Spatial Diarization for Meeting Transcription with Ad-Hoc Acoustic Sensor Networks

We propose a diarization system, that estimates "who spoke when" based on spatial information, to be used as a front-end of a meeting transcription system running on the signals gathered from an acoustic sensor network (ASN). Although the spatial distribution of the microphones is advantageous, exploiting the spatial diversity for diarization and signal enhancement is challenging, because the microphones' positions are typically unknown, and the recorded signals are initially unsynchronized in general. Here, we approach these issues by first blindly synchronizing the signals and then estimating time differences of arrival (TDOAs). The TDOA information is exploited to estimate the speakers' activity, even in the presence of multiple speakers being simultaneously active. This speaker activity information serves as a guide for a spatial mixture model, on which basis the individual speaker's signals are extracted via beamforming. Finally, the extracted signals are forwarded to a speech recognizer. Additionally, a novel initialization scheme for spatial mixture models based on the TDOA estimates is proposed. Experiments conducted on real recordings from the LibriWASN data set have shown that our proposed system is advantageous compared to a system using a spatial mixture model, which does not make use of external diarization information.

LibriWASN: A Data Set for Meeting Separation, Diarization, and Recognition with Asynchronous Recording Devices

We present LibriWASN, a data set whose design follows closely the LibriCSS meeting recognition data set, with the marked difference that the data is recorded with devices that are randomly positioned on a meeting table and whose sampling clocks are not synchronized. Nine different devices, five smartphones with a single recording channel and four microphone arrays, are used to record a total of 29 channels. Other than that, the data set follows closely the LibriCSS design: the same LibriSpeech sentences are played back from eight loudspeakers arranged around a meeting table and the data is organized in subsets with different percentages of speech overlap. LibriWASN is meant as a test set for clock synchronization algorithms, meeting separation, diarization and transcription systems on ad-hoc wireless acoustic sensor networks. Due to its similarity to LibriCSS, meeting transcription systems developed for the former can readily be tested on LibriWASN. The data set is recorded in two different rooms and is complemented with ground-truth diarization information of who speaks when.

A Meeting Transcription System for an Ad-Hoc Acoustic Sensor Network

We propose a system that transcribes the conversation of a typical meeting scenario that is captured by a set of initially unsynchronized microphone arrays at unknown positions. It consists of subsystems for signal synchronization, including both sampling rate and sampling time offset estimation, diarization based on speaker and microphone array position estimation, multi-channel speech enhancement, and automatic speech recognition. With the estimated diarization information, a spatial mixture model is initialized that is used to estimate beamformer coefficients for source separation. Simulations show that the speech recognition accuracy can be improved by synchronizing and combining multiple distributed microphone arrays compared to a single compact microphone array. Furthermore, the proposed informed initialization of the spatial mixture model delivers a clear performance advantage over random initialization.

On Synchronization of Wireless Acoustic Sensor Networks in the Presence of Time-varying Sampling Rate Offsets and Speaker Changes

A wireless acoustic sensor network records audio signals with sampling time and sampling rate offsets between the audio streams, if the analog-digital converters (ADCs) of the network devices are not synchronized. Here, we introduce a new sampling rate offset model to simulate time-varying sampling frequencies caused, for example, by temperature changes of ADC crystal oscillators, and propose an estimation algorithm to handle this dynamic aspect in combination with changing acoustic source positions. Furthermore, we show how deep neural network based estimates of the distances between microphones and human speakers can be used to determine the sampling time offsets. This enables a synchronization of the audio streams to reflect the physical time differences of flight.

A Database for Research on Detection and Enhancement of Speech Transmitted over HF links

In this paper we present an open database for the development of detection and enhancement algorithms of speech transmitted over HF radio channels. It consists of audio samples recorded by various receivers at different locations across Europe, all monitoring the same single-sideband modulated transmission from a base station in Paderborn, Germany. Transmitted and received speech signals are precisely time aligned to offer parallel data for supervised training of deep learning based detection and enhancement algorithms. For the task of speech activity detection two exemplary baseline systems are presented, one based on statistical methods employing a multi-stage Wiener filter with minimum statistics noise floor estimation, and the other relying on a deep learning approach.

Open Range Pitch Tracking for Carrier Frequency Difference Estimation from HF Transmitted Speech

In this paper we investigate the task of detecting carrier frequency differences from demodulated single sideband signals by examining the pitch contours of the received baseband speech signal in the short-time spectral domain. From the detected pitch frequency trajectory and its harmonics a carrier frequency difference, which is caused by demodulating the radio signal with the wrong carrier frequency, can be deduced. A computationally efficient realization in the power cepstral domain is presented. The core component, i.e., the pitch tracking algorithm, is shown to perform comparably to a state of the art algorithm. The full carrier frequency difference estimation system is tested on recordings of real transmissions over HF links. A comparison with an existing approach shows improved estimation accuracy, both on short and longer speech utterances
