What Averages Do Not Tell -- Predicting Real Life Processes with Sequential Deep Learning

Deep Learning is proven to be an effective tool for modeling sequential data as shown by the success in Natural Language, Computer Vision and Signal Processing. Process Mining concerns discovering insights on business processes from their execution data that are logged by supporting information systems. The logged data (event log) is formed of event sequences (traces) that correspond to executions of a process. Many Deep Learning techniques have been successfully adapted for predictive Process Mining that aims to predict process outcomes, remaining time, the next event, or even the suffix of running traces. Traces in Process Mining are multimodal sequences and very differently structured than natural language sentences or images. This may require a different approach to processing. So far, there has been little focus on these differences and the challenges introduced. Looking at suffix prediction as the most challenging of these tasks, the performance of Deep Learning models was evaluated only on average measures and for a small number of real-life event logs. Comparing the results between papers is difficult due to different pre-processing and evaluation strategies. Challenges that may be relevant are the skewness of trace-length distribution and the skewness of the activity distribution in real-life event logs. We provide an end-to-end framework which enables to compare the performance of seven state-of-the-art sequential architectures in common settings. Results show that sequence modeling still has a lot of room for improvement for majority of the more complex datasets. Further research and insights are required to get consistent performance not just in average measures but additionally over all the prefixes.

Conformance Checking of Mixed-paradigm Process Models

Mixed-paradigm process models integrate strengths of procedural and declarative representations like Petri nets and Declare. They are specifically interesting for process mining because they allow capturing complex behaviour in a compact way. A key research challenge for the proliferation of mixed-paradigm models for process mining is the lack of corresponding conformance checking techniques. In this paper, we address this problem by devising the first approach that works with intertwined state spaces of mixed-paradigm models. More specifically, our approach uses an alignment-based replay to explore the state space and compute trace fitness in a procedural way. In every state, the declarative constraints are separately updated, such that violations disable the corresponding activities. Our technique provides for an efficient replay towards an optimal alignment by respecting all orthogonal Declare constraints. We have implemented our technique in ProM and demonstrate its performance in an evaluation with real-world event logs.
