Evaluation of Zadoff-Chu, Kasami and Chirp based encoding schemes for Acoustic Local Positioning Systems

The task of determining the physical coordinates of a target in indoor environments is still a key factor for many applications including people and robot navigation, user tracking, location-based advertising, augmented reality, gaming, emergency response or ambient assisted living environments. Among the different possibilities for indoor positioning, Acoustic Local Positioning Systems (ALPS) have the potential for centimeter level positioning accuracy with coverage distances up to tens of meters. In addition, acoustic transducers are small, low cost and reliable thanks to the room constrained propagation of these mechanical waves. Waveform design (coding and modulation) is usually incorporated into these systems to facilitate the detection of the transmitted signals at the receiver. The aperiodic correlation properties of the emitted signals have a large impact on how the ALPS cope with common impairment factors such as multipath propagation, multiple access interference, Doppler shifting, near-far effect or ambient noise. This work analyzes three of the most promising families of codes found in the literature for ALPS: Kasami codes, Zadoff-Chu and Orthogonal Chirp signals. The performance of these codes is evaluated in terms of time of arrival accuracy and characterized by means of model simulation under realistic conditions and by means of experimental tests in controlled environments. The results derived from this study can be of interest for other applications based on spreading sequences, such as underwater acoustic systems, ultrasonic imaging or even Code Division Multiple Access (CDMA) communications systems.

Acoustic Local Positioning With Encoded Emission Beacons

Acoustic local positioning systems (ALPSs) are an interesting alternative for indoor positioning due to certain advantages over other approaches, including their relatively high accuracy, low cost, and room-level signal propagation. Centimeter-level or fine-grained indoor positioning can be an asset for robot navigation, guiding a person to, for instance, a particular piece in a museum or to a specific product in a shop, targeted advertising, or augmented reality. In airborne system applications, acoustic positioning can be based on using opportunistic signals or sounds produced by the person or object to be located (e.g., noise from appliances or the speech from a speaker) or from encoded emission beacons (or anchors) specifically designed for this purpose. This work presents a review of the different challenges that designers of systems based on encoded emission beacons must address in order to achieve suitable performance. At low-level processing, the waveform design (coding and modulation) and the processing of the received signal are key factors to address such drawbacks as multipath propagation, multiple-access interference, nearfar effect, or Doppler shifting. With regards to high-level system design, the issues to be addressed are related to the distribution of beacons, ease of deployment, and calibration and positioning algorithms, including the possible fusion of information. Apart from theoretical discussions, this work also includes the description of an ALPS that was implemented, installed in a large area and tested for mobile robot navigation. In addition to practical interest for real applications, airborne ALPSs can also be used as an excellent platform to test complex algorithms, which can be subsequently adapted for other positioning systems, such as underwater acoustic systems or ultrawideband radiofrequency (UWB RF) systems.

Multipath Compensation Algorithm for TDMA-Based Ultrasonic Local Positioning Systems

This paper proposes a multipath compensation algorithm (MCA) to enhance the performance of an ultrasonic local positioning system under adverse multipath conditions. The proposed algorithm is based on the accurate estimation of the environment impulse response from which the corresponding line of sight for each channel is obtained. Experimental results in two different environments and with different conditions have been conducted in order to evaluate the performance of this proposal. In both environments, results confirm the expected improvements, even under severe multipath conditions where positioning errors have been reduced from 44 to 9 cm for the 95% of the measurements.

Simultaneous Calibration and Navigation (SCAN) of Multiple Ultrasonic Local Positioning Systems

This paper proposes a Simultaneous Calibration and Navigation (SCAN) algorithm of a multiple Ultrasonic Local Positioning Systems (ULPSs) that cover an extensive indoor area. The idea is the development of the same concept than SLAM (Simultaneous Localization and Mapping), in which a Mobile Robot (MR) estimates the map while it is navigating. The MR calibrates the beacons of several ULPSs while it is moving inside the localization area. The concept of calibration is the estimation of the position of the beacons referenced to a known map. The scenario is composed of some calibrated ULPSs that we denote as Globally Referenced Ultrasonic Local Positioning Systems (GRULPSs) that are located in strategic points like entrances covering the start and the end of a possible trajectory in the environment. Additionally, there are several non-calibrated ULPSs named Locally Referenced Ultrasonic Local Positioning Systems (LRULPSs) that are placed around the localization area. The proposal uses a MR with odometer for calibrating the beacons of the LRULPSs while it is navigating on their coverage area and go from one GRULPS to another. The algorithm is based on multiple filters running in parallel (one filter for each LRULPS and another one for the GRULPSs) that estimate the global and local trajectories of the MR (one trajectory for each local reference system of the LRULPSs) fusing the information related to the Ultrasound Signals (US) and the odometer of the MR. The position of the beacons of the LRULPSs are obtained by a transformation vector for each LRULPS that converts the local coordinates to the global reference system. Extended Kalman Filter (EKF), Unscented Kalman Filter (UKF) and H-Inf Filter have been tested, in simulations and real experiments, in order to compare their performance in this case.
