Autonomous Voltage Control for Grid Operation Using Deep Reinforcement Learning

Modern power grids are experiencing grand challenges caused by the stochastic and dynamic nature of growing renewable energy and demand response. Traditional theoretical assumptions and operational rules may be violated, which are difficult to be adapted by existing control systems due to the lack of computational power and accurate grid models for use in real time, leading to growing concerns in the secure and economic operation of the power grid. Existing operational control actions are typically determined offline, which are less optimized. This paper presents a novel paradigm, Grid Mind, for autonomous grid operational controls using deep reinforcement learning. The proposed AI agent for voltage control can learn its control policy through interactions with massive offline simulations, and adapts its behavior to new changes including not only load/generation variations but also topological changes. A properly trained agent is tested on the IEEE 14-bus system with tens of thousands of scenarios, and promising performance is demonstrated in applying autonomous voltage controls for secure grid operation.

Probabilistic Load Forecasting via Point Forecast Feature Integration

Short-term load forecasting is a critical element of power systems energy management systems. In recent years, probabilistic load forecasting (PLF) has gained increased attention for its ability to provide uncertainty information that helps to improve the reliability and economics of system operation performances. This paper proposes a two-stage probabilistic load forecasting framework by integrating point forecast as a key probabilistic forecasting feature into PLF. In the first stage, all related features are utilized to train a point forecast model and also obtain the feature importance. In the second stage the forecasting model is trained, taking into consideration point forecast features, as well as selected feature subsets. During the testing period of the forecast model, the final probabilistic load forecast results are leveraged to obtain both point forecasting and probabilistic forecasting. Numerical results obtained from ISO New England demand data demonstrate the effectiveness of the proposed approach in the hour-ahead load forecasting, which uses the gradient boosting regression for the point forecasting and quantile regression neural networks for the probabilistic forecasting.

Submodular Load Clustering with Robust Principal Component Analysis

Traditional load analysis is facing challenges with the new electricity usage patterns due to demand response as well as increasing deployment of distributed generations, including photovoltaics (PV), electric vehicles (EV), and energy storage systems (ESS). At the transmission system, despite of irregular load behaviors at different areas, highly aggregated load shapes still share similar characteristics. Load clustering is to discover such intrinsic patterns and provide useful information to other load applications, such as load forecasting and load modeling. This paper proposes an efficient submodular load clustering method for transmission-level load areas. Robust principal component analysis (R-PCA) firstly decomposes the annual load profiles into low-rank components and sparse components to extract key features. A novel submodular cluster center selection technique is then applied to determine the optimal cluster centers through constructed similarity graph. Following the selection results, load areas are efficiently assigned to different clusters for further load analysis and applications. Numerical results obtained from PJM load demonstrate the effectiveness of the proposed approach.

A Rprop-Neural-Network-Based PV Maximum Power Point Tracking Algorithm with Short-Circuit Current Limitation

This paper proposes a resilient-backpropagation-neural-network-(Rprop-NN) based algorithm for Photovoltaic (PV) maximum power point tracking (MPPT). A supervision mechanism is proposed to calibrate the Rprop-NN-MPPT reference and limit short-circuit current caused by incorrect prediction. Conventional MPPT algorithms (e.g., perturb and observe (P&O), hill climbing, and incremental conductance (Inc-Cond) etc.) are trial-and-error-based, which may result in steady-state oscillations and loss of tracking direction under fast-changing ambient environment. In addition, partial shading is also a challenge due to the difficulty of finding the global maximum power point on a multi-peak characteristic curve. As an attempt to address the aforementioned issues, a novel Rprop-NN MPPT algorithm is developed and elaborated in this work. Multiple case studies are carried out to verify the effectiveness of the proposed algorithm.

A Neuron-Network-Based Optimal Control of Ultra-Capacitors with System Uncertainties

In this paper, a neural-network (NN)-based online optimal control method (NN-OPT) is proposed for ultra-capacitors (UCs) energy storage system (ESS) in hybrid AC/DC microgrids involving multiple distributed generations (e.g., Photovoltaic (PV) system, battery storage, diesel generator). Conventional control strategies usually produce large disturbances to buses during charging and discharging (C&D) processes of UCs, which significantly degrades the power quality and system performance, especially under fast C&D modes. Therefore, the optimal control theory is adopted to optimize the C&D profile as well as to suppress the disturbances caused by UCs implementation. Specifically, an NN-based intelligent algorithm is developed to learn the optimal control policy for bidirectional-converter-interfaced UCs. The inaccuracies of system modeling are also considered in the control design. Since the designed NN-OPT method is decentralized that only requires the local measurements, plug & play of UCs can be easily realized with minimal communication efforts. In addition, the PV system is under the maximum power point tracking (MPPT) control to extract the maximum benefit. Both islanded and grid-tied modes are considered during the controller design. Extensive case studies have been conducted to evaluate the effectiveness of the proposed method.
