Large-Scale Classification of Shortwave Communication Signals with Machine Learning

This paper presents a deep learning approach to the classification of 160 shortwave radio signals. It addresses the typical challenges of the shortwave spectrum, which are the large number of different signal types, the presence of various analog modulations and ionospheric propagation. As a classifier a deep convolutional neural network is used, that is trained to recognize 160 typical shortwave signal classes. The approach is blind and therefore does not require preknowledge or special preprocessing of the signal and no manual design of discriminative features for each signal class. The network is trained on a large number of synthetically generated signals and high quality recordings. Finally, the network is evaluated on real-world radio signals obtained from globally deployed receiver hardware and achieves up to 90% accuracy for an observation time of only 1 second.

Comparison of Embedded Spaces for Deep Learning Classification

Embedded spaces are a key feature in deep learning. Good embedded spaces represent the data well to support classification and advanced techniques such as open-set recognition, few-short learning and explainability. This paper presents a compact overview of different techniques to design embedded spaces for classification. It compares different loss functions and constraints on the network parameters with respect to the achievable geometric structure of the embedded space. The techniques are demonstrated with two and three-dimensional embeddings for the MNIST, Fashion MNIST and CIFAR-10 datasets, allowing visual inspection of the embedded spaces.

RF Signal Classification with Synthetic Training Data and its Real-World Performance

Neural nets are a powerful method for the classification of radio signals in the electromagnetic spectrum. These neural nets are often trained with synthetically generated data due to the lack of diverse and plentiful real RF data. However, it is often unclear how neural nets trained on synthetic data perform in real-world applications. This paper investigates the impact of different RF signal impairments (such as phase, frequency and sample rate offsets, receiver filters, noise and channel models) modeled in synthetic training data with respect to the real-world performance. For that purpose, this paper trains neural nets with various synthetic training datasets with different signal impairments. After training, the neural nets are evaluated against real-world RF data collected by a software defined radio receiver in the field. This approach reveals which modeled signal impairments should be included in carefully designed synthetic datasets. The investigated showcase example can classify RF signals into one of 20 different radio signal types from the shortwave bands. It achieves an accuracy of up to 95 % in real-world operation by using carefully designed synthetic training data only.

Fourier, Gabor, Morlet or Wigner: Comparison of Time-Frequency Transforms

In digital signal processing time-frequency transforms are used to analyze time-varying signals with respect to their spectral contents over time. Apart from the commonly used short-time Fourier transform, other methods exist in literature, such as the Wavelet, Stockwell or Wigner-Ville transform. Consequently, engineers working on digital signal processing tasks are often faced with the question which transform is appropriate for a specific application. To address this question, this paper first briefly introduces the different transforms. Then it compares them with respect to the achievable resolution in time and frequency and possible artifacts. Finally, the paper contains a gallery of time-frequency representations of numerous signals from different fields of applications to allow for visual comparison.

Classification of Radio Signals and HF Transmission Modes with Deep Learning

This paper investigates deep neural networks for radio signal classification. Instead of performing modulation recognition and combining it with further analysis methods, the classifier operates directly on the IQ data of the signals and outputs the transmission mode. A data set of radio signals of 18 different modes, that commonly occur in the HF radio band, is presented and used as a showcase example. The data set considers HF channel properties and is used to train four different deep neural network architectures. The results of the best networks show an excellent accuracy of up to 98%.
