Continuous Object State Recognition for Cooking Robots Using Pre-Trained Vision-Language Models and Black-box Optimization

The state recognition of the environment and objects by robots is generally based on the judgement of the current state as a classification problem. On the other hand, state changes of food in cooking happen continuously and need to be captured not only at a certain time point but also continuously over time. In addition, the state changes of food are complex and cannot be easily described by manual programming. Therefore, we propose a method to recognize the continuous state changes of food for cooking robots through the spoken language using pre-trained large-scale vision-language models. By using models that can compute the similarity between images and texts continuously over time, we can capture the state changes of food while cooking. We also show that by adjusting the weighting of each text prompt based on fitting the similarity changes to a sigmoid function and then performing black-box optimization, more accurate and robust continuous state recognition can be achieved. We demonstrate the effectiveness and limitations of this method by performing the recognition of water boiling, butter melting, egg cooking, and onion stir-frying.

Daily Assistive View Control Learning of Low-Cost Low-Rigidity Robot via Large-Scale Vision-Language Model

In this study, we develop a simple daily assistive robot that controls its own vision according to linguistic instructions. The robot performs several daily tasks such as recording a user's face, hands, or screen, and remotely capturing images of desired locations. To construct such a robot, we combine a pre-trained large-scale vision-language model with a low-cost low-rigidity robot arm. The correlation between the robot's physical and visual information is learned probabilistically using a neural network, and changes in the probability distribution based on changes in time and environment are considered by parametric bias, which is a learnable network input variable. We demonstrate the effectiveness of this learning method by open-vocabulary view control experiments with an actual robot arm, MyCobot.

Binary State Recognition by Robots using Visual Question Answering of Pre-Trained Vision-Language Model

Recognition of the current state is indispensable for the operation of a robot. There are various states to be recognized, such as whether an elevator door is open or closed, whether an object has been grasped correctly, and whether the TV is turned on or off. Until now, these states have been recognized by programmatically describing the state of a point cloud or raw image, by annotating and learning images, by using special sensors, etc. In contrast to these methods, we apply Visual Question Answering (VQA) from a Pre-Trained Vision-Language Model (PTVLM) trained on a large-scale dataset, to such binary state recognition. This idea allows us to intuitively describe state recognition in language without any re-training, thereby improving the recognition ability of robots in a simple and general way. We summarize various techniques in questioning methods and image processing, and clarify their properties through experiments.

Semantic Scene Difference Detection in Daily Life Patroling by Mobile Robots using Pre-Trained Large-Scale Vision-Language Model

It is important for daily life support robots to detect changes in their environment and perform tasks. In the field of anomaly detection in computer vision, probabilistic and deep learning methods have been used to calculate the image distance. These methods calculate distances by focusing on image pixels. In contrast, this study aims to detect semantic changes in the daily life environment using the current development of large-scale vision-language models. Using its Visual Question Answering (VQA) model, we propose a method to detect semantic changes by applying multiple questions to a reference image and a current image and obtaining answers in the form of sentences. Unlike deep learning-based methods in anomaly detection, this method does not require any training or fine-tuning, is not affected by noise, and is sensitive to semantic state changes in the real world. In our experiments, we demonstrated the effectiveness of this method by applying it to a patrol task in a real-life environment using a mobile robot, Fetch Mobile Manipulator. In the future, it may be possible to add explanatory power to changes in the daily life environment through spoken language.

Recognition of Heat-Induced Food State Changes by Time-Series Use of Vision-Language Model for Cooking Robot

Cooking tasks are characterized by large changes in the state of the food, which is one of the major challenges in robot execution of cooking tasks. In particular, cooking using a stove to apply heat to the foodstuff causes many special state changes that are not seen in other tasks, making it difficult to design a recognizer. In this study, we propose a unified method for recognizing changes in the cooking state of robots by using the vision-language model that can discriminate open-vocabulary objects in a time-series manner. We collected data on four typical state changes in cooking using a real robot and confirmed the effectiveness of the proposed method. We also compared the conditions and discussed the types of natural language prompts and the image regions that are suitable for recognizing the state changes.

