Mechanical Strength Prediction of Steel-Polypropylene Fiber-based High-Performance Concrete Using Hybrid Machine Learning Algorithms

This research develops and evaluates machine learning models to predict the mechanical properties of steel-polypropylene fiber-reinforced high-performance concrete (HPC). Three model families were investigated: Extra Trees with XGBoost (ET-XGB), Random Forest with LightGBM (RF-LGBM), and Transformer with XGBoost (Transformer-XGB). The target properties included compressive strength (CS), flexural strength (FS), and tensile strength (TS), based on an extensive dataset compiled from published experimental studies. Model training involved k-fold cross-validation, hyperparameter optimization, Shapley additive explanations (SHAP), and uncertainty analysis to ensure both robustness and interpretability. Among the tested approaches, the ET-XGB model achieved the highest overall accuracy, with testing R^2 values of 0.994 for CS, 0.944 for FS, and 0.978 for TS and exhibited lowest uncertainty for CS and TS (approximately 13-16% and 30.4%, respectively). The RF-LGBM model provided the most stable and reliable predictions for FS (R^2 0.977), yielding the lowest uncertainty for FS (approximately 5-33%). The Transformer-XGB model demonstrated strong predictive capability (R^2 0.978 for TS and 0.967 for FS) but consistently showed the highest uncertainty, indicating reduced generalization reliability. SHAP analysis further indicated that fiber aspect ratios (AR1 and AR2), silica fume (Sfu), and steel fiber content (SF) were the most influential predictors of strength, whereas water content (W) and the water-binder ratio (w/b) consistently had negative effects. The findings confirm that machine learning models can provide accurate, interpretable, and generalizable predictions of HPC mechanical properties. These models offer valuable tools for optimizing concrete mix design and enhancing structural performance evaluation in engineering applications.

A Data-Driven Multi-Objective Approach for Predicting Mechanical Performance, Flowability, and Porosity in Ultra-High-Performance Concrete (UHPC)

This study presents a data-driven, multi-objective approach to predict the mechanical performance, flow ability, and porosity of Ultra-High-Performance Concrete (UHPC). Out of 21 machine learning algorithms tested, five high-performing models are selected, with XGBoost showing the best accuracy after hyperparameter tuning using Random Search and K-Fold Cross-Validation. The framework follows a two-stage process: the initial XGBoost model is built using raw data, and once selected as the final model, the dataset is cleaned by (1) removing multicollinear features, (2) identifying outliers with Isolation Forest, and (3) selecting important features using SHAP analysis. The refined dataset as model 2 is then used to retrain XGBoost, which achieves high prediction accuracy across all outputs. A graphical user interface (GUI) is also developed to support material designers. Overall, the proposed framework significantly improves the prediction accuracy and minimizes the need for extensive experimental testing in UHPC mix design.

ChartKG: A Knowledge-Graph-Based Representation for Chart Images

Chart images, such as bar charts, pie charts, and line charts, are explosively produced due to the wide usage of data visualizations. Accordingly, knowledge mining from chart images is becoming increasingly important, which can benefit downstream tasks like chart retrieval and knowledge graph completion. However, existing methods for chart knowledge mining mainly focus on converting chart images into raw data and often ignore their visual encodings and semantic meanings, which can result in information loss for many downstream tasks. In this paper, we propose ChartKG, a novel knowledge graph (KG) based representation for chart images, which can model the visual elements in a chart image and semantic relations among them including visual encodings and visual insights in a unified manner. Further, we develop a general framework to convert chart images to the proposed KG-based representation. It integrates a series of image processing techniques to identify visual elements and relations, e.g., CNNs to classify charts, yolov5 and optical character recognition to parse charts, and rule-based methods to construct graphs. We present four cases to illustrate how our knowledge-graph-based representation can model the detailed visual elements and semantic relations in charts, and further demonstrate how our approach can benefit downstream applications such as semantic-aware chart retrieval and chart question answering. We also conduct quantitative evaluations to assess the two fundamental building blocks of our chart-to-KG framework, i.e., object recognition and optical character recognition. The results provide support for the usefulness and effectiveness of ChartKG.
