Signal Enhancement for Magnetic Navigation Challenge Problem

Jul 23, 2020
Albert R. Gnadt, Joseph Belarge, Aaron Canciani, Lauren Conger, Joseph Curro, Alan Edelman, Peter Morales, Michael F. O'Keeffe, Jonathan Taylor, Christopher Rackauckas


Share this with someone who'll enjoy it:


Harnessing the magnetic field of the earth for navigation has shown promise as a viable alternative to other navigation systems. A magnetic navigation system collects its own magnetic field data using a magnetometer and uses magnetic anomaly maps to determine the current location. The greatest challenge with magnetic navigation arises when the magnetic field data from the magnetometer on the navigation system encompass the magnetic field from not just the earth, but also from the vehicle on which it is mounted. It is difficult to separate the earth magnetic anomaly field magnitude, which is crucial for navigation, from the total magnetic field magnitude reading from the sensor. The purpose of this challenge problem is to decouple the earth and aircraft magnetic signals in order to derive a clean signal from which to perform magnetic navigation. Baseline testing on the dataset shows that the earth magnetic field can be extracted from the total magnetic field using machine learning (ML). The challenge is to remove the aircraft magnetic field from the total magnetic field using a trained neural network. These challenges offer an opportunity to construct an effective neural network for removing the aircraft magnetic field from the dataset, using an ML algorithm integrated with physics of magnetic navigation.

* 21 pages, 4 figures. See https://github.com/MIT-AI-Accelerator/MagNav.jl for accompanying data and code
