AMSbench: A Comprehensive Benchmark for Evaluating MLLM Capabilities in AMS Circuits

Analog/Mixed-Signal (AMS) circuits play a critical role in the integrated circuit (IC) industry. However, automating Analog/Mixed-Signal (AMS) circuit design has remained a longstanding challenge due to its difficulty and complexity. Recent advances in Multi-modal Large Language Models (MLLMs) offer promising potential for supporting AMS circuit analysis and design. However, current research typically evaluates MLLMs on isolated tasks within the domain, lacking a comprehensive benchmark that systematically assesses model capabilities across diverse AMS-related challenges. To address this gap, we introduce AMSbench, a benchmark suite designed to evaluate MLLM performance across critical tasks including circuit schematic perception, circuit analysis, and circuit design. AMSbench comprises approximately 8000 test questions spanning multiple difficulty levels and assesses eight prominent models, encompassing both open-source and proprietary solutions such as Qwen 2.5-VL and Gemini 2.5 Pro. Our evaluation highlights significant limitations in current MLLMs, particularly in complex multi-modal reasoning and sophisticated circuit design tasks. These results underscore the necessity of advancing MLLMs' understanding and effective application of circuit-specific knowledge, thereby narrowing the existing performance gap relative to human expertise and moving toward fully automated AMS circuit design workflows. Our data is released at https://huggingface.co/datasets/wwhhyy/AMSBench

AMSnet 2.0: A Large AMS Database with AI Segmentation for Net Detection

Current multimodal large language models (MLLMs) struggle to understand circuit schematics due to their limited recognition capabilities. This could be attributed to the lack of high-quality schematic-netlist training data. Existing work such as AMSnet applies schematic parsing to generate netlists. However, these methods rely on hard-coded heuristics and are difficult to apply to complex or noisy schematics in this paper. We therefore propose a novel net detection mechanism based on segmentation with high robustness. The proposed method also recovers positional information, allowing digital reconstruction of schematics. We then expand AMSnet dataset with schematic images from various sources and create AMSnet 2.0. AMSnet 2.0 contains 2,686 circuits with schematic images, Spectre-formatted netlists, OpenAccess digital schematics, and positional information for circuit components and nets, whereas AMSnet only includes 792 circuits with SPICE netlists but no digital schematics.

Automated SAR ADC Sizing Using Analytical Equations

Conventional analog and mixed-signal (AMS) circuit designs heavily rely on manual effort, which is time-consuming and labor-intensive. This paper presents a fully automated design methodology for Successive Approximation Register (SAR) Analog-to-Digital Converters (ADCs) from performance specifications to complete transistor sizing. To tackle the high-dimensional sizing problem, we propose a dual optimization scheme. The system-level optimization iteratively partitions the overall requirements and analytically maps them to subcircuit design specifications, while local optimization loops determines the subcircuits' design parameters. The dependency graph-based framework serializes the simulations for verification, knowledge-based calculations, and transistor sizing optimization in topological order, which eliminates the need for human intervention. We demonstrate the effectiveness of the proposed methodology through two case studies with varying performance specifications, achieving high SNDR and low power consumption while meeting all the specified design constraints.

AMSnet-KG: A Netlist Dataset for LLM-based AMS Circuit Auto-Design Using Knowledge Graph RAG

High-performance analog and mixed-signal (AMS) circuits are mainly full-custom designed, which is time-consuming and labor-intensive. A significant portion of the effort is experience-driven, which makes the automation of AMS circuit design a formidable challenge. Large language models (LLMs) have emerged as powerful tools for Electronic Design Automation (EDA) applications, fostering advancements in the automatic design process for large-scale AMS circuits. However, the absence of high-quality datasets has led to issues such as model hallucination, which undermines the robustness of automatically generated circuit designs. To address this issue, this paper introduces AMSnet-KG, a dataset encompassing various AMS circuit schematics and netlists. We construct a knowledge graph with annotations on detailed functional and performance characteristics. Facilitated by AMSnet-KG, we propose an automated AMS circuit generation framework that utilizes the comprehensive knowledge embedded in LLMs. We first formulate a design strategy (e.g., circuit architecture using a number of circuit components) based on required specifications. Next, matched circuit components are retrieved and assembled into a complete topology, and transistor sizing is obtained through Bayesian optimization. Simulation results of the netlist are fed back to the LLM for further topology refinement, ensuring the circuit design specifications are met. We perform case studies of operational amplifier and comparator design to verify the automatic design flow from specifications to netlists with minimal human effort. The dataset used in this paper will be open-sourced upon publishing of this paper.

