A Comparison of Residual-based Methods on Fault Detection

An important initial step in fault detection for complex industrial systems is gaining an understanding of their health condition. Subsequently, continuous monitoring of this health condition becomes crucial to observe its evolution, track changes over time, and isolate faults. As faults are typically rare occurrences, it is essential to perform this monitoring in an unsupervised manner. Various approaches have been proposed not only to detect faults in an unsupervised manner but also to distinguish between different potential fault types. In this study, we perform a comprehensive comparison between two residual-based approaches: autoencoders, and the input-output models that establish a mapping between operating conditions and sensor readings. We explore the sensor-wise residuals and aggregated residuals for the entire system in both methods. The performance evaluation focuses on three tasks: health indicator construction, fault detection, and health indicator interpretation. To perform the comparison, we utilize the Commercial Modular Aero-Propulsion System Simulation (C-MAPSS) dynamical model, specifically a subset of the turbofan engine dataset containing three different fault types. All models are trained exclusively on healthy data. Fault detection is achieved by applying a threshold that is determined based on the healthy condition. The detection results reveal that both models are capable of detecting faults with an average delay of around 20 cycles and maintain a low false positive rate. While the fault detection performance is similar for both models, the input-output model provides better interpretability regarding potential fault types and the possible faulty components.

Vacuum Circuit Breaker Closing Time Key Moments Detection via Vibration Monitoring: A Run-to-Failure Study

Circuit breakers (CBs) play an important role in modern society because they make the power transmission and distribution systems reliable and resilient. Therefore, it is important to maintain their reliability and to monitor their operation. A key to ensure a reliable operation of CBs is to monitor their condition. In this work, we performed an accelerated life testing for mechanical failures of a vacuum circuit breaker (VCB) by performing close-open operations continuously until failure. We recorded data for each operation and made the collected run-to-failure dataset publicly available. In our experiments, the VCB operated more than 26000 close-open operations without current load with the time span of five months. The run-to-failure long-term monitoring enables us to monitor the evolution of the VCB condition and the degradation over time. To monitor CB condition, closing time is one of the indicators, which is usually measured when the CB is taken out of operation and is completely disconnected from the network. We propose an algorithm that enables to infer the same information on the closing time from a non-intrusive sensor. By utilizing the short-time energy (STE) of the vibration signal, it is possible to identify the key moments when specific events happen including the time when the latch starts to move, and the closing time. The effectiveness of the proposed algorithm is evaluated on the VCB dataset and is also compared to the binary segmentation (BS) change point detection algorithm. This research highlights the potential for continuous online condition monitoring, which is the basis for applying future predictive maintenance strategies.

Interpretable Partial Discharge Detection with Temporal Convolution and Pulse Activation Maps: An application to Power Lines

Partial discharge (PD) is a common indication of insulation damages in power systems and cables. These damages can eventually result in costly repairs and substantial power outages. PD detection traditionally relies on hand-crafted features and domain expertise to identify very specific pulses in the electrical current, and the performance declines in the presence of noise or of superposed pulses. In this paper, we propose a novel end-to-end framework based on convolutional neural networks. The framework has two contributions. First, it does not require any feature extraction and enables robust PD detection. Second, we devise the pulse activation map. It provides interpretability of the results for the domain experts with the identification of the pulses that led to the detection of the PDs. The performance is evaluated on a public dataset for the detection of damaged power lines. An ablation study demonstrates the benefits of each part of the proposed framework.
