XNORBIN: A 95 TOp/s/W Hardware Accelerator for Binary Convolutional Neural Networks

Mar 05, 2018
Andrawes Al Bahou, Geethan Karunaratne, Renzo Andri, Lukas Cavigelli, Luca Benini

Share this with someone who'll enjoy it:

Deploying state-of-the-art CNNs requires power-hungry processors and off-chip memory. This precludes the implementation of CNNs in low-power embedded systems. Recent research shows CNNs sustain extreme quantization, binarizing their weights and intermediate feature maps, thereby saving 8-32\x memory and collapsing energy-intensive sum-of-products into XNOR-and-popcount operations. We present XNORBIN, an accelerator for binary CNNs with computation tightly coupled to memory for aggressive data reuse. Implemented in UMC 65nm technology XNORBIN achieves an energy efficiency of 95 TOp/s/W and an area efficiency of 2.0 TOp/s/MGE at 0.8 V.

   Access Paper Source