Hierarchical Decoupling Capacitor Optimization for Power Distribution Network of 2.5D ICs with Co-Analysis of Frequency and Time Domains Based on Deep Reinforcement Learning

With the growing need for higher memory bandwidth and computation density, 2.5D design, which involves integrating multiple chiplets onto an interposer, emerges as a promising solution. However, this integration introduces significant challenges due to increasing data rates and a large number of I/Os, necessitating advanced optimization of the power distribution networks (PDNs) both on-chip and on-interposer to mitigate the small signal noise and simultaneous switching noise (SSN). Traditional PDN optimization strategies in 2.5D systems primarily focus on reducing impedance by integrating decoupling capacitors (decaps) to lessen small signal noises. Unfortunately, relying solely on frequency-domain analysis has been proven inadequate for addressing coupled SSN, as indicated by our experimental results. In this work, we introduce a novel two-phase optimization flow using deep reinforcement learning to tackle both the on-chip small signal noise and SSN. Initially, we optimize the impedance in the frequency domain to maintain the small signal noise within acceptable limits while avoiding over-design. Subsequently, in the time domain, we refine the PDN to minimize the voltage violation integral (VVI), a more accurate measure of SSN severity. To the best of our knowledge, this is the first dual-domain optimization strategy that simultaneously addresses both the small signal noise and SSN propagation through strategic decap placement in on-chip and on-interposer PDNs, offering a significant step forward in the design of robust PDNs for 2.5D integrated systems.

MetaEarth: A Generative Foundation Model for Global-Scale Remote Sensing Image Generation

The recent advancement of generative foundational models has ushered in a new era of image generation in the realm of natural images, revolutionizing art design, entertainment, environment simulation, and beyond. Despite producing high-quality samples, existing methods are constrained to generating images of scenes at a limited scale. In this paper, we present MetaEarth, a generative foundation model that breaks the barrier by scaling image generation to a global level, exploring the creation of worldwide, multi-resolution, unbounded, and virtually limitless remote sensing images. In MetaEarth, we propose a resolution-guided self-cascading generative framework, which enables the generating of images at any region with a wide range of geographical resolutions. To achieve unbounded and arbitrary-sized image generation, we design a novel noise sampling strategy for denoising diffusion models by analyzing the generation conditions and initial noise. To train MetaEarth, we construct a large dataset comprising multi-resolution optical remote sensing images with geographical information. Experiments have demonstrated the powerful capabilities of our method in generating global-scale images. Additionally, the MetaEarth serves as a data engine that can provide high-quality and rich training data for downstream tasks. Our model opens up new possibilities for constructing generative world models by simulating Earth visuals from an innovative overhead perspective.

AMSNet: Netlist Dataset for AMS Circuits

Today's analog/mixed-signal (AMS) integrated circuit (IC) designs demand substantial manual intervention. The advent of multimodal large language models (MLLMs) has unveiled significant potential across various fields, suggesting their applicability in streamlining large-scale AMS IC design as well. A bottleneck in employing MLLMs for automatic AMS circuit generation is the absence of a comprehensive dataset delineating the schematic-netlist relationship. We therefore design an automatic technique for converting schematics into netlists, and create dataset AMSNet, encompassing transistor-level schematics and corresponding SPICE format netlists. With a growing size, AMSNet can significantly facilitate exploration of MLLM applications in AMS circuit design. We have made an initial set of netlists public, and will make both our netlist generation tool and the full dataset available upon publishing of this paper.

RLPlanner: Reinforcement Learning based Floorplanning for Chiplets with Fast Thermal Analysis

Chiplet-based systems have gained significant attention in recent years due to their low cost and competitive performance. As the complexity and compactness of a chiplet-based system increase, careful consideration must be given to microbump assignments, interconnect delays, and thermal limitations during the floorplanning stage. This paper introduces RLPlanner, an efficient early-stage floorplanning tool for chiplet-based systems with a novel fast thermal evaluation method. RLPlanner employs advanced reinforcement learning to jointly minimize total wirelength and temperature. To alleviate the time-consuming thermal calculations, RLPlanner incorporates the developed fast thermal evaluation method to expedite the iterations and optimizations. Comprehensive experiments demonstrate that our proposed fast thermal evaluation method achieves a mean absolute error (MAE) of 0.25 K and delivers over 120x speed-up compared to the open-source thermal solver HotSpot. When integrated with our fast thermal evaluation method, RLPlanner achieves an average improvement of 20.28\% in minimizing the target objective (a combination of wirelength and temperature), within a similar running time, compared to the classic simulated annealing method with HotSpot.
