FALCON: An ML Framework for Fully Automated Layout-Constrained Analog Circuit Design

Designing analog circuits from performance specifications is a complex, multi-stage process encompassing topology selection, parameter inference, and layout feasibility. We introduce FALCON, a unified machine learning framework that enables fully automated, specification-driven analog circuit synthesis through topology selection and layout-constrained optimization. Given a target performance, FALCON first selects an appropriate circuit topology using a performance-driven classifier guided by human design heuristics. Next, it employs a custom, edge-centric graph neural network trained to map circuit topology and parameters to performance, enabling gradient-based parameter inference through the learned forward model. This inference is guided by a differentiable layout cost, derived from analytical equations capturing parasitic and frequency-dependent effects, and constrained by design rules. We train and evaluate FALCON on a large-scale custom dataset of 1M analog mm-wave circuits, generated and simulated using Cadence Spectre across 20 expert-designed topologies. Through this evaluation, FALCON demonstrates >99\% accuracy in topology inference, <10\% relative error in performance prediction, and efficient layout-aware design that completes in under 1 second per instance. Together, these results position FALCON as a practical and extensible foundation model for end-to-end analog circuit design automation.

Supervised Learning for Analog and RF Circuit Design: Benchmarks and Comparative Insights

Automating analog and radio-frequency (RF) circuit design using machine learning (ML) significantly reduces the time and effort required for parameter optimization. This study explores supervised ML-based approaches for designing circuit parameters from performance specifications across various circuit types, including homogeneous and heterogeneous designs. By evaluating diverse ML models, from neural networks like transformers to traditional methods like random forests, we identify the best-performing models for each circuit. Our results show that simpler circuits, such as low-noise amplifiers, achieve exceptional accuracy with mean relative errors as low as 0.3% due to their linear parameter-performance relationships. In contrast, complex circuits, like power amplifiers and voltage-controlled oscillators, present challenges due to their non-linear interactions and larger design spaces. For heterogeneous circuits, our approach achieves an 88% reduction in errors with increased training data, with the receiver achieving a mean relative error as low as 0.23%, showcasing the scalability and accuracy of the proposed methodology. Additionally, we provide insights into model strengths, with transformers excelling in capturing non-linear mappings and k-nearest neighbors performing robustly in moderately linear parameter spaces, especially in heterogeneous circuits with larger datasets. This work establishes a foundation for extending ML-driven design automation, enabling more efficient and scalable circuit design workflows.

AICircuit: A Multi-Level Dataset and Benchmark for AI-Driven Analog Integrated Circuit Design

Analog and radio-frequency circuit design requires extensive exploration of both circuit topology and parameters to meet specific design criteria like power consumption and bandwidth. Designers must review state-of-the-art topology configurations in the literature and sweep various circuit parameters within each configuration. This design process is highly specialized and time-intensive, particularly as the number of circuit parameters increases and the circuit becomes more complex. Prior research has explored the potential of machine learning to enhance circuit design procedures. However, these studies primarily focus on simple circuits, overlooking the more practical and complex analog and radio-frequency systems. A major obstacle for bearing the power of machine learning in circuit design is the availability of a generic and diverse dataset, along with robust metrics, which are essential for thoroughly evaluating and improving machine learning algorithms in the analog and radio-frequency circuit domain. We present AICircuit, a comprehensive multi-level dataset and benchmark for developing and evaluating ML algorithms in analog and radio-frequency circuit design. AICircuit comprises seven commonly used basic circuits and two complex wireless transceiver systems composed of multiple circuit blocks, encompassing a wide array of design scenarios encountered in real-world applications. We extensively evaluate various ML algorithms on the dataset, revealing the potential of ML algorithms in learning the mapping from the design specifications to the desired circuit parameters.

