Optimizing Bipolar Constellations for High-Rate Transmission in Short-Reach Fiber Links with Direct Detection

Bipolar modulation increases the achievable information rate of communication links with direct-detection receivers. This paper optimizes bipolar transmission with a modulator bias offset for short-reach fiber links. A neural network equalizer with successive interference cancellation is shown to gain over 100 Gbit/s compared to standard receivers.

Information Rates of Successive Interference Cancellation for Optical Fiber

Successive interference cancellation (SIC) is used to approach the achievable information rates (AIRs) of joint detection and decoding for long-haul optical fiber links. The AIRs of memoryless ring constellations are compared to those of circularly symmetric complex Gaussian modulation for surrogate channel models with correlated phase noise. Simulations are performed for 1000 km of standard single-mode fiber with ideal Raman amplification. In this setup, 32 rings and 16 SIC-stages with Gaussian message-passing receivers achieve the AIR peaks of previous work. The computational complexity scales in proportion to the number of SIC-stages, where one stage has the complexity of separate detection and decoding.

Neural Network Equalizers and Successive Interference Cancellation for Bandlimited Channels with a Nonlinearity

Neural networks (NNs) inspired by the forward-backward algorithm (FBA) are used as equalizers for bandlimited channels with a memoryless nonlinearity. The NN-equalizers are combined with successive interference cancellation (SIC) to approach the information rates of joint detection and decoding (JDD) with considerably less complexity than JDD and other existing equalizers. Simulations for short-haul optical fiber links with square-law detection illustrate the gains of NNs as compared to the complexity-limited FBA and Gibbs sampling.

Comparison of PAM-6 Modulations for Short-Reach Fiber-Optic Links with Intensity Modulation and Direct Detection

PAM-6 transmission is considered for short-reach fiber-optic links with intensity modulation and direct detection. Experiments show that probabilistically-shaped PAM-6 and a framed-cross QAM-32 constellation outperform conventional cross QAM-32 under a peak power constraint.

Experiments on Bipolar Transmission with Direct Detection

Achievable information rates of bipolar 4- and 8-ary constellations are experimentally compared to those of intensity modulation (IM) when using an oversampled direct detection receiver. The bipolar constellations gain up to 1.8 dB over their IM counterparts.

Regular Perturbation and Achievable Rates of Space-Division Multiplexed Optical Channels

Regular perturbation is applied to space-division multiplexing (SDM) on optical fibers and motivates a correlated rotation-and-additive noise (CRAN) model. For S spatial modes, or 2S complex-alphabet channels, the model has 4S(S+1) hidden independent real Gauss-Markov processes, of which 2S model phase noise, 2S(2S-1) model spatial mode rotation, and 4S model additive noise. Achievable information rates of multi-carrier communication are computed by using particle filters. For S=2 spatial modes with strong coupling and a 1000 km link, joint processing of the spatial modes gains 0.5 bits/s/Hz/channel in rate and 1.4 dB in power with respect to separate processing of 2S complex-alphabet channels without considering CRAN.
