Modifying Range-Doppler geometry frameworks to process Spotlight SAR imagery in Polar Format

We present a simple method to enable processing of Spotlight Synthetic Aperture Radar (SAR) imagery distributed in Polar Format (PFA) using standard Range-Doppler (RDA) geometry algorithms. Our approach is applicable to PFA SAR images characterized by a constant value of the Center of Aperture (COA) time. We present simplified expressions for forward (image-to-ground) and inverse (ground-to-image) geometry mapping using Sensor Independent Complex Data (SICD) conventions. We discuss simple changes needed to current open source SAR software that implement Range-Doppler algorithms, to enable support within them for Spotlight data distributed in SICD format. We include a proof-of-concept script that utilizes the Python packages sarpy and isce3 to demonstrate the correctness of the proposed approach.

Deformation monitoring with Sentinel-1 Wave mode data

We describe the salient characteristics of Sentinel-1 wave (WV) mode vignettes. We describe our approach for working with WV mode data that enables vignette-based data access and processing, thereby eliminating the Sentinel-1 Single Look Complex (SLC) data packaging and current archive metadata conventions as a bottleneck to large scale processing. We discuss the spatial and temporal coverage of Sentinel-1 WV mode data and show that a large volume of data has been acquired over land masses in this mode, thus allowing us to use it for land monitoring applications as well as ocean applications. For targeted infrastructure monitoring studies, we are able to generate coregistered, geocoded stacks of WV mode SLCs for any area of interest (AOI) with sufficient wave mode coverage, in a few minutes. We demonstrate the applicability of using WV mode data for deformation monitoring applications. Finally, we discuss the benefits and limitations of working with Sentinel-1 WV mode data.

Merging Point Data for InSAR Deformation Processing

Given a collection of points $S \subset \mathbb{R}^N$, which is partitioned into $M$ overlapping subsets $\{S_i\}_{i=1}^M$, and approximate data $\{D_i\}_{i=1}^M$ associated with the subsets, one may seek a consistent merged dataset $D$ that is derived from $\{S_i\}_{i=1}^M$ and $\{D_i\}_{i=1}^M$. This note presents a method for constructing $D$ under the assumption that $D$ represents discrete samples of a suitably smooth function $f:\mathbb{R}^N \rightarrow \mathbb{R}$ evaluated at the points in $S$. The method has two steps. The first step uses a least-squares solve to approximate the constant offsets for each $D_i$. The second step uses a sequence of discrete Dirichlet problems to resolve any remaining differences. We include a two dimensional example of this method applied to deformation measurements derived from Interferometric Synthetic Aperture Radar (InSAR).