A method for Selecting Scenes and Emotion-based Descriptions for a Robot's Diary

In this study, we examined scene selection methods and emotion-based descriptions for a robot's daily diary. We proposed a scene selection method and an emotion description method that take into account semantic and affective information, and created several types of diaries. Experiments were conducted to examine the change in sentiment values and preference of each diary, and it was found that the robot's feelings and impressions changed more from date to date when scenes were selected using the affective captions. Furthermore, we found that the robot's emotion generally improves the preference of the robot's diary regardless of the scene it describes. However, presenting negative or mixed emotions at once may decrease the preference of the diary or reduce the robot's robot-likeness, and thus the method of presenting emotions still needs further investigation.

Automatic Diary Generation System including Information on Joint Experiences between Humans and Robots

In this study, we propose an automatic diary generation system that uses information from past joint experiences with the aim of increasing the favorability for robots through shared experiences between humans and robots. For the verbalization of the robot's memory, the system applies a large-scale language model, which is a rapidly developing field. Since this model does not have memories of experiences, it generates a diary by receiving information from joint experiences. As an experiment, a robot and a human went for a walk and generated a diary with interaction and dialogue history. The proposed diary achieved high scores in comfort and performance in the evaluation of the robot's impression. In the survey of diaries giving more favorable impressions, diaries with information on joint experiences were selected higher than diaries without such information, because diaries with information on joint experiences showed more cooperation between the robot and the human and more intimacy from the robot.

Foundation Model based Open Vocabulary Task Planning and Executive System for General Purpose Service Robots

This paper describes a strategy for implementing a robotic system capable of performing General Purpose Service Robot (GPSR) tasks in robocup@home. The GPSR task is that a real robot hears a variety of commands in spoken language and executes a task in a daily life environment. To achieve the task, we integrate foundation models based inference system and a state machine task executable. The foundation models plan the task and detect objects with open vocabulary, and a state machine task executable manages each robot's actions. This system works stable, and we took first place in the RoboCup@home Japan Open 2022's GPSR with 130 points, more than 85 points ahead of the other teams.

Robotic Applications of Pre-Trained Vision-Language Models to Various Recognition Behaviors

In recent years, a number of models that learn the relations between vision and language from large datasets have been released. These models perform a variety of tasks, such as answering questions about images, retrieving sentences that best correspond to images, and finding regions in images that correspond to phrases. Although there are some examples, the connection between these pre-trained vision-language models and robotics is still weak. If they are directly connected to robot motions, they lose their versatility due to the embodiment of the robot and the difficulty of data collection, and become inapplicable to a wide range of bodies and situations. Therefore, in this study, we categorize and summarize the methods to utilize the pre-trained vision-language models flexibly and easily in a way that the robot can understand, without directly connecting them to robot motions. We discuss how to use these models for robot motion selection and motion planning without re-training the models. We consider five types of methods to extract information understandable for robots, and show the results of state recognition, object recognition, affordance recognition, relation recognition, and anomaly detection based on the combination of these five methods. We expect that this study will add flexibility and ease-of-use, as well as new applications, to the recognition behavior of existing robots.

VQA-based Robotic State Recognition Optimized with Genetic Algorithm

State recognition of objects and environment in robots has been conducted in various ways. In most cases, this is executed by processing point clouds, learning images with annotations, and using specialized sensors. In contrast, in this study, we propose a state recognition method that applies Visual Question Answering (VQA) in a Pre-Trained Vision-Language Model (PTVLM) trained from a large-scale dataset. By using VQA, it is possible to intuitively describe robotic state recognition in the spoken language. On the other hand, there are various possible ways to ask about the same event, and the performance of state recognition differs depending on the question. Therefore, in order to improve the performance of state recognition using VQA, we search for an appropriate combination of questions using a genetic algorithm. We show that our system can recognize not only the open/closed of a refrigerator door and the on/off of a display, but also the open/closed of a transparent door and the state of water, which have been difficult to recognize.
