Anomaly Detection in Offshore Wind Turbine Structures using Hierarchical Bayesian Modelling

Population-based structural health monitoring (PBSHM), aims to share information between members of a population. An offshore wind (OW) farm could be considered as a population of nominally-identical wind-turbine structures. However, benign variations exist among members, such as geometry, sea-bed conditions and temperature differences. These factors could influence structural properties and therefore the dynamic response, making it more difficult to detect structural problems via traditional SHM techniques. This paper explores the use of a hierarchical Bayesian model to infer expected soil stiffness distributions at both population and local levels, as a basis to perform anomaly detection, in the form of scour, for new and existing turbines. To do this, observations of natural frequency will be generated as though they are from a small population of wind turbines. Differences between individual observations will be introduced by postulating distributions over the soil stiffness and measurement noise, as well as reducing soil depth (to represent scour), in the case of anomaly detection.

Population-based wind farm monitoring based on a spatial autoregressive approach

An important challenge faced by wind farm operators is to reduce operation and maintenance cost. Structural health monitoring provides a means of cost reduction through minimising unnecessary maintenance trips as well as prolonging turbine service life. Population-based structural health monitoring can further reduce the cost of health monitoring systems by implementing one system for multiple structures (i.e.~turbines). At the same time, shared data within a population of structures may improve the predictions of structural behaviour. To monitor turbine performance at a population/farm level, an important initial step is to construct a model that describes the behaviour of all turbines under normal conditions. This paper proposes a population-level model that explicitly captures the spatial and temporal correlations (between turbines) induced by the wake effect. The proposed model is a Gaussian process-based spatial autoregressive model, named here a GP-SPARX model. This approach is developed since (a) it reflects our physical understanding of the wake effect, and (b) it benefits from a stochastic data-based learner. A case study is provided to demonstrate the capability of the GP-SPARX model in capturing spatial and temporal variations as well as its potential applicability in a health monitoring system.

Towards a population-informed approach to the definition of data-driven models for structural dynamics

Machine learning has affected the way in which many phenomena for various domains are modelled, one of these domains being that of structural dynamics. However, because machine-learning algorithms are problem-specific, they often fail to perform efficiently in cases of data scarcity. To deal with such issues, combination of physics-based approaches and machine learning algorithms have been developed. Although such methods are effective, they also require the analyser's understanding of the underlying physics of the problem. The current work is aimed at motivating the use of models which learn such relationships from a population of phenomena, whose underlying physics are similar. The development of such models is motivated by the way that physics-based models, and more specifically finite element models, work. Such models are considered transferrable, explainable and trustworthy, attributes which are not trivially imposed or achieved for machine-learning models. For this reason, machine-learning approaches are less trusted by industry and often considered more difficult to form validated models. To achieve such data-driven models, a population-based scheme is followed here and two different machine-learning algorithms from the meta-learning domain are used. The two algorithms are the model-agnostic meta-learning (MAML) algorithm and the conditional neural processes (CNP) model. The algorithms seem to perform as intended and outperform a traditional machine-learning algorithm at approximating the quantities of interest. Moreover, they exhibit behaviour similar to traditional machine learning algorithms (e.g. neural networks or Gaussian processes), concerning their performance as a function of the available structures in the training population.

On the hierarchical Bayesian modelling of frequency response functions

Population-based structural health monitoring (PBSHM) aims to share valuable information among members of a population, such as normal- and damage-condition data, to improve inferences regarding the health states of the members. Even when the population is comprised of nominally-identical structures, benign variations among the members will exist as a result of slight differences in material properties, geometry, boundary conditions, or environmental effects (e.g., temperature changes). These discrepancies can affect modal properties and present as changes in the characteristics of the resonance peaks of the frequency response function (FRF). Many SHM strategies depend on monitoring the dynamic properties of structures, so benign variations can be challenging for the practical implementation of these systems. Another common challenge with vibration-based SHM is data loss, which may result from transmission issues, sensor failure, a sample-rate mismatch between sensors, and other causes. Missing data in the time domain will result in decreased resolution in the frequency domain, which can impair dynamic characterisation. The hierarchical Bayesian approach provides a useful modelling structure for PBSHM, because statistical distributions at the population and individual (or domain) level are learnt simultaneously to bolster statistical strength among the parameters. As a result, variance is reduced among the parameter estimates, particularly when data are limited. In this paper, combined probabilistic FRF models are developed for a small population of nominally-identical helicopter blades under varying temperature conditions, using a hierarchical Bayesian structure. These models address critical challenges in SHM, by accommodating benign variations that present as differences in the underlying dynamics, while also considering (and utilising), the similarities among the blades.

Better Together: Using Multi-task Learning to Improve Feature Selection within Structural Datasets

There have been recent efforts to move to population-based structural health monitoring (PBSHM) systems. One area of PBSHM which has been recognised for potential development is the use of multi-task learning (MTL); algorithms which differ from traditional independent learning algorithms. Presented here is the use of the MTL, ''Joint Feature Selection with LASSO'', to provide automatic feature selection for a structural dataset. The classification task is to differentiate between the port and starboard side of a tailplane, for samples from two aircraft of the same model. The independent learner produced perfect F1 scores but had poor engineering insight; whereas the MTL results were interpretable, highlighting structural differences as opposed to differences in experimental set-up.

