Identification of Energy Management Configuration Concepts from a Set of Pareto-optimal Solutions

Optimizing building configurations for an efficient use of energy is increasingly receiving attention by current research and several methods have been developed to address this task. Selecting a suitable configuration based on multiple conflicting objectives, such as initial investment cost, recurring cost, robustness with respect to uncertainty of grid operation is, however, a difficult multi-criteria decision making problem. Concept identification can facilitate a decision maker by sorting configuration options into semantically meaningful groups (concepts), further introducing constraints to meet trade-off expectations for a selection of objectives. In this study, for a set of 20000 Pareto-optimal building energy management configurations, resulting from a many-objective evolutionary optimization, multiple concept identification iterations are conducted to provide a basis for making an informed investment decision. In a series of subsequent analysis steps, it is shown how the choice of description spaces, i.e., the partitioning of the features into sets for which consistent and non-overlapping concepts are required, impacts the type of information that can be extracted and that different setups of description spaces illuminate several different aspects of the configuration data - an important aspect that has not been addressed in previous work.

Concept Identification for Complex Engineering Datasets

Finding meaningful concepts in engineering application datasets which allow for a sensible grouping of designs is very helpful in many contexts. It allows for determining different groups of designs with similar properties and provides useful knowledge in the engineering decision making process. Also, it opens the route for further refinements of specific design candidates which exhibit certain characteristic features. In this work, an approach to define meaningful and consistent concepts in an existing engineering dataset is presented. The designs in the dataset are characterized by a multitude of features such as design parameters, geometrical properties or performance values of the design for various boundary conditions. In the proposed approach the complete feature set is partitioned into several subsets called description spaces. The definition of the concepts respects this partitioning which leads to several desired properties of the identified concepts, which cannot be achieved with state-of-the-art clustering or concept identification approaches. A novel concept quality measure is proposed, which provides an objective value for a given definition of concepts in a dataset. The usefulness of the measure is demonstrated by considering a realistic engineering dataset consisting of about 2500 airfoil profiles where the performance values (lift and drag) for three different operating conditions were obtained by a computational fluid dynamics simulation. A numerical optimization procedure is employed which maximizes the concept quality measure, and finds meaningful concepts for different setups of the description spaces while also incorporating user preference. It is demonstrated how these concepts can be used to select archetypal representatives of the dataset which exhibit characteristic features of each concept.
