PU-GCN: Point Cloud Upsampling using Graph Convolutional Networks

Upsampling sparse, noisy, and non-uniform point clouds is a challenging task. In this paper, we propose 3 novel point upsampling modules: Multi-branch GCN, Clone GCN, and NodeShuffle. Our modules use Graph Convolutional Networks (GCNs) to better encode local point information. Our upsampling modules are versatile and can be incorporated into any point cloud upsampling pipeline. We show how our 3 modules consistently improve state-of-the-art methods in all point upsampling metrics. We also propose a new multi-scale point feature extractor, called Inception DenseGCN. We modify current Inception GCN algorithms by introducing DenseGCN blocks. By aggregating data at multiple scales, our new feature extractor is more resilient to density changes along point cloud surfaces. We combine Inception DenseGCN with one of our upsampling modules (NodeShuffle) into a new point upsampling pipeline: PU-GCN. We show both qualitatively and quantitatively the advantages of PU-GCN against the state-of-the-art in terms of fine-grained upsampling quality and point cloud uniformity. The website and source code of this work is available at https://sites.google.com/kaust.edu.sa/pugcn and https://github.com/guochengqian/PU-GCN respectively.

DeepGCNs: Making GCNs Go as Deep as CNNs

Convolutional Neural Networks (CNNs) have been very successful at solving a variety of computer vision tasks such as object classification and detection, semantic segmentation, activity understanding, to name just a few. One key enabling factor for their great performance has been the ability to train very deep CNNs. Despite their huge success in many tasks, CNNs do not work well with non-Euclidean data which is prevalent in many real-world applications. Graph Convolutional Networks (GCNs) offer an alternative that allows for non-Eucledian data as input to a neural network similar to CNNs. While GCNs already achieve encouraging results, they are currently limited to shallow architectures with 2-4 layers due to vanishing gradients during training. This work transfers concepts such as residual/dense connections and dilated convolutions from CNNs to GCNs in order to successfully train very deep GCNs. We show the benefit of deep GCNs with as many as 112 layers experimentally across various datasets and tasks. Specifically, we achieve state-of-the-art performance in part segmentation and semantic segmentation on point clouds and in node classification of protein functions across biological protein-protein interaction (PPI) graphs. We believe that the insights in this work will open a lot of avenues for future research on GCNs and transfer to further tasks not explored in this work. The source code for this work is available for Pytorch and Tensorflow at https://github.com/lightaime/deep_gcns_torch and https://github.com/lightaime/deep_gcns respectively.