A Meta-Learning Approach to Population-Based Modelling of Structures

A major problem of machine-learning approaches in structural dynamics is the frequent lack of structural data. Inspired by the recently-emerging field of population-based structural health monitoring (PBSHM), and the use of transfer learning in this novel field, the current work attempts to create models that are able to transfer knowledge within populations of structures. The approach followed here is meta-learning, which is developed with a view to creating neural network models which are able to exploit knowledge from a population of various tasks to perform well in newly-presented tasks, with minimal training and a small number of data samples from the new task. Essentially, the method attempts to perform transfer learning in an automatic manner within the population of tasks. For the purposes of population-based structural modelling, the different tasks refer to different structures. The method is applied here to a population of simulated structures with a view to predicting their responses as a function of some environmental parameters. The meta-learning approach, which is used herein is the model-agnostic meta-learning (MAML) approach; it is compared to a traditional data-driven modelling approach, that of Gaussian processes, which is a quite effective alternative when few data samples are available for a problem. It is observed that the models trained using meta-learning approaches, are able to outperform conventional machine learning methods regarding inference about structures of the population, for which only a small number of samples are available. Moreover, the models prove to learn part of the physics of the problem, making them more robust than plain machine-learning algorithms. Another advantage of the methods is that the structures do not need to be parametrised in order for the knowledge transfer to be performed.

On an Application of Generative Adversarial Networks on Remaining Lifetime Estimation

A major problem of structural health monitoring (SHM) has been the prognosis of damage and the definition of the remaining useful life of a structure. Both tasks depend on many parameters, many of which are often uncertain. Many models have been developed for the aforementioned tasks but they have been either deterministic or stochastic with the ability to take into account only a restricted amount of past states of the structure. In the current work, a generative model is proposed in order to make predictions about the damage evolution of structures. The model is able to perform in a population-based SHM (PBSHM) framework, to take into account many past states of the damaged structure, to incorporate uncertainties in the modelling process and to generate potential damage evolution outcomes according to data acquired from a structure. The algorithm is tested on a simulated damage evolution example and the results reveal that it is able to provide quite confident predictions about the remaining useful life of structures within a population.

On generative models as the basis for digital twins

A framework is proposed for generative models as a basis for digital twins or mirrors of structures. The proposal is based on the premise that deterministic models cannot account for the uncertainty present in most structural modelling applications. Two different types of generative models are considered here. The first is a physics-based model based on the stochastic finite element (SFE) method, which is widely used when modelling structures that have material and loading uncertainties imposed. Such models can be calibrated according to data from the structure and would be expected to outperform any other model if the modelling accurately captures the true underlying physics of the structure. The potential use of SFE models as digital mirrors is illustrated via application to a linear structure with stochastic material properties. For situations where the physical formulation of such models does not suffice, a data-driven framework is proposed, using machine learning and conditional generative adversarial networks (cGANs). The latter algorithm is used to learn the distribution of the quantity of interest in a structure with material nonlinearities and uncertainties. For the examples considered in this work, the data-driven cGANs model outperform the physics-based approach. Finally, an example is shown where the two methods are coupled such that a hybrid model approach is demonstrated.

On partitioning of an SHM problem and parallels with transfer learning

In the current work, a problem-splitting approach and a scheme motivated by transfer learning is applied to a structural health monitoring problem. The specific problem in this case is that of localising damage on an aircraft wing. The original experiment is described, together with the initial approach, in which a neural network was trained to localise damage. The results were not ideal, partly because of a scarcity of training data, and partly because of the difficulty in resolving two of the damage cases. In the current paper, the problem is split into two sub-problems and an increase in classification accuracy is obtained. The sub-problems are obtained by separating out the most difficult-to-classify damage cases. A second approach to the problem is considered by adopting ideas from transfer learning (usually applied in much deeper) networks to see if a network trained on the simpler damage cases can help with feature extraction in the more difficult cases. The transfer of a fixed trained batch of layers between the networks is found to improve classification by making the classes more separable in the feature space and to speed up convergence.

On an application of graph neural networks in population based SHM

Attempts have been made recently in the field of population-based structural health monitoring (PBSHM), to transfer knowledge between SHM models of different structures. The attempts have been focussed on homogeneous and heterogeneous populations. A more general approach to transferring knowledge between structures, is by considering all plausible structures as points on a multidimensional base manifold and building a fibre bundle. The idea is quite powerful, since, a mapping between points in the base manifold and their fibres, the potential states of any arbitrary structure, can be learnt. A smaller scale problem, but still useful, is that of learning a specific point of every fibre, i.e. that corresponding to the undamaged state of structures within a population. Under the framework of PBSHM, a data-driven approach to the aforementioned problem is developed. Structures are converted into graphs and inference is attempted within a population, using a graph neural network (GNN) algorithm. The algorithm solves a major problem existing in such applications. Structures comprise different sizes and are defined as abstract objects, thus attempting to perform inference within a heterogeneous population is not trivial. The proposed approach is tested in a simulated population of trusses. The goal of the application is to predict the first natural frequency of trusses of different sizes, across different environmental temperatures and having different bar member types. After training the GNN using part of the total population, it was tested on trusses that were not included in the training dataset. Results show that the accuracy of the regression is satisfactory even in structures with higher number of nodes and members than those used to train it.
