Solving Jigsaw Puzzles with Linear Programming

Nov 13, 2015
Rui Yu, Chris Russell, Lourdes Agapito


Share this with someone who'll enjoy it:


We propose a novel Linear Program (LP) based formula- tion for solving jigsaw puzzles. We formulate jigsaw solving as a set of successive global convex relaxations of the stan- dard NP-hard formulation, that can describe both jigsaws with pieces of unknown position and puzzles of unknown po- sition and orientation. The main contribution and strength of our approach comes from the LP assembly strategy. In contrast to existing greedy methods, our LP solver exploits all the pairwise matches simultaneously, and computes the position of each piece/component globally. The main ad- vantages of our LP approach include: (i) a reduced sensi- tivity to local minima compared to greedy approaches, since our successive approximations are global and convex and (ii) an increased robustness to the presence of mismatches in the pairwise matches due to the use of a weighted L1 penalty. To demonstrate the effectiveness of our approach, we test our algorithm on public jigsaw datasets and show that it outperforms state-of-the-art methods.
