E-RGB-D: Real-Time Event-Based Perception with Structured Light

Event-based cameras (ECs) have emerged as bio-inspired sensors that report pixel brightness changes asynchronously, offering unmatched speed and efficiency in vision sensing. Despite their high dynamic range, temporal resolution, low power consumption, and computational simplicity, traditional monochrome ECs face limitations in detecting static or slowly moving objects and lack color information essential for certain applications. To address these challenges, we present a novel approach that integrates a Digital Light Processing (DLP) projector, forming Active Structured Light (ASL) for RGB-D sensing. By combining the benefits of ECs and projection-based techniques, our method enables the detection of color and the depth of each pixel separately. Dynamic projection adjustments optimize bandwidth, ensuring selective color data acquisition and yielding colorful point clouds without sacrificing spatial resolution. This integration, facilitated by a commercial TI LightCrafter 4500 projector and a monocular monochrome EC, not only enables frameless RGB-D sensing applications but also achieves remarkable performance milestones. With our approach, we achieved a color detection speed equivalent to 1400 fps and 4 kHz of pixel depth detection, significantly advancing the realm of computer vision across diverse fields from robotics to 3D reconstruction methods. Our code is publicly available: https://github.com/MISTLab/event_based_rgbd_ros

Event-based RGB-D sensing with structured light

Event-based cameras (ECs) are bio-inspired sensors that asynchronously report brightness changes for each pixel. Due to their high dynamic range, pixel bandwidth, temporal resolution, low power consumption, and computational simplicity, they are beneficial for vision-based projects in challenging lighting conditions and they can detect fast movements with their microsecond response time. The first generation of ECs are monochrome, but color data is very useful and sometimes essential for certain vision-based applications. The latest technology enables manufacturers to build color ECs, trading off the size of the sensor and substantially reducing the resolution compared to monochrome models, despite having the same bandwidth. In addition, ECs only detect changes in light and do not show static or slowly moving objects. We introduce a method to detect full RGB events using a monochrome EC aided by a structured light projector. The projector emits rapidly changing RGB patterns of light beams on the scene, the reflection of which is captured by the EC. We combine the benefits of ECs and projection-based techniques and allow depth and color detection of static or moving objects with a commercial TI LightCrafter 4500 projector and a monocular monochrome EC, paving the way for frameless RGB-D sensing applications.
