This paper introduces a groundbreaking digital neuromorphic architecture that innovatively integrates Brain Code Unit (BCU) and Fundamental Code Unit (FCU) using mixedsignal design methodologies. Leveraging open-source datasets and the latest advances in materials science, our research focuses on enhancing the computational efficiency, accuracy, and adaptability of neuromorphic systems. The core of our approach lies in harmonizing the precision and scalability of digital systems with the robustness and energy efficiency of analog processing. Through experimentation, we demonstrate the effectiveness of our system across various metrics. The BCU achieved an accuracy of 88.0% and a power efficiency of 20.0 GOP/s/W, while the FCU recorded an accuracy of 86.5% and a power efficiency of 18.5 GOP/s/W. Our mixed-signal design approach significantly improved latency and throughput, achieving a latency as low as 0.75 ms and throughput up to 213 TOP/s. These results firmly establish the potential of our architecture in neuromorphic computing, providing a solid foundation for future developments in this domain. Our study underscores the feasibility of mixedsignal neuromorphic systems and their promise in advancing the field, particularly in applications requiring high efficiency and adaptability
Neuromorphic systems, inspired by the complexity and functionality of the human brain, have gained interest in academic and industrial attention due to their unparalleled potential across a wide range of applications. While their capabilities herald innovation, it is imperative to underscore that these computational paradigms, analogous to their traditional counterparts, are not impervious to security threats. Although the exploration of neuromorphic methodologies for image and video processing has been rigorously pursued, the realm of neuromorphic audio processing remains in its early stages. Our results highlight the robustness and precision of our FPGA-based neuromorphic system. Specifically, our system showcases a commendable balance between desired signal and background noise, efficient spike rate encoding, and unparalleled resilience against adversarial attacks such as FGSM and PGD. A standout feature of our framework is its detection rate of 94%, which, when compared to other methodologies, underscores its greater capability in identifying and mitigating threats within 5.39 dB, a commendable SNR ratio. Furthermore, neuromorphic computing and hardware security serve many sensor domains in mission-critical and privacy-preserving applications.
This paper presents a novel approach to neuromorphic audio processing by integrating the strengths of Spiking Neural Networks (SNNs), Transformers, and high-performance computing (HPC) into the HPCNeuroNet architecture. Utilizing the Intel N-DNS dataset, we demonstrate the system's capability to process diverse human vocal recordings across multiple languages and noise backgrounds. The core of our approach lies in the fusion of the temporal dynamics of SNNs with the attention mechanisms of Transformers, enabling the model to capture intricate audio patterns and relationships. Our architecture, HPCNeuroNet, employs the Short-Time Fourier Transform (STFT) for time-frequency representation, Transformer embeddings for dense vector generation, and SNN encoding/decoding mechanisms for spike train conversions. The system's performance is further enhanced by leveraging the computational capabilities of NVIDIA's GeForce RTX 3060 GPU and Intel's Core i9 12900H CPU. Additionally, we introduce a hardware implementation on the Xilinx VU37P HBM FPGA platform, optimizing for energy efficiency and real-time processing. The proposed accelerator achieves a throughput of 71.11 Giga-Operations Per Second (GOP/s) with a 3.55 W on-chip power consumption at 100 MHz. The comparison results with off-the-shelf devices and recent state-of-the-art implementations illustrate that the proposed accelerator has obvious advantages in terms of energy efficiency and design flexibility. Through design-space exploration, we provide insights into optimizing core capacities for audio tasks. Our findings underscore the transformative potential of integrating SNNs, Transformers, and HPC for neuromorphic audio processing, setting a new benchmark for future research and applications.
This research delves into sophisticated neural network frameworks like Convolutional Neural Networks (CNN), Recurrent Neural Networks (RNN), Long Short-Term Memory Networks (LSTMs), and Deep Belief Networks (DBNs) for improved analysis of ECG signals via Field Programmable Gate Arrays (FPGAs). The MIT-BIH Arrhythmia Database serves as the foundation for training and evaluating our models, with added Gaussian noise to heighten the algorithms' resilience. The developed architectures incorporate various layers for specific processing and categorization functions, employing strategies such as the EarlyStopping callback and Dropout layer to prevent overfitting. Additionally, this paper details the creation of a tailored Tensor Compute Unit (TCU) accelerator for the PYNQ Z1 platform. It provides a thorough methodology for implementing FPGA-based machine learning, encompassing the configuration of the Tensil toolchain in Docker, selection of architectures, PS-PL configuration, and the compilation and deployment of models. By evaluating performance indicators like latency and throughput, we showcase the efficacy of FPGAs in advanced biomedical computing. This study ultimately serves as a comprehensive guide to optimizing neural network operations on FPGAs across various fields.
This paper presents an innovative methodology for improving the robustness and computational efficiency of Spiking Neural Networks (SNNs), a critical component in neuromorphic computing. The proposed approach integrates astrocytes, a type of glial cell prevalent in the human brain, into SNNs, creating astrocyte-augmented networks. To achieve this, we designed and implemented an astrocyte model in two distinct platforms: CPU/GPU and FPGA. Our FPGA implementation notably utilizes Dynamic Function Exchange (DFX) technology, enabling real-time hardware reconfiguration and adaptive model creation based on current operating conditions. The novel approach of leveraging astrocytes significantly improves the fault tolerance of SNNs, thereby enhancing their robustness. Notably, our astrocyte-augmented SNN displays near-zero latency and theoretically infinite throughput, implying exceptional computational efficiency. Through comprehensive comparative analysis with prior works, it's established that our model surpasses others in terms of neuron and synapse count while maintaining an efficient power consumption profile. These results underscore the potential of our methodology in shaping the future of neuromorphic computing, by providing robust and energy-efficient systems.
