Prototyping and real-world field trials of RIS-aided wireless communications

Reconfigurable intelligent surface (RIS) is a promising technology that has the potential to change the way we interact with the wireless propagating environment. In this paper, we design and fabricate an RIS system that can be used in the fifth generation (5G) mobile communication networks. We also propose a practical two-step spatial-oversampling codebook algorithm for the beamforming of RIS, which is based on the spatial structure of the wireless channel. This algorithm has much lower complexity compared to the two-dimensional full-space searching-based codebook, yet with only negligible performance loss. Then, a series of experiments are conducted with the fabricated RIS systems, covering the office, corridor, and outdoor environments, in order to verified the effectiveness of RIS in both laboratory and current 5G commercial networks. In the office and corridor scenarios, the 5.8 GHz RIS provided a 10-20 dB power gain at the receiver. In the outdoor test, over 35 dB power gain was observed with RIS compared to the non-deployment case. However, in commercial 5G networks, the 2.6 GHz RIS improved indoor signal strength by only 4-7 dB. The experimental results indicate that RIS achieves higher power gain when transceivers are equipped with directional antennas instead of omni-directional antennas.

RIS with insufficient phase shifting capability: Modeling, beamforming, and experimental validations

Most research works on reconfigurable intelligent surfaces (RIS) rely on idealized model of the reflection coefficients, i.e., uniform reflection amplitude for any phases and sufficient phase shifting capability. In practice however, such models are oversimplified. This paper introduces a realistic reflection coefficient model for RIS based on measurements. The reflection coefficients are modeled as discrete complex values that have non-uniform amplitudes and suffer from insufficient phase shift capability. We then propose a group-based query algorithm that takes the imperfect coefficients into consideration while calculating the reflection coefficients. We analyze the performance of the proposed algorithm, and derive the closed-form expressions to characterize the received power of an RIS-aided wireless communication system. The performance gains of the proposed algorithm are confirmed in simulations. Furthermore, we validate the proposed theoretical results by experiments with our fabricated RIS prototype systems. The simulation and measurement results match well with the theoretical analysis.

RIS-aided Wireless Communications: Can RIS Beat Metal Plate?

Reconfigurable Intelligent Surface (RIS) has recently been regarded as a paradigm-shifting technology beyond 5G, for its flexibility on smartly adjusting the response to the impinging electromagnetic (EM) waves. Usually, RIS can be implemented by properly reconfiguring the adjustable parameters of each RIS unit to align the signal phase on the receiver side. And it is believed that the phase alignment can be also mechanically achieved by a metal plate with the same physical size. However, we found in the prototype experiments that, a well-rotated metal plate can only approximately perform as well as RIS under limited conditions, although its scattering efficiency is relatively higher. When it comes to the case of spherical wave impinging, RIS outperforms the metal plate even beyond the receiving near-field regions. We analyze this phenomenon with wave optics theory and propose explicit scattering models for both the metal plate and RIS in general scenarios. Finally, the models are validated by simulations and field measurements.

A Received Power Model for Reconfigurable Intelligent Surface and Measurement-based Validations

The idea of using a Reconfigurable Intelligent Surface (RIS) consisting of a large array of passive scattering elements to assist wireless communication systems has recently attracted much attention from academia and industry. A central issue with RIS is how much power they can effectively convey to the target radio nodes. Regarding this question, several power level models exist in the literature but few have been validated through experiments. In this paper, we propose a radar cross section-based received power model for an RIS-aided wireless communication system that is rooted in the physical properties of RIS. Our proposed model follows the intuition that the received power is related to the distances from the transmitter/receiver to the RIS, the angles in the TX-RIS-RX triangle, the effective area of each element, and the reflection coefficient of each element. To the best of our knowledge, this paper is the first to model the angle-dependent phase shift of the reflection coefficient, which is typically ignored in existing literature. We further measure the received power with our experimental platform in different scenarios to validate our model. The measurement results show that our model is appropriate both in near field and far field and can characterize the impact of angles well.
