Modulating Retroreflector-based Satellite-to-Ground Optical Communications: Sensing and Positioning

This paper focuses on the optimal design of a modulated retroreflector (MRR) laser link to establish a high-speed downlink for cube satellites (CubeSats), taking into account the weight and power limitations commonly encountered by these tiny satellites. To this end, first, a comprehensive channel modeling is conducted considering key real channel parameters including mechanical gimbal error, fast steering mirror angle error, laser beamwidth, MRR area, atmospheric turbulence, and channel coherence time. Accordingly, a closed-form expression for the distribution of the received signal is derived and utilized to propose a maximum likelihood based method to sense and estimate the initial position of the satellite. Subsequently, the distribution of the distance estimation error during the sensing phase is formulated as a function of the laser beamwidth and the gimbal error, which enables us to fine-tune the optimal laser beamwidth to minimize sensing time. Moreover, using the sensing and initial satellite distance estimation, two positioning algorithms are proposed. To compare the performance of the proposed positioning method, we obtain the lower bound of the positioning error as a benchmark. Finally, by providing comprehensive simulations, we evaluate the effect of different parameters on the performance of the considered MRR-based system in both the sensing and positioning phases.

LoS Coverage Analysis for UAV-based THz Communication Networks: Towards 3D Visualization of Wireless Networks

Terahertz (THz) links require a line-of-sight (LoS) connection, which is hard to be obtained in most scenarios. For THz communications, analyses based on LoS probability are not accurate, and a new real LoS model should be considered to determine the LoS status of the link in a real 3D environment. Considering unmanned aerial vehicle (UAV)-based THz networks, LoS coverage is analyzed in this work, where nodes are accurately determined to be in LoS or not. Specifically, by modeling an environment with 3D blocks, our target is to locate a set of UAVs equipped with directional THz links to provide LoS connectivity for the distributed users among the 3D obstacles. To this end, we first characterize and model the environment with 3D blocks. Then, we propose a user-friendly algorithm based on 3D spatial vectors, which determines the LoS status of nodes in the target area. In addition, using 3D modeling, several meta-heuristic algorithms are proposed for UAVs' positioning under 3D blocks in order to maximize the LoS coverage percentage. In the second part of the paper, for a UAV-based THz communication network, a geometrical analysis-based algorithm is proposed, which jointly clusters the distributed nodes and locates the set of UAVs to maximize average network capacity while ensuring the LoS state of distributed nodes among 3D obstacles. Moreover, we also propose a sub-optimal hybrid k-means-geometrical-based algorithm with a low computational complexity that can be used for networks where the topology continuously changes, and thus, users' clustering and UAVs' positioning need to be regularly updated. Finally, by providing various 3D simulations, we evaluate the effect of various system parameters such as the number and heights of UAVs, as well as the density and height of 3D obstacles on the LoS coverage.

UAV Trajectory Optimization for Directional THz Links Using Deep Reinforcement Learning

As an alternative solution for quick disaster recovery of backhaul/fronthaul links, in this paper, a dynamic unmanned aerial vehicles (UAV)-assisted heterogeneous (HetNet) network equipped with directional terahertz (THz) antennas is studied to solve the problem of transferring traffic of distributed small cells. To this end, we first characterize a detailed three-dimensional modeling of the dynamic UAV-assisted HetNet, and then, we formulate the problem for UAV trajectory to minimize the maximum outage probability of directional THz links. Then, using deep reinforcement learning (DRL) method, we propose an efficient algorithm to learn the optimal trajectory. Finally, using simulations, we investigate the performance of the proposed DRL-based trajectory method.

A General Model for Pointing Error of High Frequency Directional Antennas

This paper focuses on providing an analytical framework for the quantification and evaluation of the pointing error for a general case at high-frequency millimeter wave (mmWave) and terahertz (THz) communication links. For this aim, we first derive the the probability density function (PDF) and cumulative distribution functions (CDF) of the pointing error between an unstable transmitter (Tx) and receiver (Rx), that have different antenna patterns and for which the vibrations are not similar in the Yaw and Pitch directions. The special case where the Tx and Rx are both equipped with uniform linear array antenna is also investigated. In addition, using $\alpha-\mu$ distribution, which is a valid model for small-scale fading of mmWave/THz links, the end-to-end PDF and CDF of the considered channel is derived for all the considered cases. Finally, by employing Monte-Carlo simulations, the accuracy of the analytical expressions is verified and the performance of the system is studied.

Downlink Interference Analysis of UAV-based mmWave Fronthaul for Small Cell Networks

In this paper, an unmanned aerial vehicles (UAV)-based heterogeneous network is studied to solve the problem of transferring massive traffic of distributed small cells to the core network. First, a detailed three-dimensional (3D) model of the downlink channel is characterized by taking into account the real antenna pattern, UAVs' vibrations, random distribution of small cell base stations (SBSs), and the position of UAVs in 3D space. Then, a rigorous analysis of interference is performed for two types pf interference: intra-cell interference and inter-cell interference. The interference analysis results are then used to derive an upper bound of outage probability on the considered system. Using numerical results show that the analytical and simulation results match one another. The results show that, in the presence of UAV's fluctuations, optimizing radiation pattern shape requires balancing an inherent tradeoff between increasing pattern gain to reduce the interference as well as to compensate large path loss at mmWave frequencies and decreasing it to alleviate the adverse effect of a UAV's vibrations. The analytical derivations enable the derivation of the optimal antenna pattern for any condition in a short time instead of using time-consuming extensive simulations.

