Pseudo-Boolean d-DNNF Compilation for Expressive Feature Modeling Constructs

Configurable systems typically consist of reusable assets that have dependencies between each other. To specify such dependencies, feature models are commonly used. As feature models in practice are often complex, automated reasoning is typically employed to analyze the dependencies. Here, the de facto standard is translating the feature model to conjunctive normal form (CNF) to enable employing off-the-shelf tools, such as SAT or #SAT solvers. However, modern feature-modeling dialects often contain constructs, such as cardinality constraints, that are ill-suited for conversion to CNF. This mismatch between the input of reasoning engines and the available feature-modeling dialects limits the applicability of the more expressive constructs. In this work, we shorten this gap between expressive constructs and scalable automated reasoning. Our contribution is twofold: First, we provide a pseudo-Boolean encoding for feature models, which facilitates smaller representations of commonly employed constructs compared to Boolean encoding. Second, we propose a novel method to compile pseudo-Boolean formulas to Boolean d-DNNF. With the compiled d-DNNFs, we can resort to a plethora of efficient analyses already used in feature modeling. Our empirical evaluation shows that our proposal substantially outperforms the state-of-the-art based on CNF inputs for expressive constructs. For every considered dataset representing different feature models and feature-modeling constructs, the feature models can be significantly faster translated to pseudo-Boolean than to CNF. Overall, deriving d-DNNFs from a feature model with the targeted expressive constraints can be substantially accelerated using our pseudo-Boolean approach. Furthermore, our approach is competitive on feature models with only basic constructs.

How to Drawjectory? -- Trajectory Planning using Programming by Demonstration

A flight trajectory defines how exactly a quadrocopter moves in the three-dimensional space from one position to another. Automatic flight trajectory planning faces challenges such as high computational effort and a lack of precision. Hence, when low computational effort or precise control is required, programming the flight route trajectory manually might be preferable. However, this requires in-depth knowledge of how to accurately plan flight trajectories in three-dimensional space. We propose planning quadrocopter flight trajectories manually using the Programming by Demonstration (PbD) approach -- simply drawing the trajectory in the three-dimensional space by hand. This simplifies the planning process and reduces the level of in-depth knowledge required. We implemented the approach in the context of the Quadcopter Lab at Ulm University. In order to evaluate our approach, we compare the precision and accuracy of the trajectories drawn by a user using our approach as well as the required time with those manually programmed using a domain specific language. The evaluation shows that the Drawjectory workflow is, on average, 78.7 seconds faster without a significant loss of precision, shown by an average deviation 6.67 cm.

Streamlining Attack Tree Generation: A Fragment-Based Approach

Attack graphs are a tool for analyzing security vulnerabilities that capture different and prospective attacks on a system. As a threat modeling tool, it shows possible paths that an attacker can exploit to achieve a particular goal. However, due to the large number of vulnerabilities that are published on a daily basis, they have the potential to rapidly expand in size. Consequently, this necessitates a significant amount of resources to generate attack graphs. In addition, generating composited attack models for complex systems such as self-adaptive or AI is very difficult due to their nature to continuously change. In this paper, we present a novel fragment-based attack graph generation approach that utilizes information from publicly available information security databases. Furthermore, we also propose a domain-specific language for attack modeling, which we employ in the proposed attack graph generation approach. Finally, we present a demonstrator example showcasing the attack generator's capability to replicate a verified attack chain, as previously confirmed by security experts.

Towards Model Co-evolution Across Self-Adaptation Steps for Combined Safety and Security Analysis

Self-adaptive systems offer several attack surfaces due to the communication via different channels and the different sensors required to observe the environment. Often, attacks cause safety to be compromised as well, making it necessary to consider these two aspects together. Furthermore, the approaches currently used for safety and security analysis do not sufficiently take into account the intermediate steps of an adaptation. Current work in this area ignores the fact that a self-adaptive system also reveals possible vulnerabilities (even if only temporarily) during the adaptation. To address this issue, we propose a modeling approach that takes into account the different relevant aspects of a system, its adaptation process, as well as safety hazards and security attacks. We present several models that describe different aspects of a self-adaptive system and we outline our idea of how these models can then be combined into an Attack-Fault Tree. This allows modeling aspects of the system on different levels of abstraction and co-evolve the models using transformations according to the adaptation of the system. Finally, analyses can then be performed as usual on the resulting Attack-Fault Tree.
