Process signature-driven high spatio-temporal resolution alignment of multimodal data

We present HiRA-Pro, a novel procedure to align, at high spatio-temporal resolutions, multimodal signals from real-world processes and systems that exhibit diverse transient, nonlinear stochastic dynamics, such as manufacturing machines. It is based on discerning and synchronizing the process signatures of salient kinematic and dynamic events in these disparate signals. HiRA-Pro addresses the challenge of aligning data with sub-millisecond phenomena, where traditional timestamp, external trigger, or clock-based alignment methods fall short. The effectiveness of HiRA-Pro is demonstrated in a smart manufacturing context, where it aligns data from 13+ channels acquired during 3D-printing and milling operations on an Optomec-LENS MTS 500 hybrid machine. The aligned data is then voxelized to generate 0.25 second aligned data chunks that correspond to physical voxels on the produced part. The superiority of HiRA-Pro is further showcased through case studies in additive manufacturing, demonstrating improved machine learning-based predictive performance due to precise multimodal data alignment. Specifically, testing classification accuracies improved by almost 35% with the application of HiRA-Pro, even with limited data, allowing for precise localization of artifacts. The paper also provides a comprehensive discussion on the proposed method, its applications, and comparative qualitative analysis with a few other alignment methods. HiRA-Pro achieves temporal-spatial resolutions of 10-1000 us and 100 um in order to generate datasets that register with physical voxels on the 3D-printed and milled part. These resolutions are at least an order of magnitude finer than the existing alignment methods that employ individual timestamps, statistical correlations, or common clocks, which achieve precision of hundreds of milliseconds.

In-situ surface porosity prediction in DED (directed energy deposition) printed SS316L parts using multimodal sensor fusion

This study aims to relate the time-frequency patterns of acoustic emission (AE) and other multi-modal sensor data collected in a hybrid directed energy deposition (DED) process to the pore formations at high spatial (0.5 mm) and time (< 1ms) resolutions. Adapting an explainable AI method in LIME (Local Interpretable Model-Agnostic Explanations), certain high-frequency waveform signatures of AE are to be attributed to two major pathways for pore formation in a DED process, namely, spatter events and insufficient fusion between adjacent printing tracks from low heat input. This approach opens an exciting possibility to predict, in real-time, the presence of a pore in every voxel (0.5 mm in size) as they are printed, a major leap forward compared to prior efforts. Synchronized multimodal sensor data including force, AE, vibration and temperature were gathered while an SS316L material sample was printed and subsequently machined. A deep convolution neural network classifier was used to identify the presence of pores on a voxel surface based on time-frequency patterns (spectrograms) of the sensor data collected during the process chain. The results suggest signals collected during DED were more sensitive compared to those from machining for detecting porosity in voxels (classification test accuracy of 87%). The underlying explanations drawn from LIME analysis suggests that energy captured in high frequency AE waveforms are 33% lower for porous voxels indicating a relatively lower laser-material interaction in the melt pool, and hence insufficient fusion and poor overlap between adjacent printing tracks. The porous voxels for which spatter events were prevalent during printing had about 27% higher energy contents in the high frequency AE band compared to other porous voxels. These signatures from AE signal can further the understanding of pore formation from spatter and insufficient fusion.