Learning to Design Analog Circuits to Meet Threshold Specifications

Automated design of analog and radio-frequency circuits using supervised or reinforcement learning from simulation data has recently been studied as an alternative to manual expert design. It is straightforward for a design agent to learn an inverse function from desired performance metrics to circuit parameters. However, it is more common for a user to have threshold performance criteria rather than an exact target vector of feasible performance measures. In this work, we propose a method for generating from simulation data a dataset on which a system can be trained via supervised learning to design circuits to meet threshold specifications. We moreover perform the to-date most extensive evaluation of automated analog circuit design, including experimenting in a significantly more diverse set of circuits than in prior work, covering linear, nonlinear, and autonomous circuit configurations, and show that our method consistently reaches success rate better than 90% at 5% error margin, while also improving data efficiency by upward of an order of magnitude. A demo of this system is available at circuits.streamlit.app

Capacity Gains in MIMO Systems with Few-Bit ADCs Using Nonlinear Analog Operators

Analog to Digital Converters (ADCs) are a major contributor to the power consumption of multiple-input multiple-output (MIMO) receivers with large antenna arrays operating in the millimeter wave and terahertz carrier frequencies. This is especially the case in large bandwidth terahertz communication systems, due to the sudden drop in energy-efficiency of ADCs as the sampling rate is increased above 100MHz. Two mitigating energy-efficient approaches which have received significant recent interest are i) to reduce the number of ADCs via analog and hybrid beamforming architectures, and ii) to reduce the resolution of the ADCs which in turn decreases power consumption. However, decreasing the number and resolution of ADCs leads to performance loss -- in terms of achievable rates -- due to increased quantization error. In this work, we study the application of practically implementable nonlinear analog operators such as envelop detectors and polynomial operators, prior to sampling and quantization at the ADCs, as a way to mitigate the aforementioned rate-loss. A receiver architecture consisting of linear analog combiners, nonlinear analog operators, and few-bit ADCs is designed. The fundamental information theoretic performance limits of the resulting communication system, in terms of achievable rates, are investigated under various assumptions on the set of implementable analog operators. Various numerical evaluations and simulations of the communication system are provided to compare the set of achievable rates under different architecture designs and parameters. Circuit simulations {in a 65 nm CMOS technology} exhibiting the generation of envelope detectors and polynomial operators are provided, and their power consumption is compared.

Quantifying the Capacity Gains in Coarsely Quantized SISO Systems with Nonlinear Analog Operators

The power consumption of high-speed, high-resolution analog to digital converters (ADCs) is a limiting factor in implementing large-bandwidth mm-wave communication systems. A mitigating solution, which has drawn considerable recent interest, is to use a few low-resolution ADCs at the receiver. While reducing the number and resolution of the ADCs decreases power consumption, it also leads to a reduction in channel capacity due to the information loss induced by coarse quantization. This implies a rate-energy tradeoff governed by the number and resolution of ADCs. Recently, it was shown that given a fixed number of low-resolution ADCs, the application of practically implementable nonlinear analog operators, prior to sampling and quantization, may significantly reduce the aforementioned rate-loss. Building upon these observations, this work focuses on single-input single-output (SISO) communication scenarios, and i) characterizes capacity expressions under various assumptions on the set of implementable nonlinear analog functions, ii) provides computational methods to calculate the channel capacity numerically, and iii) quantifies the gains due to the use of nonlinear operators in SISO receiver terminals. Furthermore, circuit-level simulations, using a 65 nm Bulk CMOS technology, are provided to show the implementability of the desired nonlinear operators in the analog domain. The power requirements of the proposed circuits are quantified for various analog operators.

MIMO Systems with One-bit ADCs: Capacity Gains using Nonlinear Analog Operations

Analog to Digital Converters (ADCs) are a major contributor to the energy consumption on the receiver side of millimeter-wave multiple-input multiple-output (MIMO) systems with large antenna arrays. Consequently, there has been significant interest in using low-resolution ADCs along with hybrid beam-forming at MIMO receivers for energy efficiency. However, decreasing the ADC resolution results in performance loss -- in terms of achievable rates -- due to increased quantization error. In this work, we study the application of practically implementable nonlinear analog operations, prior to sampling and quantization at the ADCs, as a way to mitigate the aforementioned rate-loss. A receiver architecture consisting of linear analog combiners, implementable nonlinear analog operators, and one-bit threshold ADCs is designed. The fundamental information theoretic performance limits of the resulting communication system, in terms of achievable rates, are investigated under various assumptions on the set of implementable nonlinear analog functions. In order to justify the feasibility of the nonlinear operations in the proposed receiver architecture, an analog circuit is introduced, and circuit simulations exhibiting the generation of the desired nonlinear analog operations are provided.
