Multiplierless In-filter Computing for tinyML Platforms

Wildlife conservation using continuous monitoring of environmental factors and biomedical classification, which generate a vast amount of sensor data, is a challenge due to limited bandwidth in the case of remote monitoring. It becomes critical to have classification where data is generated, and only classified data is used for monitoring. We present a novel multiplierless framework for in-filter acoustic classification using Margin Propagation (MP) approximation used in low-power edge devices deployable in remote areas with limited connectivity. The entire design of this classification framework is based on template-based kernel machine, which include feature extraction and inference, and uses basic primitives like addition/subtraction, shift, and comparator operations, for hardware implementation. Unlike full precision training methods for traditional classification, we use MP-based approximation for training, including backpropagation mitigating approximation errors. The proposed framework is general enough for acoustic classification. However, we demonstrate the hardware friendliness of this framework by implementing a parallel Finite Impulse Response (FIR) filter bank in a kernel machine classifier optimized for a Field Programmable Gate Array (FPGA). The FIR filter acts as the feature extractor and non-linear kernel for the kernel machine implemented using MP approximation and a downsampling method to reduce the order of the filters. The FPGA implementation on Spartan 7 shows that the MP-approximated in-filter kernel machine is more efficient than traditional classification frameworks with just less than 1K slices.

In-filter Computing For Designing Ultra-light Acoustic Pattern Recognizers

We present a novel in-filter computing framework that can be used for designing ultra-light acoustic classifiers for use in smart internet-of-things (IoTs). Unlike a conventional acoustic pattern recognizer, where the feature extraction and classification are designed independently, the proposed architecture integrates the convolution and nonlinear filtering operations directly into the kernels of a Support Vector Machine (SVM). The result of this integration is a template-based SVM whose memory and computational footprint (training and inference) is light enough to be implemented on an FPGA-based IoT platform. While the proposed in-filter computing framework is general enough, in this paper, we demonstrate this concept using a Cascade of Asymmetric Resonator with Inner Hair Cells (CAR-IHC) based acoustic feature extraction algorithm. The complete system has been optimized using time-multiplexing and parallel-pipeline techniques for a Xilinx Spartan 7 series Field Programmable Gate Array (FPGA). We show that the system can achieve robust classification performance on benchmark sound recognition tasks using only ~ 1.5k Look-Up Tables (LUTs) and ~ 2.8k Flip-Flops (FFs), a significant improvement over other approaches.

Multiplierless MP-Kernel Machine For Energy-efficient Edge Devices

We present a novel framework for designing multiplierless kernel machines that can be used on resource-constrained platforms like intelligent edge devices. The framework uses a piecewise linear (PWL) approximation based on a margin propagation (MP) technique and uses only addition/subtraction, shift, comparison, and register underflow/overflow operations. We propose a hardware-friendly MP-based inference and online training algorithm that has been optimized for a Field Programmable Gate Array (FPGA) platform. Our FPGA implementation eliminates the need for DSP units and reduces the number of LUTs. By reusing the same hardware for inference and training, we show that the platform can overcome classification errors and local minima artifacts that result from the MP approximation. Using the FPGA platform, we also show that the proposed multiplierless MP-kernel machine demonstrates superior performance in terms of power, performance, and area compared to other comparable implementations.
