Control Architecture and Design for a Multi-robotic Visual Servoing System in Automated Manufacturing Environment

The use of robotic technology has drastically increased in manufacturing in the 21st century. But by utilizing their sensory cues, humans still outperform machines, especially in micro scale manufacturing, which requires high-precision robot manipulators. These sensory cues naturally compensate for high levels of uncertainties that exist in the manufacturing environment. Uncertainties in performing manufacturing tasks may come from measurement noise, model inaccuracy, joint compliance (e.g., elasticity), etc. Although advanced metrology sensors and high precision microprocessors, which are utilized in modern robots, have compensated for many structural and dynamic errors in robot positioning, a well-designed control algorithm still works as a comparable and cheaper alternative to reduce uncertainties in automated manufacturing. Our work illustrates that a multi-robot control system that simulates the positioning process for fastening and unfastening applications can reduce various uncertainties, which may occur in this process, to a great extent. In addition, most research papers in visual servoing mainly focus on developing control and observation architectures in various scenarios, but few have discussed the importance of the camera's location in the configuration. In a manufacturing environment, the quality of camera estimations may vary significantly from one observation location to another, as the combined effects of environmental conditions result in different noise levels of a single image shot at different locations. Therefore, in this paper, we also propose a novel algorithm for the camera's moving policy so that it explores the camera workspace and searches for the optimal location where the image noise level is minimized.

Role of Uncertainty in Model Development and Control Design for a Manufacturing Process

The use of robotic technology has drastically increased in manufacturing in the 21st century. But by utilizing their sensory cues, humans still outperform machines, especially in the micro scale manufacturing, which requires high-precision robot manipulators. These sensory cues naturally compensate for high level of uncertainties that exist in the manufacturing environment. Uncertainties in performing manufacturing tasks may come from measurement noise, model inaccuracy, joint compliance (e.g., elasticity) etc. Although advanced metrology sensors and high-precision microprocessors, which are utilized in nowadays robots, have compensated for many structural and dynamic errors in robot positioning, but a well-designed control algorithm still works as a comparable and cheaper alternative to reduce uncertainties in automated manufacturing. Our work illustrates that a multi-robot control system can reduce various uncertainties to a great amount.

Energy Aware Camera Location Search Algorithm for Increasing Precision of Observation in Automated Manufacturing

Visual servoing technology has been well developed and applied in many automated manufacturing tasks, especially in tools' pose alignment. To access a full global view of tools, most applications adopt eye-to-hand configuration or eye-to-hand/eye-in-hand cooperation configuration in an automated manufacturing environment. Most research papers mainly put efforts into developing control and observation architectures in various scenarios, but few of them have discussed the importance of the camera's location in eye-to-hand configuration. In a manufacturing environment, the quality of camera estimations may vary significantly from one observation location to another, as the combined effects of environmental conditions result in different noise levels of a single image shot at different locations. In this paper, we propose an algorithm for the camera's moving policy so that it explores the camera workspace and searches for the optimal location where the images' noise level is minimized. Also, this algorithm ensures the camera ends up at a suboptimal (if the optimal one is unreachable) location among the locations already searched, with limited energy available for moving the camera. Unlike a simple brute force approach, the algorithm enables the camera to explore space more efficiently by adapting the search policy from learning the environment. With the aid of an image averaging technique, this algorithm, in use of a solo camera, achieves the observation accuracy in eye-to-hand configurations to a desirable extent without filtering out high-frequency information in the original image. An automated manufacturing application has been simulated and the results show the success of this algorithm's improvement of observation precision with limited energy.

A Novel Feedforward Youla Parameterization Method for Avoiding Local Minima in Stereo Image Based Visual Servoing Control

In robot navigation and manipulation, accurately determining the camera's pose relative to the environment is crucial for effective task execution. In this paper, we systematically prove that this problem corresponds to the Perspective-3-Point (P3P) formulation, where exactly three known 3D points and their corresponding 2D image projections are used to estimate the pose of a stereo camera. In image-based visual servoing (IBVS) control, the system becomes overdetermined, as the 6 degrees of freedom (DoF) of the stereo camera must align with 9 observed 2D features in the scene. When more constraints are imposed than available DoFs, global stability cannot be guaranteed, as the camera may become trapped in a local minimum far from the desired configuration during servoing. To address this issue, we propose a novel control strategy for accurately positioning a calibrated stereo camera. Our approach integrates a feedforward controller with a Youla parameterization-based feedback controller, ensuring robust servoing performance. Through simulations, we demonstrate that our method effectively avoids local minima and enables the camera to reach the desired pose accurately and efficiently.

Innovative Adaptive Imaged Based Visual Servoing Control of 6 DoFs Industrial Robot Manipulators

Image-based visual servoing (IBVS) methods have been well developed and used in many applications, especially in pose (position and orientation) alignment. However, most research papers focused on developing control solutions when 3D point features can be detected inside the field of view. This work proposes an innovative feedforward-feedback adaptive control algorithm structure with the Youla Parameterization method. A designed feature estimation loop ensures stable and fast motion control when point features are outside the field of view. As 3D point features move inside the field of view, the IBVS feedback loop preserves the precision of the pose at the end of the control period. Also, an adaptive controller is developed in the feedback loop to stabilize the system in the entire range of operations. The nonlinear camera and robot manipulator model is linearized and decoupled online by an adaptive algorithm. The adaptive controller is then computed based on the linearized model evaluated at current linearized point. The proposed solution is robust and easy to implement in different industrial robotic systems. Various scenarios are used in simulations to validate the effectiveness and robust performance of the proposed controller.

The negation of permutation mass function

Negation is an important perspective of knowledge representation. Existing negation methods are mainly applied in probability theory, evidence theory and complex evidence theory. As a generalization of evidence theory, random permutation sets theory may represent information more precisely. However, how to apply the concept of negation to random permutation sets theory has not been studied. In this paper, the negation of permutation mass function is proposed. Moreover, in the negation process, the convergence of proposed negation method is verified. The trends of uncertainty and dissimilarity after each negation operation are investigated. Numerical examples are used to demonstrate the rationality of the proposed method.
