Design of a Flying Humanoid Robot Based on Thrust Vector Control

Achieving short-distance flight helps improve the efficiency of humanoid robots moving in complex environments (e.g., crossing large obstacles or reaching high places) for rapid emergency missions. This study proposes a design of a flying humanoid robot named Jet-HR2. The robot has 10 joints driven by brushless motors and harmonic drives for locomotion. To overcome the challenge of the stable-attitude takeoff in small thrust-to-weight conditions, the robot was designed based on the concept of thrust vectoring. The propulsion system consists of four ducted fans, that is, two fixed on the waist of the robot and the other two mounted on the feet, for thrust vector control. The thrust vector is controlled by adjusting the attitude of the foot during the flight. A simplified model and control strategies are proposed to solve the problem of attitude instability caused by mass errors and joint position errors during takeoff. The experimental results show that the robot's spin and dive behaviors during takeoff were effectively suppressed by controlling the thrust vector of the ducted fan on the foot. The robot successfully achieved takeoff at a thrust-to-weight ratio of 1.17 (17 kg / 20 kg) and maintained a stable attitude, reaching a takeoff height of over 1000 mm.

Integrating Combined Task and Motion Planning with Compliant Control

Planning a motion for inserting pegs remains an open problem. The difficulty lies in both the inevitable errors in the grasps of a robotic hand and absolute precision problems in robot joint motors. This paper proposes an integral method to solve the problem. The method uses combined task and motion planning to plan the grasps and motion for a dual-arm robot to pick up the objects and move them to assembly poses. Then, it controls the dual-arm robot using a compliant strategy (a combination of linear search, spiral search, and impedance control) to finish up the insertion. The method is implemented on a dual-arm Universal Robots 3 robot. Six objects, including a connector with fifteen peg-in-hole pairs for detailed analysis and other five objects with different contours of pegs and holes for additional validation, were tested by the robot. Experimental results show reasonable force-torque signal changes and end-effector position changes. The proposed method exhibits high robustness and high fidelity in successfully conducting planned peg-in-hole tasks.
