Binomial Self-compensation for Motion Error in Dynamic 3D Scanning

Phase shifting profilometry (PSP) is favored in high-precision 3D scanning due to its high accuracy, robustness, and pixel-wise property. However, a fundamental assumption of PSP that the object should remain static is violated in dynamic measurement, making PSP susceptible to object moving, resulting in ripple-like errors in the point clouds. We propose a pixel-wise and frame-wise loopable binomial self-compensation (BSC) algorithm to effectively and flexibly eliminate motion error in the four-step PSP. Our mathematical model demonstrates that by summing successive motion-affected phase frames weighted by binomial coefficients, motion error exponentially diminishes as the binomial order increases, accomplishing automatic error compensation through the motion-affected phase sequence, without the assistance of any intermediate variable. Extensive experiments show that our BSC outperforms the existing methods in reducing motion error, while achieving a depth map frame rate equal to the camera's acquisition rate (90 fps), enabling high-accuracy 3D reconstruction with a quasi-single-shot frame rate.

Phase Guided Light Field for Spatial-Depth High Resolution 3D Imaging

On 3D imaging, light field cameras typically are of single shot, and however, they heavily suffer from low spatial resolution and depth accuracy. In this paper, by employing an optical projector to project a group of single high-frequency phase-shifted sinusoid patterns, we propose a phase guided light field algorithm to significantly improve both the spatial and depth resolutions for off-the-shelf light field cameras. First, for correcting the axial aberrations caused by the main lens of our light field camera, we propose a deformed cone model to calibrate our structured light field system. Second, over wrapped phases computed from patterned images, we propose a stereo matching algorithm, i.e. phase guided sum of absolute difference, to robustly obtain the correspondence for each pair of neighbored two lenslets. Finally, by introducing a virtual camera according to the basic geometrical optics of light field imaging, we propose a reorganization strategy to reconstruct 3D point clouds with spatial-depth high resolution. Experimental results show that, compared with the state-of-the-art active light field methods, the proposed reconstructs 3D point clouds with a spatial resolution of 1280$\times$720 with factors 10$\times$ increased, while maintaining the same high depth resolution and needing merely a single group of high-frequency patterns.
