Estimating optical vegetation indices with Sentinel-1 SAR data and AutoML

Current optical vegetation indices (VIs) for monitoring forest ecosystems are widely used in various applications. However, continuous monitoring based on optical satellite data can be hampered by atmospheric effects such as clouds. On the contrary, synthetic aperture radar (SAR) data can offer insightful and systematic forest monitoring with complete time series due to signal penetration through clouds and day and night acquisitions. The goal of this work is to overcome the issues affecting optical data with SAR data and serve as a substitute for estimating optical VIs for forests using machine learning. Time series of four VIs (LAI, FAPAR, EVI and NDVI) were estimated using multitemporal Sentinel-1 SAR and ancillary data. This was enabled by creating a paired multi-temporal and multi-modal dataset in Google Earth Engine (GEE), including temporally and spatially aligned Sentinel-1, Sentinel-2, digital elevation model (DEM), weather and land cover datasets (MMT-GEE). The use of ancillary features generated from DEM and weather data improved the results. The open-source Automatic Machine Learning (AutoML) approach, auto-sklearn, outperformed Random Forest Regression for three out of four VIs, while a 1-hour optimization length was enough to achieve sufficient results with an R2 of 69-84% low errors (0.05-0.32 of MAE depending on VI). Great agreement was also found for selected case studies in the time series analysis and in the spatial comparison between the original and estimated SAR-based VIs. In general, compared to VIs from currently freely available optical satellite data and available global VI products, a better temporal resolution (up to 240 measurements/year) and a better spatial resolution (20 m) were achieved using estimated SAR-based VIs. A great advantage of the SAR-based VI is the ability to detect abrupt forest changes with a sub-weekly temporal accuracy.
