Structural Plan-to-Model Conversion with Deterministic Geometry and Guarded Agentic Vision-Language Refinement

Converting structural framing plans into editable finite-element model drafts remains labor-intensive and prone to transcription error. Existing drawing-understanding systems for building components rely on task-specific trained neural detectors, and language-model agents in structural engineering operate on text or model data rather than the drawing itself. This paper presents, to the authors' knowledge, the first framework applying an agentic vision-language layer to structural component detection and model drafting from framing-plan PDFs, without task-specific detector training or fine-tuning. A deterministic stage extracts primitives, estimates scale by dimension-ratio consensus, recognizes five entity classes with a drafting grammar, and assembles an editable layout. The agentic stage proposes typed corrections constrained by deterministic candidates, operation-specific admission tests, change-level review, and fail-closed transactions. Evaluation used an author-generated benchmark of 100 plans: a development half that informed every rule revision, and a seed-disjoint held-out half generated after the rules froze, evaluated once. All reported scores are end-to-end results of the complete framework on the held-out half. Scale was estimated within 0.1% of the generator reference for every drawing. Recall and precision were 0.922/0.997 for columns, 0.886/0.990 for beams, 1.000/1.000 for walls, 1.000/1.000 for braces, and 1.000/0.964 for openings. A controlled study repeated two corruptions three times on three development drawings. Calibration passed all nine trials; member repair met every strict end-state predicate in five of nine. Guarded review corrected missed framing and false marks within explicit bounds. The held-out half shares the development generator, so the study excludes independently drafted plans, raster evaluation, analytical connectivity, and solver validation.

An Open-Source Framework for Coupled Vehicle-Bridge Interaction Analysis Using OpenSees

Vehicle-bridge interaction (VBI) is important for simulating bridge response under moving vehicular loads and supports applications such as dynamic amplification studies, weigh-in-motion, and indirect bridge monitoring. Although VBI theory is well established, many existing implementations use custom finite element code or research-specific solvers, which limits their reuse. This paper presents an open-source Python framework for VBI analysis built on OpenSees. The bridge and vehicle are modeled as separate OpenSees subsystems and connected through an iterative scheme that exchanges displacement and force values at each time step until convergence. Five vehicle model types are supported, from a single axle spring-mass system to two-axle composite half-cars with body pitch and separate tyre and suspension elements. A decoupled mode is also provided: the vehicle static weight is applied as a moving load on the bridge, and the resulting bridge motion is then used as base excitation for the vehicle. Validation against three published benchmarks (quarter-car, half-car with pitch, and full composite models) shows close agreement, with R2 above 0.998 in all cases. A parametric study reports the accuracy of the decoupled mode as a function of vehicle-to-bridge mass ratio, span length, speed, road roughness class, and background traffic density, and indicates when the decoupled mode is adequate and when full coupling is needed. The complete framework and benchmark configurations are released as open-source software to support reproducible research in vehicle-bridge dynamics.

Integration of Object Detection and Small VLMs for Construction Safety Hazard Identification

Accurate and timely identification of construction hazards around workers is essential for preventing workplace accidents. While large vision-language models (VLMs) demonstrate strong contextual reasoning capabilities, their high computational requirements limit their applicability in near real-time construction hazard detection. In contrast, small vision-language models (sVLMs) with fewer than 4 billion parameters offer improved efficiency but often suffer from reduced accuracy and hallucination when analyzing complex construction scenes. To address this trade-off, this study proposes a detection-guided sVLM framework that integrates object detection with multimodal reasoning for contextual hazard identification. The framework first employs a YOLOv11n detector to localize workers and construction machinery within the scene. The detected entities are then embedded into structured prompts to guide the reasoning process of sVLMs, enabling spatially grounded hazard assessment. Within this framework, six sVLMs (Gemma-3 4B, Qwen-3-VL 2B/4B, InternVL-3 1B/2B, and SmolVLM-2B) were evaluated in zero-shot settings on a curated dataset of construction site images with hazard annotations and explanatory rationales. The proposed approach consistently improved hazard detection performance across all models. The best-performing model, Gemma-3 4B, achieved an F1-score of 50.6%, compared to 34.5% in the baseline configuration. Explanation quality also improved significantly, with BERTScore F1 increasing from 0.61 to 0.82. Despite incorporating object detection, the framework introduces minimal overhead, adding only 2.5 ms per image during inference. These results demonstrate that integrating lightweight object detection with small VLM reasoning provides an effective and efficient solution for context-aware construction safety hazard detection.

