Reconfigurable Intelligent Surface: Power Consumption Modeling and Practical Measurement Validation

Due to the ability to reshape the wireless communication environment in a cost- and energy-efficient manner, the reconfigurable intelligent surface (RIS) has garnered substantial attention. However, the explicit power consumption model of RIS and measurement validation, have received far too little attention. Therefore, in this work, we propose the RIS power consumption model and implement the practical measurement validation with various RISs. Measurement results illustrate the generality and accuracy of the proposed model. Firstly, we verify that RIS has static power consumption, and present the experiment results. Secondly, we confirm that the dynamic power consumption of the varactor-diode based RIS is almost negligible. Finally but significantly, we model the quantitative relationship between the dynamic power consumption of the PIN-diode based RIS and the polarization mode, controllable bit resolution, working status of RIS, which is validated by practical experimental results.

Design and Implementation of MIMO Transmission Based on Dual-Polarized Reconfigurable Intelligent Surface

Multiple-input multiple-output (MIMO) signaling is one of the key technologies of current mobile communication systems. However, the complex and expensive radio frequency (RF) chains have always limited the increase of MIMO scale. In this paper, we propose a MIMO transmission architecture based on a dual-polarized reconfigurable intelligent surface (RIS), which can directly achieve modulation and transmission of multichannel signals without the need for conventional RF chains. Compared with previous works, the proposed architecture can improve the integration of RIS-based transmission systems. A prototype of the dual-polarized RIS-based MIMO transmission system is built and the experimental results confirm the feasibility of the proposed architecture. The dual-polarized RIS-based MIMO transmission architecture provides a promising solution for realizing low-cost ultra-massive MIMO towards future networks.

Path Loss Modeling and Measurements for Reconfigurable Intelligent Surfaces in the Millimeter-Wave Frequency Band

Reconfigurable intelligent surfaces (RISs) provide an interface between the electromagnetic world of the wireless propagation environment and the digital world of information science. Simple yet sufficiently accurate path loss models for RISs are an important basis for theoretical analysis and optimization of RIS-assisted wireless communication systems. In this paper, we refine our previously proposed free-space path loss model for RISs to make it simpler, more applicable, and easier to use. In the proposed path loss model, the impact of the radiation patterns of the antennas and unit cells of the RIS is formulated in terms of an angle-dependent loss factor. The refined model gives more accurate estimates of the path loss of RISs comprised of unit cells with a deep sub-wavelength size. The free-space path loss model of the sub-channel provided by a single unit cell is also explicitly provided. In addition, two fabricated RISs, which are designed to operate in the millimeter-wave (mmWave) band, are utilized to carry out a measurement campaign in order to characterize and validate the proposed path loss model for RIS-assisted wireless communications. The measurement results corroborate the proposed analytical model. The proposed refined path loss model for RISs reveals that the reflecting capability of a single unit cell is proportional to its physical aperture and to an angle-dependent factor. In particular, the far-field beamforming gain provided by an RIS is mainly determined by the total area of the surface and by the angles of incidence and reflection.