This study presents advanced neural network architectures including Convolutional Neural Networks (CNN), Recurrent Neural Networks (RNN), Long Short-Term Memory Networks (LSTMs), and Deep Belief Networks (DBNs) for enhanced ECG signal analysis using Field Programmable Gate Arrays (FPGAs). We utilize the MIT-BIH Arrhythmia Database for training and validation, introducing Gaussian noise to improve algorithm robustness. The implemented models feature various layers for distinct processing and classification tasks and techniques like EarlyStopping callback and Dropout layer are used to mitigate overfitting. Our work also explores the development of a custom Tensor Compute Unit (TCU) accelerator for the PYNQ Z1 board, offering comprehensive steps for FPGA-based machine learning, including setting up the Tensil toolchain in Docker, selecting architecture, configuring PS-PL, and compiling and executing models. Performance metrics such as latency and throughput are calculated for practical insights, demonstrating the potential of FPGAs in high-performance biomedical computing. The study ultimately offers a guide for optimizing neural network performance on FPGAs for various applications.
Due to the ability to implement customized topology, FPGA is increasingly used to deploy SNNs in both embedded and high-performance applications. In this paper, we survey state-of-the-art SNN implementations and their applications on FPGA. We collect the recent widely-used spiking neuron models, network structures, and signal encoding formats, followed by the enumeration of related hardware design schemes for FPGA-based SNN implementations. Compared with the previous surveys, this manuscript enumerates the application instances that applied the above-mentioned technical schemes in recent research. Based on that, we discuss the actual acceleration potential of implementing SNN on FPGA. According to our above discussion, the upcoming trends are discussed in this paper and give a guideline for further advancement in related subjects.
Reconfigurable architectures like Field Programmable Gate Arrays (FPGAs) have been used for accelerating computations in several domains because of their unique combination of flexibility, performance, and power efficiency. However, FPGAs have not been widely used for high-performance computing, primarily because of their programming complexity and difficulties in optimizing performance. We optimize Tensil AI's open-source inference accelerator for maximum performance using ResNet20 trained on CIFAR in this paper in order to gain insight into the use of FPGAs for high-performance computing. In this paper, we show how improving hardware design, using Xilinx Ultra RAM, and using advanced compiler strategies can lead to improved inference performance. We also demonstrate that running the CIFAR test data set shows very little accuracy drop when rounding down from the original 32-bit floating point. The heterogeneous computing model in our platform allows us to achieve a frame rate of 293.58 frames per second (FPS) and a %90 accuracy on a ResNet20 trained using CIFAR. The experimental results show that the proposed accelerator achieves a throughput of 21.12 Giga-Operations Per Second (GOP/s) with a 5.21 W on-chip power consumption at 100 MHz. The comparison results with off-the-shelf devices and recent state-of-the-art implementations illustrate that the proposed accelerator has obvious advantages in terms of energy efficiency.
Autoencoders are unsupervised neural networks that are used to process and compress input data and then reconstruct the data back to the original data size. This allows autoencoders to be used for different processing applications such as data compression, image classification, image noise reduction, and image coloring. Hardware-wise, re-configurable architectures like Field Programmable Gate Arrays (FPGAs) have been used for accelerating computations from several domains because of their unique combination of flexibility, performance, and power efficiency. In this paper, we look at the different autoencoders available and use the convolutional autoencoder in both FPGA and GPU-based implementations to process noisy static MNIST images. We compare the different results achieved with the FPGA and GPU-based implementations and then discuss the pros and cons of each implementation. The evaluation of the proposed design achieved 80%accuracy and our experimental results show that the proposed accelerator achieves a throughput of 21.12 Giga-Operations Per Second (GOP/s) with a 5.93 W on-chip power consumption at 100 MHz. The comparison results with off-the-shelf devices and recent state-of-the-art implementations illustrate that the proposed accelerator has obvious advantages in terms of energy efficiency and design flexibility. We also discuss future work that can be done with the use of our proposed accelerator.
Guillain-Barre syndrome is a rare neurological condition in which the human immune system attacks the peripheral nervous system. A peripheral nervous system appears as a diffusively connected system of mathematical models of neuron models, and the system's period becomes shorter than the periods of each neural circuit. The stimuli in the conduction path that will address the myelin sheath that has lost its function are received by the axons and are conveyed externally to the target organ, aiming to solve the problem of decreased nerve conduction. In the NEURON simulation environment, one can create a neuron model and define biophysical events that take place within the system for study. In this environment, signal transmission between cells and dendrites is obtained graphically. The simulated potassium and sodium conductance are replicated adequately, and the electronic action potentials are quite comparable to those measured experimentally. In this work, we propose an analog and digital coupled neuron model comprising individual excitatory and inhibitory neural circuit blocks for a low-cost and energy-efficient system. Compared to digital design, our analog design performs in lower frequency but gives a 32.3\% decreased energy efficiency. Thus, the resulting coupled analog hardware neuron model can be a proposed model for the simulation of reduced nerve conduction. As a result, the analog coupled neuron, (even with its greater design complexity) serious contender for the future development of a wearable sensor device that could help with Guillain-Barre syndrome and other neurologic diseases.