Fine-Tuning Large Language Models and Evaluating Retrieval Methods for Improved Question Answering on Building Codes

Building codes are regulations that establish standards for the design, construction, and safety of buildings to ensure structural integrity, fire protection, and accessibility. They are often extensive, complex, and subject to frequent updates, making manual querying challenging and time-consuming. Key difficulties include navigating large volumes of text, interpreting technical language, and identifying relevant clauses across different sections. A potential solution is to build a Question-Answering (QA) system that answers user queries based on building codes. Among the various methods for building a QA system, Retrieval-Augmented Generation (RAG) stands out in performance. RAG consists of two components: a retriever and a language model. This study focuses on identifying a suitable retriever method for building codes and optimizing the generational capability of the language model using fine-tuning techniques. We conducted a detailed evaluation of various retrieval methods by performing the retrieval on the National Building Code of Canada (NBCC) and explored the impact of domain-specific fine-tuning on several language models using the dataset derived from NBCC. Our analysis included a comparative assessment of different retrievers and the performance of both pre-trained and fine-tuned models to determine the efficacy and domain-specific adaptation of language models using fine-tuning on the NBCC dataset. Experimental results showed that Elasticsearch proved to be the most robust retriever among all. The findings also indicate that fine-tuning language models on an NBCC-specific dataset can enhance their ability to generate contextually relevant responses. When combined with context retrieved by a powerful retriever like Elasticsearch, this improvement in LLM performance can optimize the RAG system, enabling it to better navigate the complexities of the NBCC.

Using Vision Language Models for Safety Hazard Identification in Construction

Safety hazard identification and prevention are the key elements of proactive safety management. Previous research has extensively explored the applications of computer vision to automatically identify hazards from image clips collected from construction sites. However, these methods struggle to identify context-specific hazards, as they focus on detecting predefined individual entities without understanding their spatial relationships and interactions. Furthermore, their limited adaptability to varying construction site guidelines and conditions hinders their generalization across different projects. These limitations reduce their ability to assess hazards in complex construction environments and adaptability to unseen risks, leading to potential safety gaps. To address these challenges, we proposed and experimentally validated a Vision Language Model (VLM)-based framework for the identification of construction hazards. The framework incorporates a prompt engineering module that structures safety guidelines into contextual queries, allowing VLM to process visual information and generate hazard assessments aligned with the regulation guide. Within this framework, we evaluated state-of-the-art VLMs, including GPT-4o, Gemini, Llama 3.2, and InternVL2, using a custom dataset of 1100 construction site images. Experimental results show that GPT-4o and Gemini 1.5 Pro outperformed alternatives and displayed promising BERTScore of 0.906 and 0.888 respectively, highlighting their ability to identify both general and context-specific hazards. However, processing times remain a significant challenge, impacting real-time feasibility. These findings offer insights into the practical deployment of VLMs for construction site hazard detection, thereby contributing to the enhancement of proactive safety management.

ErgoChat: a Visual Query System for the Ergonomic Risk Assessment of Construction Workers

In the construction sector, workers often endure prolonged periods of high-intensity physical work and prolonged use of tools, resulting in injuries and illnesses primarily linked to postural ergonomic risks, a longstanding predominant health concern. To mitigate these risks, researchers have applied various technological methods to identify the ergonomic risks that construction workers face. However, traditional ergonomic risk assessment (ERA) techniques do not offer interactive feedback. The rapidly developing vision-language models (VLMs), capable of generating textual descriptions or answering questions about ergonomic risks based on image inputs, have not yet received widespread attention. This research introduces an interactive visual query system tailored to assess the postural ergonomic risks of construction workers. The system's capabilities include visual question answering (VQA), which responds to visual queries regarding workers' exposure to postural ergonomic risks, and image captioning (IC), which generates textual descriptions of these risks from images. Additionally, this study proposes a dataset designed for training and testing such methodologies. Systematic testing indicates that the VQA functionality delivers an accuracy of 96.5%. Moreover, evaluations using nine metrics for IC and assessments from human experts indicate that the proposed approach surpasses the performance of a method using the same architecture trained solely on generic datasets. This study sets a new direction for future developments in interactive ERA using generative artificial intelligence (AI) technologies.

A Conditional Wasserstein Generative Adversarial Network for Pixel-level Crack Detection using Video Extracted Images

Automatic crack detection on pavement surfaces is an important research field in the scope of developing an intelligent transportation infrastructure system. In this paper, a novel method on the basis of conditional Wasserstein generative adversarial network (cWGAN) is proposed for road crack detection. A 121-layer densely connected neural network with deconvolution layers for multi-level feature fusion is used as generator, and a 5-layer fully convolutional network is used as discriminator. To overcome the scattered output issue related deconvolution layers, connectivity maps are introduced to represent the crack information within the proposed cWGAN. The proposed method is tested on a dataset collected from a moving vehicle equipped with a commercial grade high speed camera. This dataset is challenging because the images containing cracks also include the disturbance of other objects. The results show that the proposed method achieves state-of-the-art performance compared with other existing methods in terms of precision, recall and F1 score.
