A convolutional neural network for prestack fracture detection

Jul 03, 2021
Zhenyu Yuan, Yuxin Jiang, Jingjing Li, Handong Huang

Figure 1 for A convolutional neural network for prestack fracture detection
Figure 2 for A convolutional neural network for prestack fracture detection
Figure 3 for A convolutional neural network for prestack fracture detection
Figure 4 for A convolutional neural network for prestack fracture detection

Fractures are widely developed in hydrocarbon reservoirs and constitute the accumulation spaces and transport channels of oil and gas. Fracture detection is a fundamental task for reservoir characterization. From prestack seismic gathers, anisotropic analysis and inversion were commonly applied to characterize the dominant orientations and relative intensities of fractures. However, the existing methods were mostly based on the vertical aligned facture hypothesis, it is impossible for them to recognize fracture dip. Furthermore, it is difficult or impractical for existing methods to attain the real fracture densities. Based on data-driven deep learning, this paper designed a convolutional neural network to perform prestack fracture detection. Capitalizing on the connections between seismic responses and fracture parameters, a suitable azimuth dataset was firstly generated through fracture effective medium modeling and anisotropic plane wave analyzing. Then a multi-input and multi-output convolutional neural network was constructed to simultaneously detect fracture density, dip and strike azimuth. The application on a practical survey validated the effectiveness of the proposed CNN model.

Viaarxiv icon

Hybrid-DNNs: Hybrid Deep Neural Networks for Mixed Inputs

May 18, 2020
Zhenyu Yuan, Yuxin Jiang, Jingjing Li, Handong Huang

Figure 1 for Hybrid-DNNs: Hybrid Deep Neural Networks for Mixed Inputs
Figure 2 for Hybrid-DNNs: Hybrid Deep Neural Networks for Mixed Inputs
Figure 3 for Hybrid-DNNs: Hybrid Deep Neural Networks for Mixed Inputs
Figure 4 for Hybrid-DNNs: Hybrid Deep Neural Networks for Mixed Inputs

Rapid development of big data and high-performance computing have encouraged explosive studies of deep learning in geoscience. However, most studies only take single-type data as input, frittering away invaluable multisource, multi-scale information. We develop a general architecture of hybrid deep neural networks (HDNNs) to support mixed inputs. Regarding as a combination of feature learning and target learning, the new proposed networks provide great capacity in high-hierarchy feature extraction and in-depth data mining. Furthermore, the hybrid architecture is an aggregation of multiple networks, demonstrating good flexibility and wide applicability. The configuration of multiple networks depends on application tasks and varies with inputs and targets. Concentrating on reservoir production prediction, a specific HDNN model is configured and applied to an oil development block. Considering their contributions to hydrocarbon production, core photos, logging images and curves, geologic and engineering parameters can all be taken as inputs. After preprocessing, the mixed inputs are prepared as regular-sampled structural and numerical data. For feature learning, convolutional neural networks (CNN) and multilayer perceptron (MLP) network are configured to separately process structural and numerical inputs. Learned features are then concatenated and fed to subsequent networks for target learning. Comparison with typical MLP model and CNN model highlights the superiority of proposed HDNN model with high accuracy and good generalization.
