LLM-to-Phy3D: Physically Conform Online 3D Object Generation with LLMs

The emergence of generative artificial intelligence (GenAI) and large language models (LLMs) has revolutionized the landscape of digital content creation in different modalities. However, its potential use in Physical AI for engineering design, where the production of physically viable artifacts is paramount, remains vastly underexplored. The absence of physical knowledge in existing LLM-to-3D models often results in outputs detached from real-world physical constraints. To address this gap, we introduce LLM-to-Phy3D, a physically conform online 3D object generation that enables existing LLM-to-3D models to produce physically conforming 3D objects on the fly. LLM-to-Phy3D introduces a novel online black-box refinement loop that empowers large language models (LLMs) through synergistic visual and physics-based evaluations. By delivering directional feedback in an iterative refinement process, LLM-to-Phy3D actively drives the discovery of prompts that yield 3D artifacts with enhanced physical performance and greater geometric novelty relative to reference objects, marking a substantial contribution to AI-driven generative design. Systematic evaluations of LLM-to-Phy3D, supported by ablation studies in vehicle design optimization, reveal various LLM improvements gained by 4.5% to 106.7% in producing physically conform target domain 3D designs over conventional LLM-to-3D models. The encouraging results suggest the potential general use of LLM-to-Phy3D in Physical AI for scientific and engineering applications.

Controlled Agentic Planning & Reasoning for Mechanism Synthesis

This work presents a dual-agent Large Language Model (LLM)-based reasoning method for mechanism synthesis, capable of reasoning at both linguistic and symbolic levels to generate geometrical and dynamic outcomes. The model consists of a composition of well-defined functions that, starting from a natural language specification, references abstract properties through supporting equations, generates and parametrizes simulation code, and elicits feedback anchor points using symbolic regression and distance functions. This process closes an actionable refinement loop at the linguistic and symbolic layers. The approach is shown to be both effective and convergent in the context of planar mechanisms. Additionally, we introduce MSynth, a novel benchmark for planar mechanism synthesis, and perform a comprehensive analysis of the impact of the model components. We further demonstrate that symbolic regression prompts unlock mechanistic insights only when applied to sufficiently large architectures.

From Idea to CAD: A Language Model-Driven Multi-Agent System for Collaborative Design

Creating digital models using Computer Aided Design (CAD) is a process that requires in-depth expertise. In industrial product development, this process typically involves entire teams of engineers, spanning requirements engineering, CAD itself, and quality assurance. We present an approach that mirrors this team structure with a Vision Language Model (VLM)-based Multi Agent System, with access to parametric CAD tooling and tool documentation. Combining agents for requirements engineering, CAD engineering, and vision-based quality assurance, a model is generated automatically from sketches and/ or textual descriptions. The resulting model can be refined collaboratively in an iterative validation loop with the user. Our approach has the potential to increase the effectiveness of design processes, both for industry experts and for hobbyists who create models for 3D printing. We demonstrate the potential of the architecture at the example of various design tasks and provide several ablations that show the benefits of the architecture's individual components.

LLM2FEA: Discover Novel Designs with Generative Evolutionary Multitasking

The rapid research and development of generative artificial intelligence has enabled the generation of high-quality images, text, and 3D models from text prompts. This advancement impels an inquiry into whether these models can be leveraged to create digital artifacts for both creative and engineering applications. Drawing on innovative designs from other domains may be one answer to this question, much like the historical practice of ``bionics", where humans have sought inspiration from nature's exemplary designs. This raises the intriguing possibility of using generative models to simultaneously tackle design tasks across multiple domains, facilitating cross-domain learning and resulting in a series of innovative design solutions. In this paper, we propose LLM2FEA as the first attempt to discover novel designs in generative models by transferring knowledge across multiple domains. By utilizing a multi-factorial evolutionary algorithm (MFEA) to drive a large language model, LLM2FEA integrates knowledge from various fields to generate prompts that guide the generative model in discovering novel and practical objects. Experimental results in the context of 3D aerodynamic design verify the discovery capabilities of the proposed LLM2FEA. The designs generated by LLM2FEA not only satisfy practicality requirements to a certain degree but also feature novel and aesthetically pleasing shapes, demonstrating the potential applications of LLM2FEA in discovery tasks.

Generative AI-based Prompt Evolution Engineering Design Optimization With Vision-Language Model

Engineering design optimization requires an efficient combination of a 3D shape representation, an optimization algorithm, and a design performance evaluation method, which is often computationally expensive. We present a prompt evolution design optimization (PEDO) framework contextualized in a vehicle design scenario that leverages a vision-language model for penalizing impractical car designs synthesized by a generative model. The backbone of our framework is an evolutionary strategy coupled with an optimization objective function that comprises a physics-based solver and a vision-language model for practical or functional guidance in the generated car designs. In the prompt evolutionary search, the optimizer iteratively generates a population of text prompts, which embed user specifications on the aerodynamic performance and visual preferences of the 3D car designs. Then, in addition to the computational fluid dynamics simulations, the pre-trained vision-language model is used to penalize impractical designs and, thus, foster the evolutionary algorithm to seek more viable designs. Our investigations on a car design optimization problem show a wide spread of potential car designs generated at the early phase of the search, which indicates a good diversity of designs in the initial populations, and an increase of over 20\% in the probability of generating practical designs compared to a baseline framework without using a vision-language model. Visual inspection of the designs against the performance results demonstrates prompt evolution as a very promising paradigm for finding novel designs with good optimization performance while providing ease of use in specifying design specifications and preferences via a natural language interface.

Large Language and Text-to-3D Models for Engineering Design Optimization

The current advances in generative AI for learning large neural network models with the capability to produce essays, images, music and even 3D assets from text prompts create opportunities for a manifold of disciplines. In the present paper, we study the potential of deep text-to-3D models in the engineering domain, with focus on the chances and challenges when integrating and interacting with 3D assets in computational simulation-based design optimization. In contrast to traditional design optimization of 3D geometries that often searches for the optimum designs using numerical representations, such as B-Spline surface or deformation parameters in vehicle aerodynamic optimization, natural language challenges the optimization framework by requiring a different interpretation of variation operators while at the same time may ease and motivate the human user interaction. Here, we propose and realize a fully automated evolutionary design optimization framework using Shap-E, a recently published text-to-3D asset network by OpenAI, in the context of aerodynamic vehicle optimization. For representing text prompts in the evolutionary optimization, we evaluate (a) a bag-of-words approach based on prompt templates and Wordnet samples, and (b) a tokenisation approach based on prompt templates and the byte pair encoding method from GPT4. Our main findings from the optimizations indicate that, first, it is important to ensure that the designs generated from prompts are within the object class of application, i.e. diverse and novel designs need to be realistic, and, second, that more research is required to develop methods where the strength of text prompt variations and the resulting variations of the 3D designs share causal relations to some degree to improve the optimization.
