Towards MR-Based Trochleoplasty Planning

To treat Trochlear Dysplasia (TD), current approaches rely mainly on low-resolution clinical Magnetic Resonance (MR) scans and surgical intuition. The surgeries are planned based on surgeons experience, have limited adoption of minimally invasive techniques, and lead to inconsistent outcomes. We propose a pipeline that generates super-resolved, patient-specific 3D pseudo-healthy target morphologies from conventional clinical MR scans. First, we compute an isotropic super-resolved MR volume using an Implicit Neural Representation (INR). Next, we segment femur, tibia, patella, and fibula with a multi-label custom-trained network. Finally, we train a Wavelet Diffusion Model (WDM) to generate pseudo-healthy target morphologies of the trochlear region. In contrast to prior work producing pseudo-healthy low-resolution 3D MR images, our approach enables the generation of sub-millimeter resolved 3D shapes compatible for pre- and intraoperative use. These can serve as preoperative blueprints for reshaping the femoral groove while preserving the native patella articulation. Furthermore, and in contrast to other work, we do not require a CT for our pipeline - reducing the amount of radiation. We evaluated our approach on 25 TD patients and could show that our target morphologies significantly improve the sulcus angle (SA) and trochlear groove depth (TGD). The code and interactive visualization are available at https://wehrlimi.github.io/sr-3d-planning/.

cIDIR: Conditioned Implicit Neural Representation for Regularized Deformable Image Registration

Regularization is essential in deformable image registration (DIR) to ensure that the estimated Deformation Vector Field (DVF) remains smooth, physically plausible, and anatomically consistent. However, fine-tuning regularization parameters in learning-based DIR frameworks is computationally expensive, often requiring multiple training iterations. To address this, we propose cIDI, a novel DIR framework based on Implicit Neural Representations (INRs) that conditions the registration process on regularization hyperparameters. Unlike conventional methods that require retraining for each regularization hyperparameter setting, cIDIR is trained over a prior distribution of these hyperparameters, then optimized over the regularization hyperparameters by using the segmentations masks as an observation. Additionally, cIDIR models a continuous and differentiable DVF, enabling seamless integration of advanced regularization techniques via automatic differentiation. Evaluated on the DIR-LAB dataset, $\operatorname{cIDIR}$ achieves high accuracy and robustness across the dataset.

Towards Real-time Intrahepatic Vessel Identification in Intraoperative Ultrasound-Guided Liver Surgery

While laparoscopic liver resection is less prone to complications and maintains patient outcomes compared to traditional open surgery, its complexity hinders widespread adoption due to challenges in representing the liver's internal structure. Laparoscopic intraoperative ultrasound offers efficient, cost-effective and radiation-free guidance. Our objective is to aid physicians in identifying internal liver structures using laparoscopic intraoperative ultrasound. We propose a patient-specific approach using preoperative 3D ultrasound liver volume to train a deep learning model for real-time identification of portal tree and branch structures. Our personalized AI model, validated on ex vivo swine livers, achieved superior precision (0.95) and recall (0.93) compared to surgeons, laying groundwork for precise vessel identification in ultrasound-based liver resection. Its adaptability and potential clinical impact promise to advance surgical interventions and improve patient care.
