200Gb/s VCSEL transmission using 60m OM4 MMF and KP4 FEC for AI computing clusters

We show a beyond 200Gb/s VCSEL transmission experiment. Results are based on 35GHz VCSEL and advanced DSP. We show an AIR of 245Gb/s PAM-6 back-to-back, and 200Gb/s PAM-4 over 60m OM4 fiber assuming KP4-FEC.

Spiking Neural Network Nonlinear Demapping on Neuromorphic Hardware for IM/DD Optical Communication

Neuromorphic computing implementing spiking neural networks (SNN) is a promising technology for reducing the footprint of optical transceivers, as required by the fast-paced growth of data center traffic. In this work, an SNN nonlinear demapper is designed and evaluated on a simulated intensity-modulation direct-detection link with chromatic dispersion. The SNN demapper is implemented in software and on the analog neuromorphic hardware system BrainScaleS-2 (BSS-2). For comparison, linear equalization (LE), Volterra nonlinear equalization (VNLE), and nonlinear demapping by an artificial neural network (ANN) implemented in software are considered. At a pre-forward error correction bit error rate of 2e-3, the software SNN outperforms LE by 1.5 dB, VNLE by 0.3 dB and the ANN by 0.5 dB. The hardware penalty of the SNN on BSS-2 is only 0.2 dB, i.e., also on hardware, the SNN performs better than all software implementations of the reference approaches. Hence, this work demonstrates that SNN demappers implemented on electrical analog hardware can realize powerful and accurate signal processing fulfilling the strict requirements of optical communications.

Experimental Comparison of PAM-8 Probabilistic Shaping with Different Gaussian Orders at 200 Gb/s Net Rate in IM/DD System with O-Band TOSA

For 200Gb/s net rates, cap probabilistic shaped PAM-8 with different Gaussian orders are experimentally compared against uniform PAM-8. In back-to-back and 5km measurements, cap-shaped 85-GBd PAM-8 with Gaussian order of 5 outperforms 71-GBd uniform PAM-8 by up to 2.90dB and 3.80dB in receiver sensitivity, respectively.

Spiking Neural Network Equalization on Neuromorphic Hardware for IM/DD Optical Communication

A spiking neural network (SNN) non-linear equalizer model is implemented on the mixed-signal neuromorphic hardware system BrainScaleS-2 and evaluated for an IM/DD link. The BER 2e-3 is achieved with a hardware penalty less than 1 dB, outperforming numeric linear equalization.

Experimental Comparison of Cap and Cup Probabilistically Shaped PAM for O-Band IM/DD Transmission System

For 200Gbit/s net rates, uniform PAM-4, 6 and 8 are experimentally compared against probabilistic shaped PAM-8 cap and cup variants. In back-to-back and 20km measurements, cap shaped 80GBd PAM-8 outperforms 72GBd PAM-8 and 83GBd PAM-6 by up to 3.50dB and 0.8dB in receiver sensitivity, respectively

Spiking Neural Network Equalization for IM/DD Optical Communication

A spiking neural network (SNN) equalizer model suitable for electronic neuromorphic hardware is designed for an IM/DD link. The SNN achieves the same bit-error-rate as an artificial neural network, outperforming linear equalization.

1.71 Tb/s Single-Channel and 56.51 Tb/s DWDM Transmission over 96.5 km Field-Deployed SSMF

We report an industry leading optical dense wavelength division multiplexing (DWDM) field trial with line rates per channel exceeding 1.66 Tb/s using 130 GBaud dual-polarization probabilistic constellation shaping 256-ary quadrature amplitude modulation (DP-PCS256QAM) in a high capacity data center interconnect (DCI) scenario. This research trial was performed on 96.5 km of field-deployed standard single mode G.652 fiber infrastructure of Deutsche Telekom in Germany employing Erbium-doped fiber amplifier (EDFA)-only amplification. A total of 34 channels were transmitted with 150 GHz spacing for a total fiber capacity of 56.51 Tb/s and a spectral efficiency higher than 11bit/s/Hz. In the single-channel transmission scenario 1.71 Tb/s was achieved over the same link. In addition, we successfully demonstrate record net bitrates of 1.88 Tb/s in back-to-back (B2B) using 130 GBaud DP-PCS400QAM.
