Neural Network Acceleration on MPSoC board: Integrating SLAC's SNL, Rogue Software and Auto-SNL

The LCLS-II Free Electron Laser (FEL) will generate X-ray pulses for beamline experiments at rates of up to 1~MHz, with detectors producing data throughputs exceeding 1 TB/s. Managing such massive data streams presents significant challenges, as transmission and storage infrastructures become prohibitively expensive. Machine learning (ML) offers a promising solution for real-time data reduction, but conventional implementations introduce excessive latency, making them unsuitable for high-speed experimental environments. To address these challenges, SLAC developed the SLAC Neural Network Library (SNL), a specialized framework designed to deploy real-time ML inference models on Field-Programmable Gate Arrays (FPGA). SNL's key feature is the ability to dynamically update model weights without requiring FPGA resynthesis, enhancing flexibility for adaptive learning applications. To further enhance usability and accessibility, we introduce Auto-SNL, a Python extension that streamlines the process of converting Python-based neural network models into SNL-compatible high-level synthesis code. This paper presents a benchmark comparison against hls4ml, the current state-of-the-art tool, across multiple neural network architectures, fixed-point precisions, and synthesis configurations targeting a Xilinx ZCU102 FPGA. The results showed that SNL achieves competitive or superior latency in most tested architectures, while in some cases also offering FPGA resource savings. This adaptation demonstrates SNL's versatility, opening new opportunities for researchers and academics in fields such as high-energy physics, medical imaging, robotics, and many more.

rule4ml: An Open-Source Tool for Resource Utilization and Latency Estimation for ML Models on FPGA

Implementing Machine Learning (ML) models on Field-Programmable Gate Arrays (FPGAs) is becoming increasingly popular across various domains as a low-latency and low-power solution that helps manage large data rates generated by continuously improving detectors. However, developing ML models for FPGAs is time-consuming, as optimization requires synthesis to evaluate FPGA area and latency, making the process slow and repetitive. This paper introduces a novel method to predict the resource utilization and inference latency of Neural Networks (NNs) before their synthesis and implementation on FPGA. We leverage HLS4ML, a tool-flow that helps translate NNs into high-level synthesis (HLS) code, to synthesize a diverse dataset of NN architectures and train resource utilization and inference latency predictors. While HLS4ML requires full synthesis to obtain resource and latency insights, our method uses trained regression models for immediate pre-synthesis predictions. The prediction models estimate the usage of Block RAM (BRAM), Digital Signal Processors (DSP), Flip-Flops (FF), and Look-Up Tables (LUT), as well as the inference clock cycles. The predictors were evaluated on both synthetic and existing benchmark architectures and demonstrated high accuracy with R2 scores ranging between 0.8 and 0.98 on the validation set and sMAPE values between 10% and 30%. Overall, our approach provides valuable preliminary insights, enabling users to quickly assess the feasibility and efficiency of NNs on FPGAs, accelerating the development and deployment processes. The open-source repository can be found at https://github.com/IMPETUS-UdeS/rule4ml, while the datasets are publicly available at https://borealisdata.ca/dataverse/rule4ml.
