Robust Reinforcement Learning Algorithm for Vision-based Ship Landing of UAVs

This paper addresses the problem of developing an algorithm for autonomous ship landing of vertical take-off and landing (VTOL) capable unmanned aerial vehicles (UAVs), using only a monocular camera in the UAV for tracking and localization. Ship landing is a challenging task due to the small landing space, six degrees of freedom ship deck motion, limited visual references for localization, and adversarial environmental conditions such as wind gusts. We first develop a computer vision algorithm which estimates the relative position of the UAV with respect to a horizon reference bar on the landing platform using the image stream from a monocular vision camera on the UAV. Our approach is motivated by the actual ship landing procedure followed by the Navy helicopter pilots in tracking the horizon reference bar as a visual cue. We then develop a robust reinforcement learning (RL) algorithm for controlling the UAV towards the landing platform even in the presence of adversarial environmental conditions such as wind gusts. We demonstrate the superior performance of our algorithm compared to a benchmark nonlinear PID control approach, both in the simulation experiments using the Gazebo environment and in the real-world setting using a Parrot ANAFI quad-rotor and sub-scale ship platform undergoing 6 degrees of freedom (DOF) deck motion.

Intelligent Vision-based Autonomous Ship Landing of VTOL UAVs

The paper discusses an intelligent vision-based control solution for autonomous tracking and landing of Vertical Take-Off and Landing (VTOL) capable Unmanned Aerial Vehicles (UAVs) on ships without utilizing GPS signal. The central idea involves automating the Navy helicopter ship landing procedure where the pilot utilizes the ship as the visual reference for long-range tracking; however, refers to a standardized visual cue installed on most Navy ships called the "horizon bar" for the final approach and landing phases. This idea is implemented using a uniquely designed nonlinear controller integrated with machine vision. The vision system utilizes machine learning-based object detection for long-range ship tracking and classical computer vision for the estimation of aircraft relative position and orientation utilizing the horizon bar during the final approach and landing phases. The nonlinear controller operates based on the information estimated by the vision system and has demonstrated robust tracking performance even in the presence of uncertainties. The developed autonomous ship landing system was implemented on a quad-rotor UAV equipped with an onboard camera, and approach and landing were successfully demonstrated on a moving deck, which imitates realistic ship deck motions. Extensive simulations and flight tests were conducted to demonstrate vertical landing safety, tracking capability, and landing accuracy.

Development and Validation of a Comprehensive Helicopter Flight Dynamics Code

A comprehensive helicopter flight dynamics code is developed based on the UH-60 helicopter and named Texas A\&M University Rotorcraft Analysis Code (TRAC). This is a complete software package, which could perform trim analysis to autonomous flight simulation and the capability to model any helicopter configuration. Different components of the helicopter such as the main rotor, tail rotor, fuselage, vertical tail, and horizontal tail are modeled individually as different modules in the code and integrated to develop a complete UH-60 model. Since the code is developed on a module basis, it can be easily modified to adopt another component or configure a different helicopter. TRAC can predict the dynamic responses of both the articulated rotor blades and the helicopter fuselage and yields the required pilot control inputs to achieve trim condition for different flight regimes such as hover, forward flight, coordinated turn, climb/descent, etc. These trim results are validated with the test data obtained from the UH-60 flight tests conducted by the US Army. Beyond trim analysis, TRAC can also generate linearized models at various flight conditions based on a first-order Taylor series expansion. The extracted linear models show realistic helicopter dynamic behavior and were used to simulate a fully autonomous flight that involves a UH-60 helicopter approaching a ship and landing on the deck by implementing a Linear Quadratic Regulator (LQR) optimal controller.

A Vision-Based Control Method for Autonomous Landing of Vertical Flight Aircraft On a Moving Platform Without Using GPS

The paper discusses a novel vision-based estimation and control approach to enable fully autonomous tracking and landing of vertical take-off and landing (VTOL) capable unmanned aerial vehicles (UAVs) on moving platforms without relying on a GPS signal. A unique feature of the present method is that it accomplishes this task without tracking the landing pad itself; however, by utilizing a standardized visual cue installed normal to the landing pad and parallel to the pilot's/vehicle's line of sight. A computer vision system using a single monocular camera is developed to detect the visual cue and then accurately estimate the heading of the UAV and its relative distances in all three directions to the landing pad. Through comparison with a Vicon-based motion capture system, the capability of the present vision system to measure distances in real-time within an accuracy of less than a centimeter and heading within a degree with the right visual cue, is demonstrated. A gain-scheduled proportional integral derivative (PID) control system is integrated with the vision system and then implemented on a quad-rotor-UAV dynamic model in a realistic simulation program called Gazebo. Extensive simulations are conducted to demonstrate the ability of the controller to achieve robust tracking and landing on platforms moving in arbitrary trajectories. Repeated flight tests, using both stationary and moving platforms are successfully conducted with less than 5 centimeters of landing error.