Pointing Error Modeling of mmWave to THz High-Directional Antennas

This paper focuses on providing an analytical framework for the quantification and evaluation of the pointing error at high-frequency millimeter wave (mmWave) and terahertz (THz) communication links. For this aim, we first characterize the channel of a point-to-point communication link between to unstable transmitter (Tx) and receiver (Rx) and then, we derive the probability density function (PDF) and cumulative distribution functions (CDF) of the pointing error in the presence of an unstable Tx and Rx as a function of the antennas' pattern. Specifically, for the standard array antenna, a closed-form expression is provided for PDF of the pointing error, which is a function of the number of antenna elements. Moreover, a more tractable approximate model is provided for the CDF and PDF of pointing error. In addition, using $\alpha-\mu$ distribution, which is a common model for small-scale fading of THz links, the end-to-end PDF of the considered channel is derived and used to calculate the outage probability of the considered system. Finally, by employing Monte-Carlo simulations, the accuracy of the analytical expressions is verified and the performance of the system is studied.

3D Uplink Channel Modeling of UAV-based mmWave Fronthaul Links for Future Small Cell Networks

In this study, we consider an unmanned aerial vehicle (UAV)-assisted heterogeneous network that is offered as a cost-effective and easy to deploy solution to solve the problem related to transferring traffic of distributed small cells to the core network. For any given distribution of small cell base stations (SBSs), we first characterize an accurate millimeter wave (mmWave) channel model for SBS to networked flying platform (NFP) by taking into consideration real parameters such as UAV's vibrations, distribution of SBSs, position of UAVs in the sky, real three-dimensional (3D) antenna pattern model provided by 3GPP along with interference caused by antenna side lobes and frequency reuse. Then, for the characterized channel, we derive an analytical closed-form expression for the end-to-end signal-to-noise plus interference ratio (SINR). Based on that, we derive the closed-form expressions for the outage probability and channel capacity of the considered UAV-based mmWave uplinks. The accuracy of the derived analytical expressions is verified by Monte Carlo simulations. Finally, we investigate the effects of different channel parameters such as antenna pattern gain, strength of UAV's vibrations, UAVs' positions in the sky, distribution of SBSs, and frequency reuse on the performance of the considered UAV-based uplink channel in terms of average capacity and outage probability.

Enabling Long mmWave Aerial Backhaul Links via Fixed-Wing UAVs: Performance and Design

We propose a fixed wing unmanned aerial vehicles (UAV)-based millimeter wave (mmWave) backhaul links, that is offered as a cost effective and easy to deploy solution, to connect a disaster or remote area to the nearest core network. First, we fully characterize the single relay fixed-wing UAV-based communication system by taking into account the effects of realistic physical parameters, such as the UAV's circular path, critical points of the flight path, heights and positions of obstacles, flight altitude, tracking error, the severity of UAV's vibrations, the real 3D antenna pattern, mmWave atmospheric channel loss, temperature and air pressure. Second, we derive the distribution of the signal-to-noise ratio (SNR) metric, which is based on the sum of a series of Dirac delta functions. Using the SNR distribution, we derive closed-form expressions for the outage probability and the ergodic capacity of the considered system as a function of all system parameters. To provide an acceptable quality of service for longer link lengths, we extend the analytical expressions to a multi-relay system. The accuracy of the closed-form expressions are verified by Monte-Carlo simulations. Finally, by providing sufficient simulation results, we investigate the effects of key channel parameters such as antenna pattern gain and flight path on the performance of the considered system; and we carefully analyze the relationships between these parameters in order to maximize the average channel capacity.

A Study of Multihop mmW Aerial Backhaul Links

The main contribution of this paper is to analyze a long networked flying platform (NFP)-based millimeter wave (mmWave) backhaul link that is offered as a cost effective and easy to deploy solution to connect a disaster or remote area to the nearest core network. For this aim, we characterize the backhaul channel as a function of realistic physical parameters such as heights and distances of obstacles along the route, flight altitude and the intensity of NFPs' vibrations, the real 3D antenna pattern provided by 3GPP, etc. For the characterized channel, we derive an analytical closed-form expression for the outage probability. Finally, using the obtained results, we provide a fast algorithm for the optimal parameter design of the considered system that minimizes the cost.

Long mmWave Backhaul Connectivity Using Fixed-Wing UAVs

This paper discusses the analysis of a fixed-wing unmanned aerial vehicle (UAV)-based millimeter wave (mmWave) backhaul link, that is offered as a cost-effective and easy deploy the solution to connect a disaster or remote area to the nearest core network. We present the optimal design of a relay system based on fixed-wing UAV, taking into account the actual channel parameters such as the UAV vibrations, tracking error, real 3GPP antenna pattern, UAV's height, flight path, and the effect of physical obstacles. The performance of the considered system is evaluated in terms of outage probability and the channel capacity while taking into account the impact of the system parameters such as optimal selection of UAV flight path and antenna patterns.
