Formal Language Constraints for Markov Decision Processes

In order to satisfy safety conditions, a reinforcement learned (RL) agent maybe constrained from acting freely, e.g., to prevent trajectories that might cause unwanted behavior or physical damage in a robot. We propose a general framework for augmenting a Markov decision process (MDP) with constraints that are described in formal languages over sequences of MDP states and agent actions. Constraint enforcement is implemented by filtering the allowed action set or by applying potential-based reward shaping to implement hard and soft constraint enforcement, respectively. We instantiate this framework using deterministic finite automata to encode constraints and propose methods of augmenting MDP observations with the state of the constraint automaton for learning. We empirically evaluate these methods with a variety of constraints by training Deep Q-Networks in Atari games as well as Proximal Policy Optimization in MuJoCo environments. We experimentally find that our approaches are effective in significantly reducing or eliminating constraint violations with either minimal negative or, depending on the constraint, a clear positive impact on final performance.
