Add to EdgeChangsong Xie
Experimental Comparison of PAM-8 Probabilistic Shaping with Different Gaussian Orders at 200 Gb/s Net Rate in IM/DD System with O-Band TOSA
Jun 14, 2022
For 200Gb/s net rates, cap probabilistic shaped PAM-8 with different Gaussian orders are experimentally compared against uniform PAM-8. In back-to-back and 5km measurements, cap-shaped 85-GBd PAM-8 with Gaussian order of 5 outperforms 71-GBd uniform PAM-8 by up to 2.90dB and 3.80dB in receiver sensitivity, respectively.
Experimental Comparison of Cap and Cup Probabilistically Shaped PAM for O-Band IM/DD Transmission System
May 18, 2022
For 200Gbit/s net rates, uniform PAM-4, 6 and 8 are experimentally compared against probabilistic shaped PAM-8 cap and cup variants. In back-to-back and 20km measurements, cap shaped 80GBd PAM-8 outperforms 72GBd PAM-8 and 83GBd PAM-6 by up to 3.50dB and 0.8dB in receiver sensitivity, respectively
* Originally published in ECOC-2021. We have updated Figure 3. The change also affects the overall outcome. In contrast to the published version, compared to uniform PAM-8 72 GBd, PS-PAM-8 80 GBd performance is updated to 3.50 dB instead of 5.17 dB, while for PAM-6 83 GBd the gain becomes 0.8 dB instead of 2.17 dB. The changes are adapted in all sections except the experimental setup and DSP section
1.71 Tb/s Single-Channel and 56.51 Tb/s DWDM Transmission over 96.5 km Field-Deployed SSMF
Aug 04, 2021
We report an industry leading optical dense wavelength division multiplexing (DWDM) field trial with line rates per channel exceeding 1.66 Tb/s using 130 GBaud dual-polarization probabilistic constellation shaping 256-ary quadrature amplitude modulation (DP-PCS256QAM) in a high capacity data center interconnect (DCI) scenario. This research trial was performed on 96.5 km of field-deployed standard single mode G.652 fiber infrastructure of Deutsche Telekom in Germany employing Erbium-doped fiber amplifier (EDFA)-only amplification. A total of 34 channels were transmitted with 150 GHz spacing for a total fiber capacity of 56.51 Tb/s and a spectral efficiency higher than 11bit/s/Hz. In the single-channel transmission scenario 1.71 Tb/s was achieved over the same link. In addition, we successfully demonstrate record net bitrates of 1.88 Tb/s in back-to-back (B2B) using 130 GBaud DP-PCS400QAM.
