Learning Dynamic Swing-Up of an Inverted Pendulum using Remote Magnetic Actuation

Electromagnetic Navigation Systems (eMNS) have gained considerable attention for minimally invasive surgery and targeted drug delivery. While most of the literature relies on quasi-static control of these systems, recent work has demonstrated the benefits of dynamic approaches. However, trajectory tracking far from equilibrium states remains largely unaddressed. We close this gap by demonstrating the first swing-up of a magnetically actuated inverted pendulum using the clinically-ready Navion eMNS. Although the inverted pendulum is not clinically relevant in itself, the proposed method utilizes torques and forces as control objectives, making it applicable to other magnetically actuated devices such as catheters and guidewires. Our approach combines trajectory optimization that accounts for internal eMNS dynamics with time-varying Linear Quadratic Regulator (LQR) state feedback and Iterative Learning Control (ILC), which leverages previous trial data and the system's dynamic model to progressively refine the feedforward command. While LQR alone fails due to the complex phenomena of magnetic actuation, ILC enables successful swing-up within six iterations. Furthermore, post-experimental analysis reveals that the learned ILC correction closely matches the torque discrepancy predicted by high-fidelity magnetic field model calibration, suggesting learning and adaptation as a promising tool to deal with uncertainties in electromagnetic actuation arising, e.g., from patient-specific physiological motion patterns and field model calibration inaccuracies.

Advancing Minimally Invasive Precision Surgery in Open Cavities with Robotic Flexible Endoscopy

Flexible robots hold great promise for enhancing minimally invasive surgery (MIS) by providing superior dexterity, precise control, and safe tissue interaction. Yet, translating these advantages into endoscopic interventions within open cavities remains challenging. The lack of anatomical constraints and the inherent flexibility of such devices complicate their control, while the limited field of view of endoscopes restricts situational awareness. We present a robotic platform designed to overcome these challenges and demonstrate its potential in fetoscopic laser coagulation, a complex MIS procedure typically performed only by highly experienced surgeons. Our system combines a magnetically actuated flexible endoscope with teleoperated and semi-autonomous navigation capabilities for performing targeted laser ablations. To enhance surgical awareness, the platform reconstructs real-time mosaics of the endoscopic scene, providing an extended and continuous visual context. The ability of this system to address the key limitations of MIS in open spaces is validated in vivo in an ovine model.

Clinically Ready Magnetic Microrobots for Targeted Therapies

Systemic drug administration often causes off-target effects limiting the efficacy of advanced therapies. Targeted drug delivery approaches increase local drug concentrations at the diseased site while minimizing systemic drug exposure. We present a magnetically guided microrobotic drug delivery system capable of precise navigation under physiological conditions. This platform integrates a clinical electromagnetic navigation system, a custom-designed release catheter, and a dissolvable capsule for accurate therapeutic delivery. In vitro tests showed precise navigation in human vasculature models, and in vivo experiments confirmed tracking under fluoroscopy and successful navigation in large animal models. The microrobot balances magnetic material concentration, contrast agent loading, and therapeutic drug capacity, enabling effective hosting of therapeutics despite the integration complexity of its components, offering a promising solution for precise targeted drug delivery.

Modeling Electromagnetic Navigation Systems for Medical Applications using Random Forests and Artificial Neural Networks

Electromagnetic Navigation Systems (eMNS) can be used to control a variety of multiscale devices within the human body for remote surgery. Accurate modeling of the magnetic fields generated by the electromagnets of an eMNS is crucial for the precise control of these devices. Existing methods assume a linear behavior of these systems, leading to significant modeling errors within nonlinear regions exhibited at higher magnetic fields. In this paper, we use a random forest (RF) and an artificial neural network (ANN) to model the nonlinear behavior of the magnetic fields generated by an eMNS. Both machine learning methods outperformed the state-of-the-art linear multipole electromagnet method (LMEM). The RF and the ANN model reduced the root mean squared error of the LMEM when predicting the field magnitude by around 40% and 80%, respectively, over the entire current range of the eMNS. At high current regions, especially between 30 and 35 A, the field-magnitude RMSE improvement of the ANN model over the LMEM was over 35 mT. This study demonstrates the feasibility of using machine learning methods to model an eMNS for medical applications, and its ability to account for complex nonlinear behavior at high currents. The use of machine learning thus shows promise for improving surgical procedures that use magnetic navigation.
