Automatically Reconciling the Trade-off between Prediction Accuracy and Earliness in Prescriptive Business Process Monitoring

Prescriptive business process monitoring provides decision support to process managers on when and how to adapt an ongoing business process to prevent or mitigate an undesired process outcome. We focus on the problem of automatically reconciling the trade-off between prediction accuracy and prediction earliness in determining when to adapt. Adaptations should happen sufficiently early to provide enough lead time for the adaptation to become effective. However, earlier predictions are typically less accurate than later predictions. This means that acting on less accurate predictions may lead to unnecessary adaptations or missed adaptations. Different approaches were presented in the literature to reconcile the trade-off between prediction accuracy and earliness. So far, these approaches were compared with different baselines, and evaluated using different data sets or even confidential data sets. This limits the comparability and replicability of the approaches and makes it difficult to choose a concrete approach in practice. We perform a comparative evaluation of the main alternative approaches for reconciling the trade-off between prediction accuracy and earliness. Using four public real-world event log data sets and two types of prediction models, we assess and compare the cost savings of these approaches. The experimental results indicate which criteria affect the effectiveness of an approach and help us state initial recommendations for the selection of a concrete approach in practice.

A User Study on Explainable Online Reinforcement Learning for Adaptive Systems

Online reinforcement learning (RL) is increasingly used for realizing adaptive systems in the presence of design time uncertainty. Online RL facilitates learning from actual operational data and thereby leverages feedback only available at runtime. However, Online RL requires the definition of an effective and correct reward function, which quantifies the feedback to the RL algorithm and thereby guides learning. With Deep RL gaining interest, the learned knowledge is no longer explicitly represented, but is represented as a neural network. For a human, it becomes practically impossible to relate the parametrization of the neural network to concrete RL decisions. Deep RL thus essentially appears as a black box, which severely limits the debugging of adaptive systems. We previously introduced the explainable RL technique XRL-DINE, which provides visual insights into why certain decisions were made at important time points. Here, we introduce an empirical user study involving 54 software engineers from academia and industry to assess (1) the performance of software engineers when performing different tasks using XRL-DINE and (2) the perceived usefulness and ease of use of XRL-DINE.

Explaining Online Reinforcement Learning Decisions of Self-Adaptive Systems

Design time uncertainty poses an important challenge when developing a self-adaptive system. As an example, defining how the system should adapt when facing a new environment state, requires understanding the precise effect of an adaptation, which may not be known at design time. Online reinforcement learning, i.e., employing reinforcement learning (RL) at runtime, is an emerging approach to realizing self-adaptive systems in the presence of design time uncertainty. By using Online RL, the self-adaptive system can learn from actual operational data and leverage feedback only available at runtime. Recently, Deep RL is gaining interest. Deep RL represents learned knowledge as a neural network whereby it can generalize over unseen inputs, as well as handle continuous environment states and adaptation actions. A fundamental problem of Deep RL is that learned knowledge is not explicitly represented. For a human, it is practically impossible to relate the parametrization of the neural network to concrete RL decisions and thus Deep RL essentially appears as a black box. Yet, understanding the decisions made by Deep RL is key to (1) increasing trust, and (2) facilitating debugging. Such debugging is especially relevant for self-adaptive systems, because the reward function, which quantifies the feedback to the RL algorithm, must be defined by developers. The reward function must be explicitly defined by developers, thus introducing a potential for human error. To explain Deep RL for self-adaptive systems, we enhance and combine two existing explainable RL techniques from the machine learning literature. The combined technique, XRL-DINE, overcomes the respective limitations of the individual techniques. We present a proof-of-concept implementation of XRL-DINE, as well as qualitative and quantitative results of applying XRL-DINE to a self-adaptive system exemplar.

Counterfactual Explanations for Predictive Business Process Monitoring

Predictive business process monitoring increasingly leverages sophisticated prediction models. Although sophisticated models achieve consistently higher prediction accuracy than simple models, one major drawback is their lack of interpretability, which limits their adoption in practice. We thus see growing interest in explainable predictive business process monitoring, which aims to increase the interpretability of prediction models. Existing solutions focus on giving factual explanations.While factual explanations can be helpful, humans typically do not ask why a particular prediction was made, but rather why it was made instead of another prediction, i.e., humans are interested in counterfactual explanations. While research in explainable AI produced several promising techniques to generate counterfactual explanations, directly applying them to predictive process monitoring may deliver unrealistic explanations, because they ignore the underlying process constraints. We propose LORELEY, a counterfactual explanation technique for predictive process monitoring, which extends LORE, a recent explainable AI technique. We impose control flow constraints to the explanation generation process to ensure realistic counterfactual explanations. Moreover, we extend LORE to enable explaining multi-class classification models. Experimental results using a real, public dataset indicate that LORELEY can approximate the prediction models with an average fidelity of 97.69\% and generate realistic counterfactual explanations.

Feature-Model-Guided Online Learning for Self-Adaptive Systems

A self-adaptive system can modify its own structure and behavior at runtime based on its perception of the environment, of itself and of its requirements. To develop a self-adaptive system, software developers codify knowledge about the system and its environment, as well as how adaptation actions impact on the system. However, the codified knowledge may be insufficient due to design time uncertainty, and thus a self-adaptive system may execute adaptation actions that do not have the desired effect. Online learning is an emerging approach to address design time uncertainty by employing machine learning at runtime. Online learning accumulates knowledge at runtime by, for instance, exploring not-yet executed adaptation actions. We address two specific problems with respect to online learning for self-adaptive systems. First, the number of possible adaptation actions can be very large. Existing online learning techniques randomly explore the possible adaptation actions, but this can lead to slow convergence of the learning process. Second, the possible adaptation actions can change as a result of system evolution. Existing online learning techniques are unaware of these changes and thus do not explore new adaptation actions, but explore adaptation actions that are no longer valid. We propose using feature models to give structure to the set of adaptation actions and thereby guide the exploration process during online learning. Experimental results involving four real-world systems suggest that considering the hierarchical structure of feature models may speed up convergence by 7.2% on average. Considering the differences between feature models before and after an evolution step may speed up convergence by 64.6% on average. [...]
