WAIR-D: Wireless AI Research Dataset

It is a common sense that datasets with high-quality data samples play an important role in artificial intelligence (AI), machine learning (ML) and related studies. However, although AI/ML has been introduced in wireless researches long time ago, few datasets are commonly used in the research community. Without a common dataset, AI-based methods proposed for wireless systems are hard to compare with both the traditional baselines and even each other. The existing wireless AI researches usually rely on datasets generated based on statistical models or ray-tracing simulations with limited environments. The statistical data hinder the trained AI models from further fine-tuning for a specific scenario, and ray-tracing data with limited environments lower down the generalization capability of the trained AI models. In this paper, we present the Wireless AI Research Dataset (WAIR-D)1, which consists of two scenarios. Scenario 1 contains 10,000 environments with sparsely dropped user equipments (UEs), and Scenario 2 contains 100 environments with densely dropped UEs. The environments are randomly picked up from more than 40 cities in the real world map. The large volume of the data guarantees that the trained AI models enjoy good generalization capability, while fine-tuning can be easily carried out on a specific chosen environment. Moreover, both the wireless channels and the corresponding environmental information are provided in WAIR-D, so that extra-information-aided communication mechanism can be designed and evaluated. WAIR-D provides the researchers benchmarks to compare their different designs or reproduce results of others. In this paper, we show the detailed construction of this dataset and examples of using it.

Learning to Flip Successive Cancellation Decoding of Polar Codes with LSTM Networks

The key to successive cancellation (SC) flip decoding of polar codes is to accurately identify the first error bit. The optimal flipping strategy is considered difficult due to lack of an analytical solution. Alternatively, we propose a deep learning aided SC flip algorithm. Specifically, before each SC decoding attempt, a long short-term memory (LSTM) network is exploited to either (i) locate the first error bit, or (ii) undo a previous `wrong' flip. In each SC attempt, the sequence of log likelihood ratios (LLRs) derived in the previous SC attempt is exploited to decide which action to take. Accordingly, a two-stage training method of the LSTM network is proposed, i.e., learn to locate first error bits in the first stage, and then to undo `wrong' flips in the second stage. Simulation results show that the proposed approach identifies error bits more accurately and achieves better performance than the state-of-the-art SC flip algorithms.
