3-DUSSS: 3-Dimensional Ultrasonic Self Supervised Segmentation

This study introduces a novel self-supervised learning approach for volumetric segmentation of defect indications captured by phased array ultrasonic testing data from Carbon Fiber Reinforced Polymers (CFRPs). By employing this self-supervised method, defect segmentation is achieved automatically without the need for labelled training data or examples of defects. The approach has been tested using artificially induced defects, including back-drilled holes and Polytetrafluoroethylene (PTFE) inserts, to mimic different defect responses. Additionally, it has been evaluated on stepped geometries with varying thickness, demonstrating impressive generalization across various test scenarios. Minimal preprocessing requirements are needed, with no removal of geometric features or Time-Compensated Gain (TCG) necessary for applying the methodology. The model's performance was evaluated for defect detection, in-plane and through-thickness localisation, as well as defect sizing. All defects were consistently detected with thresholding and different processing steps able to remove false positive indications for a 100% detection accuracy. Defect sizing aligns with the industrial standard 6 dB amplitude drop method, with a Mean Absolute Error (MAE) of 1.41 mm. In-plane and through-thickness localisation yielded comparable results, with MAEs of 0.37 and 0.26 mm, respectively. Visualisations are provided to illustrate how this approach can be utilised to generate digital twins of components.

GANs and alternative methods of synthetic noise generation for domain adaption of defect classification of Non-destructive ultrasonic testing

This work provides a solution to the challenge of small amounts of training data in Non-Destructive Ultrasonic Testing for composite components. It was demonstrated that direct simulation alone is ineffective at producing training data that was representative of the experimental domain due to poor noise reconstruction. Therefore, four unique synthetic data generation methods were proposed which use semi-analytical simulated data as a foundation. Each method was evaluated on its classification performance of real experimental images when trained on a Convolutional Neural Network which underwent hyperparameter optimization using a genetic algorithm. The first method introduced task specific modifications to CycleGAN, to learn the mapping from physics-based simulations of defect indications to experimental indications in resulting ultrasound images. The second method was based on combining real experimental defect free images with simulated defect responses. The final two methods fully simulated the noise responses at an image and signal level respectively. The purely simulated data produced a mean classification F1 score of 0.394. However, when trained on the new synthetic datasets, a significant improvement in classification performance on experimental data was realized, with mean classification F1 scores of 0.843, 0.688, 0.629, and 0.738 for the respective approaches.
