Learning Wireless Data Knowledge Graph for Green Intelligent Communications: Methodology and Experiments

Intelligent communications have played a pivotal role in shaping the evolution of 6G networks. Native artificial intelligence (AI) within green communication systems must meet stringent real-time requirements. To achieve this, deploying lightweight and resource-efficient AI models is necessary. However, as wireless networks generate a multitude of data fields and indicators during operation, only a fraction of them imposes significant impact on the network AI models. Therefore, real-time intelligence of communication systems heavily relies on a small but critical set of the data that profoundly influences the performance of network AI models. These challenges underscore the need for innovative architectures and solutions. In this paper, we propose a solution, termed the pervasive multi-level (PML) native AI architecture, which integrates the concept of knowledge graph (KG) into the intelligent operational manipulations of mobile networks, resulting in the establishment of a wireless data KG. Leveraging the wireless data KG, we characterize the massive and complex data collected from wireless communication networks and analyze the relationships among various data fields. The obtained graph of data field relations enables the on-demand generation of minimal and effective datasets, referred to as feature datasets, tailored to specific application requirements. Consequently, this architecture not only enhances AI training, inference, and validation processes but also significantly reduces resource wastage and overhead for communication networks. To implement this architecture, we have developed a specific solution comprising a spatio-temporal heterogeneous graph attention neural network model (STREAM) as well as a feature dataset generation algorithm. Experiments are conducted to validate the effectiveness of the proposed architecture.

An NLoS-based Enhanced Sensing Method for MmWave Communication System

The millimeter-wave (mmWave)-based Wi-Fi sensing technology has recently attracted extensive attention since it provides a possibility to realize higher sensing accuracy. However, current works mainly concentrate on sensing scenarios where the line-of-sight (LoS) path exists, which significantly limits their applications. To address the problem, we propose an enhanced mmWave sensing algorithm in the 3D non-line-of-sight environment (mm3NLoS), aiming to sense the direction and distance of the target when the LoS path is weak or blocked. Specifically, we first adopt the directional beam to estimate the azimuth/elevation angle of arrival (AoA) and angle of departure (AoD) of the reflection path. Then, the distance of the related path is measured by the fine timing measurement protocol. Finally, we transform the AoA and AoD of the multiple non-line-of-sight (NLoS) paths into the direction vector and then obtain the information of targets based on the geometric relationship. The simulation results demonstrate that mm3NLoS can achieve a centimeter-level error with a 2m spacing. Compared to the prior work, it can significantly reduce the performance degradation under the NLoS condition.

Representation Learning of Knowledge Graph for Wireless Communication Networks

With the application of the fifth-generation wireless communication technologies, more smart terminals are being used and generating huge amounts of data, which has prompted extensive research on how to handle and utilize these wireless data. Researchers currently focus on the research on the upper-layer application data or studying the intelligent transmission methods concerning a specific problem based on a large amount of data generated by the Monte Carlo simulations. This article aims to understand the endogenous relationship of wireless data by constructing a knowledge graph according to the wireless communication protocols, and domain expert knowledge and further investigating the wireless endogenous intelligence. We firstly construct a knowledge graph of the endogenous factors of wireless core network data collected via a 5G/B5G testing network. Then, a novel model based on graph convolutional neural networks is designed to learn the representation of the graph, which is used to classify graph nodes and simulate the relation prediction. The proposed model realizes the automatic nodes classification and network anomaly cause tracing. It is also applied to the public datasets in an unsupervised manner. Finally, the results show that the classification accuracy of the proposed model is better than the existing unsupervised graph neural network models, such as VGAE and ARVGE.

Maximizing the Set Cardinality of Users Scheduled for Ultra-dense uRLLC Networks

Ultra-reliability and low latency communication plays an important role in the fifth and sixth generation communication systems. Among the different research issues, scheduling as many users as possible to serve on the limited time-frequency resource is a crucial topic, with requirement of the maximum allowable transmission power and the minimum rate requirement of each user.We address it by proposing a mixed integer programming model, with objective function is maximizing the set cardinality of users instead of maximizing the system sum rate. Mathematical transformations and successive convex approximation are combined to solve the problem. Numerical results show that the proposed method achieves a considerable performance compared with exhaustive search method, but with lower computational complexity.
