such as with distanced speech. Previous challenges have released datasets to address the issue of distanced ASR, however, the focus remains primarily on distance, specifically relying on multi-microphone array systems. Here we present the B(asic) E(motion) R(andom phrase) S(hou)t(s) (BERSt) dataset. The dataset contains almost 4 hours of English speech from 98 actors with varying regional and non-native accents. The data was collected on smartphones in the actors homes and therefore includes at least 98 different acoustic environments. The data also includes 7 different emotion prompts and both shouted and spoken utterances. The smartphones were places in 19 different positions, including obstructions and being in a different room than the actor. This data is publicly available for use and can be used to evaluate a variety of speech recognition tasks, including: ASR, shout detection, and speech emotion recognition (SER). We provide initial benchmarks for ASR and SER tasks, and find that ASR degrades both with an increase in distance and shout level and shows varied performance depending on the intended emotion. Our results show that the BERSt dataset is challenging for both ASR and SER tasks and continued work is needed to improve the robustness of such systems for more accurate real-world use.
