Scale-Preserving Automatic Concept Extraction (SPACE)

Convolutional Neural Networks (CNN) have become a common choice for industrial quality control, as well as other critical applications in the Industry 4.0. When these CNNs behave in ways unexpected to human users or developers, severe consequences can arise, such as economic losses or an increased risk to human life. Concept extraction techniques can be applied to increase the reliability and transparency of CNNs through generating global explanations for trained neural network models. The decisive features of image datasets in quality control often depend on the feature's scale; for example, the size of a hole or an edge. However, existing concept extraction methods do not correctly represent scale, which leads to problems interpreting these models as we show herein. To address this issue, we introduce the Scale-Preserving Automatic Concept Extraction (SPACE) algorithm, as a state-of-the-art alternative concept extraction technique for CNNs, focused on industrial applications. SPACE is specifically designed to overcome the aforementioned problems by avoiding scale changes throughout the concept extraction process. SPACE proposes an approach based on square slices of input images, which are selected and then tiled before being clustered into concepts. Our method provides explanations of the models' decision-making process in the form of human-understandable concepts. We evaluate SPACE on three image classification datasets in the context of industrial quality control. Through experimental results, we illustrate how SPACE outperforms other methods and provides actionable insights on the decision mechanisms of CNNs. Finally, code for the implementation of SPACE is provided.

Scalable Concept Extraction in Industry 4.0

The industry 4.0 is leveraging digital technologies and machine learning techniques to connect and optimize manufacturing processes. Central to this idea is the ability to transform raw data into human understandable knowledge for reliable data-driven decision-making. Convolutional Neural Networks (CNNs) have been instrumental in processing image data, yet, their ``black box'' nature complicates the understanding of their prediction process. In this context, recent advances in the field of eXplainable Artificial Intelligence (XAI) have proposed the extraction and localization of concepts, or which visual cues intervene on the prediction process of CNNs. This paper tackles the application of concept extraction (CE) methods to industry 4.0 scenarios. To this end, we modify a recently developed technique, ``Extracting Concepts with Local Aggregated Descriptors'' (ECLAD), improving its scalability. Specifically, we propose a novel procedure for calculating concept importance, utilizing a wrapper function designed for CNNs. This process is aimed at decreasing the number of times each image needs to be evaluated. Subsequently, we demonstrate the potential of CE methods, by applying them in three industrial use cases. We selected three representative use cases in the context of quality control for material design (tailored textiles), manufacturing (carbon fiber reinforcement), and maintenance (photovoltaic module inspection). In these examples, CE was able to successfully extract and locate concepts directly related to each task. This is, the visual cues related to each concept, coincided with what human experts would use to perform the task themselves, even when the visual cues were entangled between multiple classes. Through empirical results, we show that CE can be applied for understanding CNNs in an industrial context, giving useful insights that can relate to domain knowledge.
