Parallel Algorithms for Exact Enumeration of Deep Neural Network Activation Regions

A feedforward neural network using rectified linear units constructs a mapping from inputs to outputs by partitioning its input space into a set of convex regions where points within a region share a single affine transformation. In order to understand how neural networks work, when and why they fail, and how they compare to biological intelligence, we need to understand the organization and formation of these regions. Step one is to design and implement algorithms for exact region enumeration in networks beyond toy examples. In this work, we present parallel algorithms for exact enumeration in deep (and shallow) neural networks. Our work has three main contributions: (1) we present a novel algorithm framework and parallel algorithms for region enumeration; (2) we implement one of our algorithms on a variety of network architectures and experimentally show how the number of regions dictates runtime; and (3) we show, using our algorithm's output, how the dimension of a region's affine transformation impacts further partitioning of the region by deeper layers. To our knowledge, we run our implemented algorithm on networks larger than all of the networks used in the existing region enumeration literature. Further, we experimentally demonstrate the importance of parallelism for region enumeration of any reasonably sized network.

Multi-Neuron Representations of Hierarchical Concepts in Spiking Neural Networks

We describe how hierarchical concepts can be represented in three types of layered neural networks. The aim is to support recognition of the concepts when partial information about the concepts is presented, and also when some of the neurons in the network might fail. Our failure model involves initial random failures. The three types of networks are: feed-forward networks with high connectivity, feed-forward networks with low connectivity, and layered networks with low connectivity and with both forward edges and "lateral" edges within layers. In order to achieve fault-tolerance, the representations all use multiple representative neurons for each concept. We show how recognition can work in all three of these settings, and quantify how the probability of correct recognition depends on several parameters, including the number of representatives and the neuron failure probability. We also discuss how these representations might be learned, in all three types of networks. For the feed-forward networks, the learning algorithms are similar to ones used in [4], whereas for networks with lateral edges, the algorithms are generally inspired by work on the assembly calculus [3, 6, 7].
