SEER: Super-Optimization Explorer for HLS using E-graph Rewriting with MLIR

High-level synthesis (HLS) is a process that automatically translates a software program in a high-level language into a low-level hardware description. However, the hardware designs produced by HLS tools still suffer from a significant performance gap compared to manual implementations. This is because the input HLS programs must still be written using hardware design principles. Existing techniques either leave the program source unchanged or perform a fixed sequence of source transformation passes, potentially missing opportunities to find the optimal design. We propose a super-optimization approach for HLS that automatically rewrites an arbitrary software program into efficient HLS code that can be used to generate an optimized hardware design. We developed a toolflow named SEER, based on the e-graph data structure, to efficiently explore equivalent implementations of a program at scale. SEER provides an extensible framework, orchestrating existing software compiler passes and hardware synthesis optimizers. Our work is the first attempt to exploit e-graph rewriting for large software compiler frameworks, such as MLIR. Across a set of open-source benchmarks, we show that SEER achieves up to 38x the performance within 1.4x the area of the original program. Via an Intel-provided case study, SEER demonstrates the potential to outperform manually optimized designs produced by hardware experts.

Abstract Interpretation on E-Graphs

Recent e-graph applications have typically considered concrete semantics of expressions, where the notion of equivalence stems from concrete interpretation of expressions. However, equivalences that hold over one interpretation may not hold in an alternative interpretation. Such an observation can be exploited. We consider the application of abstract interpretation to e-graphs, and show that within an e-graph, the lattice meet operation associated with the abstract domain has a natural interpretation for an e-class, leading to improved precision in over-approximation. In this extended abstract, we use Interval Arithmetic (IA) to illustrate this point.
